J7243ST 3.5GHz User Manual V1.0
Thank you for purchasing the 4G LTE Mobile WiFi. This device brings you a high speed
wireless network connection. This document will help you understand your Mobile WiFi so you
can start using it right away. Please read this document carefully before using your Mobile
WiFi.
Getting to Know Your Mobile WiFi
Note: The Mobile WiFi function descriptions and illustrations in this document are for your
reference only. The product you have purchased may vary.
Application
Wi-Fi devices (such as smartphones, tablet computers, and game consoles) or computers can
all access the Internet through Mobile WiFi. The specific connection procedure depends on the
operating system of the Wi-Fi device or computer. Establish a connection according to your
device's specific instructions.
To access the Internet through a USB port connection, just plug-and-play.
Access 4G/3G/2G Internet by PC
Note: The PC will automatically install the driver after the device is connected to the PC via
USB cable.
When the installation cannot be completed, please check the anti-virus and security software
first, you should turn off those anti-virus and security software and try it again.
www.jatontec.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jatontec J7243ST
Summary of Contents for Jatontec J7243ST
- Page 1 J7243ST 3.5GHz User Manual V1.0 Thank you for purchasing the 4G LTE Mobile WiFi. This device brings you a high speed wireless network connection. This document will help you understand your Mobile WiFi so you can start using it right away. Please read this document carefully before using your Mobile WiFi.
-
Page 2: System Request
Tips: It is recommended that you set up an convenient SSID account name and WIFI password after Log in the management page. Windows 10 1. Click Start-> Windows Setting->Network and Internet->Network and sharing Center-> Connect Network 2. Select the SSID from the WIFI list and click connect www.jatontec.com... -
Page 3: Android Mobile
3. Enter the correct wifi passport and click “add” 4. After a while, WiFi connect successfully Android Mobile 1. Click “setting” ,click “WLAN”switch to turn on WLAN 2. Select the SSID name from the List 3. Enter the wifi password and click connect www.jatontec.com... -
Page 4: Charging The Battery
If the router has not been used for long time or the battery runs out, then charging it again, the router can be not power on immediately, please charge it continuously for some time before turning it on. Method 1: use the charger to charge the device. Method 2: charge the device through a computer connection www.jatontec.com... - Page 5 No Power Supply Steady On The battery is fully charged Battery Flashing The battery is charging Steady On WiFi enabled WLAN WiFi disabled Flashing Data is transmitting. The signal is too weak or no signal SIGNAL Green The mobile network connected www.jatontec.com...
- Page 6 WiFi security setting Please set a conventional and safety SSID and wifi password as following steps. 1. Log in admin page 2. select LAN setting->WLAN 3. Enter the new SSID 4. Enter the new WIFI password 5. Click “Apply” www.jatontec.com...
- Page 7 SIM card. If the user don’t want to use the PIN code, please select the”disable”, and then to enter the correct PIN code and click “save”. Flow data Display the currently upload and download rate; Display the LAN statistics. Display the WLAN statistics. www.jatontec.com...
- Page 8 User can lock the Cell by select “Cell Selection” Searching the network When you select “manual” to searching the network, will pop up a list of the searched network. The user can select a workable network, and the device will be registered to the selected network. www.jatontec.com...
-
Page 9: Accessory List
Device will be normal heating if work long hours, weak signals or high temperature room. Which will not affect the use and life of the device. Avoid long time direct skin contact with the device. The minimum physical distance is 20cm between the device and users while turn on it. www.jatontec.com...
