Summary of Contents for Aquaport AQP-TAP-4S
- Page 2 AQUAPORT SELECT 3 STEP SYSTEM Aquaport has developed a premium range of tap mixers to suit your home or office décor and budget. From a simple 1-way lever tap to a premium 4 way Filtered Sink Mixer offering the choice of hot and cold mains water as well as chilled and ambient water from the one tap.
-
Page 3: Water Quality
WATER QUALITY System Maximum: Minimum: Caution: For use with municipal water only. Specifications 860 kpa Working Pressure 300 kpa SAFETY PRECAUTIONS 1ºC Working Temperature: 80ºC Warning: It is essential that these Installation and Operating Instructions be strictly observed, for correct operation of this appliance. -
Page 4: Installation Instructions
INSTALLATION INSTRUCTIONS A. Component identification and content check list: AQP-TAP-4S - 4 Way Tap Model Description Mains Cold Water Connection (Letter C engraved) Mains Hot Water Connection (Letter H engraved) Cold Filtered Water Shank with Brass Adapter Ambient filtered Water Shank Filtered Water Lever Mains Water Hot &... - Page 5 AQP-TAP-4G - 4 Way Tap Model Description Mains Cold Water Connection (Letter C engraved) Mains Hot Water Connection (Letter H engraved) Cold Filtered Water Shank with Brass Adapter Ambient Filtered Water Shank Filtered Water Lever Mains Water Hot & Cold Lever Aerator (located in outlet) Fittings Flexible Metal connectors...
- Page 6 B. Typical Installation Diagram A. Tap B. Cold Mains Water C. Hot Mains Water D. Flexible Metal Connectors E. Cold Filtered Water Shank F. Ambient Filtered Water Shank G. Quick Connect T Piece H. 1/4 inch tubing * I. Filtration System * J.
- Page 7 C. Faucet Installation Instructions 4. Thread the Flexible Metal Connectors (9) and tap shanks (4 & 5) through the Mixer Base (14a). Warning: Do not use any tools to fix the flexible metal connectors. Hand tight pressure only. Note: Check to make sure the mixer base o-ring is still present and is fully seated in place.
- Page 8 10. Place the 1/4 inch Quick Connection Black O-ring (12) into 14. Before turning on mains water supply, open the tap Mains the 1/4 inch Quick Connection Piece (13), and screw 1/4 inch Water Hot & Cold Levers (7) midway between full hot and full Quick Connection Piece onto the ends of the Ambient and Cold cold and remove the Aerators (8) from the tap outlets.
- Page 9 D. Tubing Installation 6. Push the tubing firmly into the quick connection fittings on the Filter System, Quick Connect T Piece and Tap connections The Tap has been supplied with quick and easy to install quick until the pencil mark is pushed next to the collet or until tubing connection pieces for your filtered water connection.
- Page 10 Quick Connection Piece and install tube. If tap is leaking at the tap handle please Faulty Tap contact Aquaport. Please make sure that the shut off valve on your filtration Shut off valve is switched off system is open.
-
Page 11: Warranty
TAP 5 YEAR LIMITED WARRANTY workmanship. Aquaport warrants the Filtered Water Sink Mixer Tap to the first 3. Product must be installed by a licensed plumber, and purchaser from the date of purchase. Product will be repaired or in accordance to relevant National Standards and State replaced at our discretion. - Page 12 9. Warranty does not cover the fitting of other devices to the To Make a Claim: outlet of the tap. EG. Tap water filter. 1. Copy of proof of purchase with date of purchase is required. 10. Warranty does not cover the fitting of non-approved in tap body Please keep purchase receipt in a safe place.
- Page 13 INSTALLATION AND OPERATING INSTRUCTIONS 11...
- Page 14 CUSTOMER HOTLINE: 1300 764 325 Aquaport Corporation Pty Ltd PO Box 81 Findon SA 5023 Australia Telephone: 1300 764 325 Facsimile: 08 8354 0722 Email: aquaport@aquaport.com.au Web: www.aquaport.com.au...
