- Page 1 Instruction Book of ROADEFEND RDT401P Driver State Analysis Warning System Roadefend Vision Technology(shanghai) Co.,Ltd...
- Page 2 2018-RDT401P-R001 I. Product Synopsis Roadefend RDT401P is a bran-new Driver ADAS Safety Monitor System based on the fifth generation of video based driver state analysis technology, which gives a warning of fatigue drive and kinds of dangerous driving behaviors by means of image recognition and driver’s mental state analysis to decrease accidents caused by fatigue drive.
-
Page 3: Product Specifications
Instructions for use of RDT401P 2018-RDT401P-R001 Figure 1. Schematic Diagram of Appearance of RDT401P Driver State Analysis Warning System 3. Product specifications Table 1 RDT-401P-WH product specifications Working Daylight Night Type RDT401P ●Yes ●Yes hours Near- Sun- Product sighted Glasses... -
Page 4: Function Instruction
Instructions for use of RDT401P 2018-RDT401P-R001 port RDT402P or other Ethernet devices RS232- communicating with RDT402 RS232- communicating with 2/RS485 external devices supporting communications 4 Function Instruction 1) All Kinds of Warning The default starting speed is 15km/h for all below kinds of warning (except for the speeding... - Page 5 [1s, 3s]. Driver Characteristics and Posture Self-calibration After RDT401P is started and the vehicle speed exceeds 30km/h (which can be set), the system will enter a period of 45-second self-calibration (the calibration time is 10s in test mode).
-
Page 6: Input/Output Interface
Analog Image Output RDT401P provides real-time analog image output in NTSC or PAL format. The signal can be used to calibrate the orientation of installation, and can also be connected with almost all the popular Car DVRs (Digital Video Record) on the market to store the videos about the driver’s driving. -
Page 7: Installation Instruction
10) Local Storage of Alarm Images RDT401P will create folders with year.month.day in an SD card and store the alarm images of the day sorted according to types of fatigue warming (sleepiness, calling, smoking, etc.). -
Page 8: Quick Installation
Instructions for use of RDT401P 2018-RDT401P-R001 2. Quick Installation 2.1. Main harness description: RDT401P main harness is 1 to 5, the schematic diagrams and functions of each joint are as follows: Figure 4.Main Harness Joints ● GPS Connection Cable - Used for connecting an external GPS antenna to position the device, calculate the speed of the vehicle by GPS data, etc. - Page 9 Instructions for use of RDT401P 2018-RDT401P-R001 Figure 5. P2 power extension harness Figure 6. Harness connection diagram 2.3.If you need to debug or check the video, connect the CVBS display by P4 cable.
-
Page 10: Product List
Bracket Figure 7. A schematic diagram of parts 4. Calibration Adjust the angle of RDT401P up and down to ensure that the driver's face is in the center of the screen of an external display. 5. Work status 1) After the vehicle starts, RDT401P will start immediately; after about 8 seconds, it will make a sound indicative of start-up completion, indicating that the product is ready for work. -
Page 11: Electrical Properties
Instructions for use of RDT401P 2018-RDT401P-R001 III. Electrical Properties Table 4 RDT-401P-WH Electrical Properties Operating Voltage +9V ~ +36V Rated Power Max Power Operating Temperature Range -20℃~ 70℃ Storage Temperature Range -30℃~ 85℃ Working Humidity 0 ~ 90 RH%±5% Failures and Solutions thereof If you experience the following problems when using the product, please resolve the failures with the aid of the following countermeasures. - Page 12 Instructions for use of RDT401P 2018-RDT401P-R001 distance is too close. distance. Maintain a correct posture for 10s in No warning is triggered when Calibration is not test mode and when hearing a beep- the driver looks around. completed. beep tone, you can test the posture warning.
-
Page 13: Security Warning
2. RDT401P Benefits RDT401P employs the method of combining the image recognition with the driving behavior analysis to give a well-intentioned warning when you are tired and inattentive. Once serious fatigue occurs, the system will give you a wake-up call in time, which is a critical moment between life and death. -
Page 14: User Notice
Instructions for use of RDT401P 2018-RDT401P-R001 VIII. User Notice The product is powered on; and after the vehicle travel speed reaches the speed value (default 15Km/h) for triggering the fatigue warning function, the product will enter the normal working condition.
