CSW-12-VD

Portable Evaporative Cooler

MADE IN

USA

Table of Contents

Summary of Contents for Advanced Radiant Systems Cool-Space CSW-12-VD

Page 1 A Product of Advanced Radiant Systems, Inc. www.cool-space.com sales@cool-space.com CSW-12-VD Portable Evaporative Cooler MADE IN IMPORTANT SAFETY INFORMATION INSIDE Serious injury or death possible • Read, understand, and follow all • safety information and instructions in this manual before using or servicing this product.
Page 3: Table Of Contents
INDEX Index Page 2 Signal Word Definitions Page 2 General Description and Use Page 3 Specifications Page 4 Wiring Page 4 How Evaporative Cooling Works Pages 5 & 6 Unpacking Page 6 & 7 Assembly Instructions Pages 7 Connecting the Water Supply Page 8 Connecting the Electrical Supply Page 8...
Page 4: General Description And Use
GENERAL DESCRIPTION & USE This unit is a compact, self-contained, high- efficiency portable evaporative cooler capable of ELECTRICAL SHOCK HAZARD lowering existing temperatures by as much as 26 FIRE HAZARD degrees. The unit draws air across water- saturated high-efficiency cooling pads, causing a Serious injury or death may •...
Page 5: Specifications
SPECIFICATIONS Air Volume 3800-CFM (2200-CFM Low), 700-FPM @ 6FT Fan Motor Variable Cooling Media Type CELdek high cellulose paper treated media pads for effective cooling and resistance to edge degradation. Cross-fluted design induces highly turbulent mixing of air & water for optimum cooling and enhanced self-cleaning.
Page 6: How Evaporative Cooling Works Pages 5
HOW EVAPORATIVE COOLING WORKS To understand how the portable evaporative cooler works a basic understanding of psychrometrics is necessary. Psychrometrics is the branch of thermodynamics devoted to the study of air and water vapor mixtures. psychrometric chart is a graphical representation of properties of moist air. To illustrate how the unit operates, some of the relevant properties are described in this section followed by a sample application.
Page 7: Unpacking
The following example illustrates the use of the psychrometric chart as it relates to evaporative cooling. Since all of the items described above are properties, any two of them describe a state point on the psychrometric chart. Once this point is determined, the values of all the other properties can be read from the chart. The example below shows a Mollier type psychrometric chart for atmospheric pressure.
Page 8 Screws: (qty. 8) Pads ASSEMBLY ELECTRICAL SHOCK HAZARD Wheel Assembly Serious injury or death may • Tools required: ” nut driver 7/16 occur. 1.) Turn unit over and place on cardboard to Disconnect from electrical protect finish • supply before and during 2.) Align wheel plate with embedded nuts on bottom of housing assembly of this product.
Page 9: Connecting The Water Supply
CONNECTING THE WATER SUPPLY ELECTRICAL SHOCK HAZARD -Do not connect this unit to any water Serious injury or death may • source where the water pressure exceeds 60 occur. psi. This will cause permanent damage to the unit. Pressures above 60 psi must use a Disconnect from electrical •...
Page 10: Start-Up Procedure
START-UP PROCEDURE Do not operate the pump when the reservoir is dry. This will cause the pump to fail and also void the warranty. There are 4 factors to consider when determining where to place your evaporative cooler. 1. Fresh air supply: The inlet side of the unit (pad side) requires a constant, uninterrupted supply of fresh air for maximum performance.
Page 11: Maintenance Pages 10
ODOR CONTROL One of the few inconvenient aspects of evaporative cooling is the control of unpleasant odors. There are two primary causes of these odors: 1. Initial wetting of new pads 2. Poor maintenance and storage behaviors and/or poor quality water. Your EVAP-series cooler has been delivered with pads that have never been wet.
Page 12 MAINTENANCE Water Chemistry Hard water contains relatively large amounts of CHEMICAL BURN HAZARD minerals, primarily calcium. A sample of water can POISONOUS GAS HAZARD contain only a specific maximum amount of dissolved solids in solution. If these concentrations increase Serious injury or death may •...
Page 13 Removing the cooling media: In order to perform any maintenance on internal components the cooling pads must be removed to ELECTRICAL SHOCK HAZARD access the inside of the unit. Serious injury or death may • Media removal / replacement is simple, if you follow occur.
Page 14: Troubleshooting
TROUBLESHOOTING ELECTRICAL SHOCK HAZARD Serious injury or death may • occur. Disconnect from electrical • supply before servicing this product. Fan System: The fan system consists of two primary elements: Fan Blade and Motor Problem Check Solution Fan won’t run and makes no sound. Power cord, extension cord, switches, and circuit Reconnect power or extension cord.
Page 15: Replacement Parts
COMMON REPLACEMENT PARTS ITEM DESCRIPTION PART NO. QUANTITY CS-F12-VD 60HZ FAN ASSEMBLY ON/OFF SWITCH CS-E110 VARIABLE SWITCH CS-E187-VD 60HZ PUMP CS-E12-101 FLOAT CS-P053.1 PAD MEDIA KIT CS-A12-101 WARRANTY WARRANTY RETURNED GOODS Your COOLSPACE unit is guaranteed against any defective material or workmanship Equipment may be accepted for return with in 90 days of shipment, when for a period of 12 months from your date of original purchase.
Page 17 COOLSPACE® Warranty Form Date Purchased: __________________________ Purchased From: _______________________________________________ Model Number: CSW- __________ Serial Number: ___________________ Company: _____________________________________________________ Contact: _______________________________________________________ Address: _______________________________________________________ Phone Number: __________________ Fax Number: ___________________ You must complete this form and return within fifteen (15) days of initial purchase to validate your cooler’s warranty.
Page 19 IMPORTANT NOTICE: DO NOT RETURN TO PLACE OF PURCHASE. Please call 800-557-5716 for technical service support and warranty information If you have questions about the product you have purchased or would like to leave us feedback, please contact us via our website www.cool-space.com or by calling 1-800-557-5716.
