Wireless timer control with 16 programmable channels to control individual receivers on daily basis
at a pre-programmed time and up to maximum of 12 times a day.
Display Information
1.
Memory slots. (Max. 12)
2.
24 hour time display
Displays 'ON' timer for indicated unit.
3.
Displays 'OFF' timer for indicated unit.
4.
Timer setting: Random 'ON/OFF' mode
5.
for security prevention.
Timer setting: Single 'ON/OFF' mode.
6.
Timer setting: 'ON/OFF' daily cycle mode.
7.
8.
Battery Status.
9.
Unit.
10. Signal indication.
11. ON / OFF' button.
12. 'UP ▲/ DOWN▼' selection.
13. 'Pause / Delete' button.
14. 'Enter' button.
15. Clock.
16. Timer.
17. Unit code selection.
Wireless Timer Control
Advertisement
Table of Contents
Summary of Contents for Kappa TMT-918
- Page 1 Wireless Timer Control Wireless timer control with 16 programmable channels to control individual receivers on daily basis at a pre-programmed time and up to maximum of 12 times a day. Display Information Memory slots. (Max. 12) 24 hour time display Displays ‘ON’...
- Page 2 Set up clock The clock has a 24 hour display. Before programming the control, enter the correct time. Press the CLOCK button for 3 seconds and the hours of the clock start flashing (Fig.1) Use the ▲ and ▼ buttons to set the hour and press ENTER (Fig.2) ...
- Page 3 Then on timer control press ‘OFF’ button once, the LED on receiver will flash to indicate programmed code is deleted. To delete all code: On receiver hold down the self learning button on receiver for 6 seconds, this will enter learning / deleting mode.
- Page 4 will start to flash. (Fig.13) With ▲ and ▼ select one of the three symbols you wish to program as. Daily timer. Once only timer. Random timer.
- Page 5 Press ‘TIMER’ to return to Main Display. ！ You can reprogram a timer simply by over lapping the memory slots. ※Hint※ During any setting, press the ‘TIMER’ button to exit out and restart your settings again. Pausing a Timer The ‘II / DEL’...
- Page 6 Child protect mode To avoid your settings being changed, a child protect mode has been built-in. The timer control will be locked and LCD screen will indicate ‘CP’ Activating CP mode Hold down both ‘ENTER’ & ‘II / DEL’ button for 3 seconds. (Fig.17) ...
- Page 7 Trouble Shooting Text on display is unclear. Press ‘TIMER’ button for 3 seconds. If there is no text or remains unclear, change the lithium battery 3V CR2032. No red RF signal indicator. Check the 12V A23 battery and replace if required. Specifications.
