- Page 1 OM-254 206A 2011−08 Description Accessory 4-1/2 In. Angle Grinder File: Accessory www.HobartWelders.com...
-
Page 2: Table Of Contents
............. . WARRANTY Hobart is registered to the ISO 9001 Quality... -
Page 3: Section 1 − Safety Precautions - Read Before Using
SECTION 1 − SAFETY PRECAUTIONS - READ BEFORE USING Pwr. Tools 2011−08 Protect yourself and others from injury — read and follow these precautions. 1-1. Symbol Usage DANGER! − Indicates a hazardous situation which, if Indicates special instructions. not avoided, will result in death or serious injury. The possible hazards are shown in the adjoining symbols or explained in the text. -
Page 4: Additional Symbols For Installation, Operation, And Maintenance
FLYING METAL or DIRT can injure eyes. SPARKS can cause fire or explosion. D Welding, chipping, wire brushing, and grinding Sparks can fly off from the equipment. The flying cause sparks and flying metal. As welds cool, sparks, hot workpiece, and hot equipment can they can throw off slag. -
Page 5: California Proposition 65 Warnings
1-4. California Proposition 65 Warnings Battery posts, terminals and related accessories contain lead This product contains chemicals, including lead, known to and lead compounds, chemicals known to the State of the state of California to cause cancer, birth defects, or other California to cause cancer and birth defects or other reproductive harm. -
Page 6: Section 2 − Additional Safety Precautions
SECTION 2 − ADDITIONAL SAFETY PRECAUTIONS Do not use this equipment unless Store wheels and accessories in a Run grinder at normal operating sure correctly location where they speed for one minute before using. assembled and working properly. protected against damage from Do not start the grinder with the impact, chemicals, and extreme wheel or accessory touching the... -
Page 7: Specifications
4-2. Specifications Maximum Voltage Amperage No Load Weight w/ Overall Arbor Size Wheel Wheel Types Rating Rating Speed Wheel Dimensions Size Length: 12-1/4 in. (31.1 cm) Grinding Wheels 7/8 in. (22.2 mm) 120 Volts 4-1/2 in. Cut-Off Wheels 5.2 lb Width: 9-3/8 in. -
Page 8: Installing And Positioning Guard
5-3. Installing And Positioning Guard Turn grinder disconnect input power before installing, adjusting, or servicing this equipment. Securely attach guard to grinder. Position guard so the operator is least exposed to the wheel or accessory Be sure guard is correctly in- stalled and adjusted before using grinder. -
Page 9: Installing/Removing Wheel
5-4. Installing/Removing Wheel Tools Needed: Turn off grinder and disconnect Inspect wheels and accessories for Slotted shoulder is on bottom of flange. input power before installing, damage before use. Replace and Place flange on spindle so that slotted adjusting, servicing this dispose of damaged or vibrating shoulder fits over flats on spindle shaft. -
Page 10: Section 6 − Operation
SECTION 6 − OPERATION 6-1. Controls Do not use this equipment unless you are sure it is correctly assembled and working properly. Power Cord Stabilizer Handle Frame Handle Power Switch Check that all components are clean, tight, working properly, and there is no visible damage before using the angle grinder. -
Page 11: Section 7 − Maintenance
SECTION 7 − MAINTENANCE 7-1. Routine Maintenance Turn off grinder and disconnect input power before installing, adjusting, or servicing this equipment. Service equipment more often if used in severe conditions. Do not use cleaners and solvents (including gasoline, tetrachloride, and ammonia) that may damage plastic parts. n = Check ~ = Clean l = Replace... - Page 15 Effective January 1, 2011 5/3/1 WARRANTY applies to all Hobart welding equipment, plasma cutters and spot welders with a Warranty Questions? serial number preface of MB or newer. Call This limited warranty supersedes all previous Hobart warranties and is exclusive with 1-800-332-3281 no other guarantees or warranties expressed or implied.
- Page 16 Thank you for purchasing Hobart. Our trained technical support team is dedicated to your satisfaction. For questions regarding performance, op- eration, or service, contact us! Resources Available Always provide Model Name and Serial/Style Number. To locate a Service Center: Call 1-800-332-3281 or visit our website at www.HobartWelders.com/wheretobuy...
