COSMOS ALCOHOL COSMOS ALCOHOL TESTER TESTER ENGLISH GEB.ANL .E Seite1 / 02.04.2005 ./ TYP 2000 ALCOHOL-TESTER BLOW STRONGLY - Champion - Pro - Sportsman - Minimum POWER DISPLAY and FITNESS TEST Insert PLEASE WAIT STRAW here The measurement cell in this machine Drink no alcohol for 20 minutes before the test.
Page 2
These instructions do not modify the conditions of guarantee and liability detailed in Cosmos Automaten GmbH’s General Conditions of Sale 92. RESALE The COSMOS ALCOHOL TESTER must not be exported to the USA without the express written permission of Cosmos Automaten GmbH. SPECIFICATIONS...
Page 4
(with their car!). Once a COSMOS ALCOHOL TESTER has been installed, customers are more careful about when they should drive but are not discouraged from drinking – whether they are drinking beer, wine or shorts.
Page 5
Cosmos and we will dispose of them for you. COSMOS AUTOMATEN GMBH AM IHLSEE 18 23795 BAD SEGEBERG...
Page 6
Motor Connection to the display 10-core cable connection to the coin mechanism board Connection to the coin mechanism Note the cut-out section! COSMOS AUTOMATEN GMBH AM IHLSEE 18 D 23795 BAD SEGEBERG Tel: 0049 (0) 4551/83838 Fax: 0049 (0) 4551/87171...
Page 7
COSMOS COSMOS ALCOHOL TESTER TYPE 2000 ALCOHOL Fixings TESTER INSTRUCTIONS Page 6 / 2005-04-02 TYPE 2000 Machine dimensions WxHxD 50x75x18 Geräte-Außenmaße BxHxT 50x75x 18 All dimensions in cm Alle Angaben in cm Blow hole max. 1.63 high blasöffnung maximal 1,63 ho...
Page 8
All the functions are automatically checked by a self-diagnostic program, thanks to microprocessor technology. The lamps can be tested simply by pressing a button. Calibration is fully automatic. Safe to operate – easy to maintain – vandal-proof COSMOS AUTOMATEN GMBH AM IHLSEE 18 23795 BAD SEGEBERG Tel: 04551/83838 Fax: 04551/87171...
Page 9
ALCOHOL Software details TESTER INSTRUCTIONS Page 08 / 2005-04-02 / TYPE 2000 The COSMOS ALCOHOL TESTER has 6 programs you can operate and adjust. Blink program 1 or 2 TON Music on or off See page 9 for Calibration Lamps light in 4 sectors No.
Page 10
ALCOHOL Calibrating with the gas simulator TESTER INSTRUCTIONS Page 09 - mg / l - / 2005-04-02 / TYPE 2000 J Your newly delivered alcohol tester is already calibrated and ready for use. It should be recalibrated every 6-8 weeks after initial commissioning (to obtain precise values, the equipment must have been switched on for at least 60 minutes).
Page 11
TESTER switched on. Moisture is “burned off”. The Cosmos Gas Simulator serves to simulate a human breath sample and therefore provides a low- cost calibration procedure. The gas simulator provides a controlled alcohol reference gas for the calibration of breath alcohol measuring devices.
Page 12
Calibration must take place every 6 month in order to ensure accurate measurement. However, Cosmos recommends calibration every 6 – 8 weeks, i.e. at the same intervals as service staff arrive to refill straws, to remove money and to calibrate.
Page 13
• Blowing in fluid interrupts the operation of the chemical cell for about one hour (E 01 is displayed) Should this occur, leave the COSMOS ALCOHOL TESTER switched on and blow into it strongly ten times using a straw. Any remaining liquid will be evaporated by the electric light bulb.
Page 14
“warming up” (evaporating the fluid, etc.). Warning!! Error messages can be caused not only by faults within the COSMOS machine itself, but also by electromagnetic interference from other unshielded equipment in the vicinity.
Page 15
COSMOS Type 2000 mother board ALCOHOL Plugs and sockets TESTER INSTRUCTIONS Page 11 / 2005-04-02 / TYPE 2000 Test COSMOS AUTOMATEN GMBH AM IHLSEE 18 23795 BAD SEGEBERG Tel: 04551/83838 Fax: 04551/87171...
Page 16
COSMOS TYPE 2000 display board ALCOHOL Plugs and sockets TESTER INSTRUCTIONS Page 12 / 2005-04-02 / TYPE 2000 ("Hupe" = buzzer)
Page 17
2000 COSMOS-ALCOHOL-TESTER TYP COSMOS ALCOHOL SOUND & ADDITIONAL BOARD TESTER This expansions module is not standard equipment INSTRUCTIONS Page 13 / 02.04.05 / TYP 2000 Sound board front 1 Recording button 2 Internal check 3 Microphone back Sound fast - slow...
Page 18
20 minutes to ensure that blood alcohol is being reduced. At the second test the display must indicate a lower value. The police also use the same electro-chemical measurement cell, among other things COSMOS AUTOMATEN GMBH AM IHLSEE 18 23795 BAD SEGEBERG Tel: 04551/83838 Fax: 04551/87171...
Page 19
Das Gerät wurde in einer Reihe von typischen Situationen getestet. Bad Segeberg 01.09.1999 COSMOS-AUTOMATEN GmbH Onno Lüttmer COSMOS AUTOMATEN GMBH - AM IHLSEE 18 - D 23795 BAD SEGEBERG Tel: 0049 (0) 4551 / 83838 Fax: 0049 (0) 4551 / 87171 e-mail: cosmos@alcoholtester.de...
