Operating pressure up to 42 MPa.
•
Operating temperature up to 500 °C.
•
Material stainless steel 1.4541.
•
Sealing component selection from different
material: Graphite, PTFE, PEEK, Viton, EPDM.
JSP, s. r. o.
CZ Raisova 547, 506 01 Jičín
Industrial Controls
+420 493 760 811 • jsp@jsp.cz
MANUAL
VS 100, VS 110, VS 120, VS 200
Isolating Vent Valve
Isolating Valve
Testing Vent Valve
Two Valve Manifolds
•
Gland packing adjuster.
•
Seat diameter 4 mm.
•
EU Type Examination Certificate
according to Directive PED 2014/68/EU.
SK Karloveská 63, 841 04 Bratislava
+421 2 6030 1080 • predaj@jsp.sk
Accessories - ND0402EN - 2018/10
www.jsp.cz
Advertisement
Table of Contents
Summary of Contents for JSP VS 100
- Page 1 Accessories - ND0402EN - 2018/10 MANUAL VS 100, VS 110, VS 120, VS 200 Isolating Vent Valve Isolating Valve Testing Vent Valve Two Valve Manifolds • • Operating pressure up to 42 MPa. Gland packing adjuster. • • Operating temperature up to 500 °C. Seat diameter 4 mm. • • Material stainless steel 1.4541. EU Type Examination Certificate according to Directive PED 2014/68/EU. • Sealing component selection from different material: Graphite, PTFE, PEEK, Viton, EPDM.
-
Page 2: Table Of Contents
Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 Contents 1. General instructions and information ......................3 1.1 Symbols used ..............................3 1.2 Scope of delivery ............................3 1.3 Description of the delivery and packing .......................3 1.4 Storage ................................3 1.5 Installation and commissioning ........................3 1.6 Spare parts ..............................3... -
Page 3: General Instructions And Information
Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 1. General instructions and information presented. The claiming party shall give identification of the product, number of the delivery note and description of the fault or defect. 1.1 Symbols used The manufacturer is not responsible for any defects caused Symbol of warning;... -
Page 4: Product Description
Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 3. Product description VS 100, VS 110, VS 120, VS 200 Isolating Vent Valve Isolating Valve Testing Vent Valve Two Valve Manifold • Operating pressure up to 42 MPa. • Operating temperature up to 500 °C. • Material stainless steel 1.4541. •... -
Page 5: Installation, Operation And Maintenanceu
Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 4. Installation, operation and maintenanceu 4.1.2 Commissioning After connection or welding of the impulse piping the shut 4.1 Installation and commissioning offvalve is ready for operation. After installation of a shut off valve into piping it is necessary to 4.1.1 General... -
Page 6: Examples Of Mounting With Brackets
Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 4.4 Examples of mounting with brackets 4.5 Connection of impulse piping by means of cutting rings Max. deviation 0.5° Deburr edges of the pipe. Max. odchylka 0,5°. Odhrotovat hrany trubky. Nasadit matici a kroužek Clean threads and contact surfaces. Install a nut and ring on the pipe. -
Page 7: Operation And Maintenance
Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 4.6 Operation and maintenance 5. Product specifications The device is attendance- and maintenance-free. 5.1 Technical specifications Only in case of a leakage of the spindle gland (version with gland packing adjuster), the leakage can be eliminated by Operation pressure: tightening the adjuster screw (position 4). - Page 8 Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 Table 1. Chemical resistance of sealing materials Medium Viton EPDM PTFE Grafit PEEK Acetone Acetylene Water solution Ammoniac Liquid Fluid Ethylene Hydraulic liquids Fireproof Hydroxides Boracic acid Lemon acid Nitric acid < 65 % Fluoric acid >...
-
Page 9: Operation Conditions
Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 5.3 Operation conditions The manifolds are designed and manufactured for operation in environment defined by conditions IE36 according to the standard EN 60721-3-3 and technical regulation PT 500026. Pressure and temperature characteristics The operating characteristics of a manifold are given by pressure and temperature, see Fig. -
Page 10: Tests, Certificates And Standards
Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 6. Tests, certificates and standards Coding on the valve: Code on the hexagon of the valve: 6.1 Tests and certificates O-ring Viton or V- KY version for oxygen Valves and manifolds VS have the following certificates and... -
Page 11: Ordering Information
Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 8. Ordering information 8.1 Ordering table Description Type • One-way vent valve VS 100 ° One-way valve VS 110 • Testing one-way vent valve VS 120 Version of inlet thread Code •... - Page 12 Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 Code Nipples, cones and cutting rings Only for thread codes • Nipple for welding ∅ ∅ ∅ ∅ 12 (∅ ∅ ∅ ∅ 14)/∅ ∅ ∅ ∅ 8 mm with cap nut M20x1.5 V12 ..
- Page 13 Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 Description Type ° VS 200 Two-way manifold Version of inlet thread Code ° Male thread M20x1.5 manometric ° Male thread M20x1.5 with tapered seat ° Male thread M16x1.5 with tapered seat (only for cutting ring, diameter of 8 mm) °...
- Page 14 Valves VS 100, VS 110, VS 120 and Two Valve Manifolds VS 200 Code Nipples, cones and cutting rings Only for thread codes • Nipple for welding ∅ ∅ ∅ ∅ 12 (∅ ∅ ∅ ∅ 14)/∅ ∅ ∅ ∅ 8 mm with cap nut M20x1.5 V12 ..
-
Page 15: Contacts
JSP, s.r.o. | Raisova 547, 506 01 Jičín, Czech Republic +420 493 760 811 | export@jsp.cz | www.jsp.cz Your Supplier:...
