AQ-Tron BAT/44892 Product Manual

Portable power source: 12/24v, 1700/3400a.

Hide thumbs

Table of Contents

Quick Links

Download this manual

PRODUCT MANUAL

SAVE THESE INSTRUCTIONS: This manual contains important safety and operating instructions. Read

through this owner's manual carefully before using your new tool. Pay close attention to all safety instruc-

tions, Warning and Caution sections. Use your tool properly and only for its intended use.

WARNING:

The appliance is not intended for use by young children or infirm persons without supervision.

Young children should be supervised to ensure that they do not play with the appliance.

The jump starters described in this manual are suitable for portable power source or off-road side

battery emergency rescues. Ratings are described as below.

BAT/44892 : 12/24V, 1700/3400A

Caution :

Contains sealed, non-spillable lead acid battery. Must be disposed of properly.

Unit should be kept at full charge.

Recharge upon purchase and immediately after each use.

Recharge if not used for six months.

Can be charged continuously without damage to unit.

WARNING : Risk of Explosive Gases

A lead acid battery is dangerous because it can generate explosive gases during normal battery

operation.

To reduce risk of explosion, follow these instructions and those of the battery manufacturer and of any

equipment you intend to use in vicinity of battery. Review warnings on these products and on battery.

Make sure someone is close enough to come to your aid when you are working with a lead-acid battery.

Avoid touching eyes while working with a lead- acid battery. Wear complete eye and clothing protection.

Keep fresh water and soap nearby in case battery acid contacts skin. Wash immediately with soap and

water if battery acid contacts skin or clothing. If acid should get into your eye, flush immediately with

cold water for 10 minutes, and get medical attention.

Never smoke while working with a lead-acid battery. Do not allow a spark or flame to get near battery.

Be careful to not drop any metal tool or object onto battery as sparking may occur. This may create an

explosion hazard.

A lead-acid battery can produce a short-circuit current strong enough to weld metal to skin. Remove all

jewelry and personal metal items when working with a lead-acid battery.

Do not use the portable power source to charge dry-cell batteries. These batteries may burst and cause

injury and damage to persons or property.

10. Do not attempt to charge or boost a frozen lead-acid battery.

www.aqtron.com - info@aqtron.com

BAT/44892

Table of Contents

Need help?

Do you have a question about the BAT/44892 and is the answer not in the manual?

Questions and answers

Summary of Contents for AQ-Tron BAT/44892

Page 1 The jump starters described in this manual are suitable for portable power source or off-road side battery emergency rescues. Ratings are described as below. BAT/44892 : 12/24V, 1700/3400A Caution : Contains sealed, non-spillable lead acid battery. Must be disposed of properly.
Page 2 PRODUCT MANUAL BAT/44892 11. Even though the portable power source is equipped with polarity warning, prevent clamps from touching each other or contact the same metal to prevent accidental arcing. 12. Use of an attachment not recommended or sold by the manufacturer, may result in a risk of damage to the unit, or personal injury.
Page 3 PRODUCT MANUAL BAT/44892 RECHARGING THE PORTABLE POWER SOURCE There are two ways to charge the portable power source. The first method is automatic charging with the provided switching charger (preferred). The second is with the DC power jack through the power extension cord.
Page 4 PRODUCT MANUAL BAT/44892 USE AS A JUMP STARTER IN EMERGENCIES For optimum performance, do not store below 50 F when using as a jump starter. The portable power source will only jump start a battery if there is more than 3 Vdc of power remaining in the battery. If the battery is below 3 Vdc, please refer to, “Operating Instructions: Use as a battery charger”...
Page 5 PRODUCT MANUAL BAT/44892 FREQUENTLY ASKED QUESTIONS Q: How many jump starts can I expect from a fully charged unit before needing to be recharged? A: Depending on the engine type and size, condition of battery, and temperature the portable power source normally can be used 20 times before recharging.
