Summary of Contents for Marecoluce Tetris Solar
- Page 1 Tetris Solar Tetris Solar Pag. 2 installation of the fitting Electronic circuit board Pag. 3 Cleaning the panel Pag. 5 Warnings and waste disposal Pag. 6...
- Page 2 TETRIS SOLAR Installation of the fitting Electronic circuit board pre-installed and factory set (for programming modes see pag.3-4) Pay attention: The respect of the abovementioned parameters is greatly influenced by the positioning of the fitting, the quantity and quality of the solar exposure, and the ambient temperature.
- Page 3 Electronic circuit board of Tetris Solar Max. module input short circuit current at 50°C Max. load output current at 50°C System voltage 12 V Ambient temperature -25°C / +50°C allowed Max. voltage of 47 V DC Solar panel Temperature compensation...
- Page 4 Electronic circuit board of Tetris Solar LED displays Status Meaning Illuminates green Normal operation system fault - too high charging current - overload / short circuit Info LED - overheated Flashes slowly red* together with red LED : - too low battery voltage...
- Page 5 Faults and remedies Tetris Solar No display : Check battery polarity and external fuse. Or battery voltage is too low or battery defective. Battery is not charged : Check if solar modul is connected with correct polarity or if short circuit at the solar input.
- Page 6 WARNINGS & WASTE DISPOSAL IT IS FORBIDDEN TO MODIFY THE FITTING WITHOUT AUTHORISATION • Any tampering of the luminaire will render the warrantee void, and may render the product dangerous. •The installation and programming of the product conducted by qualified personnel. •...
- Page 7 47032 Bertinoro (FC) Italia Via S.Croce, 121 (z.i) tel. +39 0543 4687 fax +39 0543 449051 info@marecoluce.it marecoluce.it...
