Summary of Contents for Advanced Screenworks Mystic Series
- Page 1 Tech Support Help Line: 678-926-9700 Send Tech Support Media to: 678-462-8928 ® INSTALLATION INSTRUCTIONS © Advanced Screenworks, LLC 2019...
-
Page 2: Important Safety Information
1. IMPORTANT SAFETY INFORMATION Read all instructions and the following safety information carefully prior to installation and use. Failure to do so may result in serious injury or death. Mystic Motorized Screens are heavy, require electric connection, and may be installed in applications that require professional skilled workers. - Page 3 5. PREPARATION OF JOB SITE, OPENING PACKAGES ********** DO NOT USE A KNIFE OR UNPROTECTED BLADE TO OPEN PACKAGES ********** Each Mystic unit comes packaged in two sturdy cardboard tubes with metal caps screwed on to the ends of the tubes. If you are not using saw horses, spread blankets on floor or lawn to protect the painted metal frames from scratches and the screen fabric from damage.
- Page 4 6. PREPARATION OF THE STRUCTURE: FLAT, LEVEL, PLUMB, AND SQUARE ***** THE UNIT WILL NOT OPERATE PROPERLY UNLESS IT IS FLAT, LEVEL, PLUMB, AND SQUARE ***** For Recessed Mount Applications, ensure that: (a) FLAT & LEVEL: a. The base surface of the header to which the canister back will be secured is flat and level;...
-
Page 5: Install The Outer Rails
8. INSTALL THE OUTER RAILS For Recessed Mount Applications: Place one outer rail directly under the edge of the canister and firmly along the side jamb of the structure. The face of the outer rail that is towards the back of the canister should be lined up with the back of the canister and run plumb vertically to the floor/base of the structure. - Page 6 10. INSTALL THE BOTTOM WEIGHT BAR ASSEMBLY NOTE: to perform the instruction in this section, you may need to adjust the temporary factory set limits on the motor by following the instructions found in the accompanying document entitled “Instructions for the Mystic Classic Remote and Motor” Using the UP button on the remote, raise the bottom zipper to a comfortable level so that you can slide the bottom weight bar on to the bottom zipper.
-
Page 7: Final Checks
13. SECURE SCREWS ATTACHING INNER SIDE RAIL TO OUTER SIDE RAIL ************* IMPORTANT: DO NOT USE POWER TOOLS IN THIS STEP. ************** Using a hand screwdriver, secure the inner rail to the outer rail using the screws supplied. These screws should not be tightened to the maximum. - Page 8 This page is intentionally blank. P a g e...
- Page 9 955 Patrick Industrial Ct Winder, GA 30680 Phone: 678-926-9700 Fax: 678-288-7924 INSTRUCTIONS FOR THE MYSTIC CLASSIC MOTORS & REMOTE IMPORTANT NOTES BEFORE YOU START: 1. THE MOTOR AND REMOTE ARE SYNCHRONIZED AND PRE-PROGRAMMED AT THE FACTORY. 2. PLEASE READ EACH INSTRUCTION CAREFULLY AND COMPLETELY BEFORE PERFORMING THE ACTIONS DESCRIBED IN THE INSTRUCTION.
- Page 10 A. THE MOTOR AND SIX CHANNEL REMOTE COMES FROM THE FACTORY WITH CHANNEL ONE SYNCHRONIZED. B. TEMPORARY UPPER AND LOWER LIMITS HAVE BEEN SET AT THE FACTORY. THE SCREEN PANEL IS ROLLED UP ON THE TUBE SO THAT WHEN YOU POSITION IT CORRECTLY IN THE HOOD WITH THE LIMIT ADJUSTMENT SWITCHES FACING FORWARD THE SCREEN PANEL WILL BE AT ITS UPPER LIMIT.
- Page 11 F. HOW TO: SET AND ADJUST UPPER AND LOWER LIMITS 1. ALWAYS SET THE LOWER LIMIT FIRST 2. USE THE DOWN ARROW ON THE REMOTE TO MOVE THE BOTTOM BAR DOWN. IF THE BOTTOM BAR DOES NOT STOP BEFORE 1’ FROM THE BOTTOM, PRESS THE STOP BUTTON TO STOP IT 1’ FROM THE BOTTOM.
- Page 12 5. NEXT, WE WILL SET THE UPPER LIMIT. USE THE UP ARROW ON THE REMOTE TO MOVE THE BOTTOM BAR UP. IF THE BOTTOM BAR DOES NOT STOP BEFORE 1’ FROM THE TOP, PRESS THE STOP BUTTON TO STOP IT 1’ FROM THE TOP. CAUTION#1: Do not allow the bottom bar to rise too far so as to run up into the hood.
- Page 13 G. HOW TO: SYNCHRONIZE A 2 REMOTE (EITHER A 2 HAND HELD OR WALL MOUNT) TO THE MOTOR: 1. PRESS AND HOLD THE STOP BUTTON ON THE PRIMARY HAND HELD REMOTE. THE MOTOR WILL JOG OR BEEP 5 TIMES. RELEASE THE STOP BUTTON. 2.
