Summary of Contents for Challenger EPS0412
- Page 1 ELECTRIC LIFTER TROLLEY INSTRUCTION MANUAL Imported exclusively by Pacific Hoists Pty. Ltd. & Pacific Hoists Ltd. In support of cancer charities in Australia & New Zealand...
- Page 2 www.jbstools.com WWW.CHALLENGERHOISTS.COM.AU...
-
Page 3: Specifications
Challenger brand directly supports cancer charities in Australia and New Zealand. It is important that this manual be kept in a safe place where any operator of the Challenger Electric Lifter Trolley can refer to it and understand the operating principles of this device. All users of this Challenger Electric Lifter Trolley should read this manual in full and understand the safe operating principles of the device. - Page 4 SPECIFICATIONS www.jbstools.com WWW.CHALLENGERHOISTS.COM.AU...
-
Page 5: General Precautions
GENERAL PRECAUTIONS The operator should read the instructions before using this electric lifter trolley to avoid any ■ injuries This electric lifter trolley is used to lift and lower loads within it’s rated capactiy ■ The electric lifter trolley should only be operated by persons who are authorised to do so ■... -
Page 6: Maintenance
MAINTENANCE REGULAR INSPECTION OF YOUR CHALLENGER ELECTRIC LIFTER TROLLEY WILL HAVE A TWOFOLD RESULT BY ENSURING THE UNIT IS SUITABLE FOR SAFE OPERATION AND WILL ASSIST WITH EXTENDING THE OPERATING LIFE OF THE UNIT. THE FOLLOWING INSPECTION SHOULD BE PERFORMED BOTH PRIOR TO, AND AFTER, EVERY USE: Check for any bending or cracking on the electric lifter trolley ■... -
Page 7: Charging The Battery
OPERATING INSTRUCTIONS To brake, press the brake pedal located on the left side of the swivel caster ■ To release the brake, lift the brake pedal ■ To lift the forks, turn the emergency stop button on the control panel clockwise and operate ■... -
Page 8: Control Panel
CONTROL PANEL Press the emergency button, to disconnect the power supply of the pump station motor ■ Turn the emergency button clockwise to connect the motor ■ When the voltmeter is below 10V, the storage battery must be charged ■ The up/ down buttons are used to raise or lower the forks ■... -
Page 9: Troubleshooting
TROUBLE SHOOTING Fault Cause Countermeasures The forks cannot • Low hydraulic oil level • Inject hydraulic oil reach the max. height The forks cannot be • No hydraulic oil • Check hydraulic oil raised • Hydraulic oil is impure • Replace the hydraulic oil Pump station motor •... -
Page 10: Spare Parts
SPARE PARTS Description Qty. Bracket Roller Composite sleeve Ultra big washer Full thread hexagon headed bolt M6X16 Tyne Long axis Spring washer for shaft www.jbstools.com... - Page 11 SPARE PARTS Description Qty. Handle Split washer Chain wheel Composite sleeve Chain wheel cap Chain wheel cap Chain wheel shaft Hexagon socket set screws with flat point Chain Chain joint Chain tie rod Hexagon nut Non-metal hexagon lock nut Full thread hexagon headed bolt Spring washer Hexagon nut Full thread hexagon headed bolt...
- Page 12 SPARE PARTS www.jbstools.com WWW.CHALLENGERHOISTS.COM.AU...
- Page 13 SPARE PARTS Description Qty. Electric appliance cap Cross recess head screw M6X16 Embedded nut Electric cabinet Charger 12V/10A Anchor ear Storage battery Fixture Hexagonal socket head cap screw Oil pump installation board Pump station Hexagon nut Spring washer Hexagonal socket head cap Cross recess head screw Hexagon nut Flat washer...
- Page 14 SPARE PARTS www.jbstools.com WWW.CHALLENGERHOISTS.COM.AU...
- Page 15 SPARE PARTS Description Qty. Start switch Motor O-ring Solenoid pilot actuated valve Clamp Stop valve Central valve body Screw Safety valve Flow control valve Fuel return tube Gear pump Fuel suction tube Carbon brush Filter Fuel tank...
- Page 16 SPARE PARTS www.jbstools.com WWW.CHALLENGERHOISTS.COM.AU...
- Page 17 SPARE PARTS Description Qty. Piston rod Steel wire washer for shaft Piston Spring washer for shaft Dustproof ring Y sealing ring for shaft End cover O-ring Oil tank body Composite gasket Oil release screw plug Composite gasket Long joint Safety valve Joint body Single 90°...
- Page 18 SPARE PARTS www.jbstools.com WWW.CHALLENGERHOISTS.COM.AU...
-
Page 19: Inspection Log
National Sales & Service P: 02 8825 6900 www.challengerhoists.com.au Thank you for choosing the Challenger brand. Not only are you choosing a quality and reliable brand but you are also helping to support cancer charities in Australia & New Zealand.
