  • Page 1 ENGLISH Wine dispenser User manual Winefit EVO...
  • Page 2 ENGLISH SAFETY REGULATIONS The machine can only be used correctly after having read this manual which also contains the basic safety rules set out below: SAFETY INFORMATION • This appliance is intended for use in domestic and similar applications such as: •...
  • Page 3 • The appliance must not be exposed to rain. • Keep the ventilation openings in the housing of the appliance or in the recessed structure free of obstructions. • NOTE: to obtain an electronic version of the user manual, please forward the request to the following address: Info@winefit.it...
  • Page 4 ENGLISH INTRODUCTORY GUIDE TO THE INSTALLATION OF THE APPLIANCE • To avoid hazards due to the instability of the appliance, this must be fixed according to the Instructions. • Leave sufficient space to install the appliance on a flat surface. •...
  • Page 5 ENGLISH • Do not place anything on top of the device. • The maximum opening of the doors is shown below in the following images never open more than specified: • Place the device taking into account the size of the doors opening...
  • Page 6 ENGLISH • The maximum opening of the front console is shown below in the following image never open more than specified: • For a correct levelling, position the device on a perfectly flat surface and adjust the feet, indicated in the following images, by screwing or loosening them until the stability is achieved.
  • Page 7 ENGLISH • When positioning the device, make sure that the power cord is not entangled. • Be careful not to crush or damage the power cord while positioning it, this may cause electrical shock or fire. • The device must be positioned in such a way as to make the power cord plug accessible.

  • Page 8: Table Of Contents

    GENERAL DESCRIPTION…………………………………………………………………………………………………………... 10 MAINCOMPONENTS (FIGURE1)…………………………………………………………………………………………………. 10 CAPACITIVE KEYBOARD(FIGURE2)……………………………………………………………………………………………. 11 NOTES BEFORE USE………………………………………………………………………………………………………………... 11 HOW TO PREPARE WINEFIT EVO………………………………………………………………………………………………… 12 HOW TO SWITCH ON THE APPLIANCE………………………………………………………………………………………….. 12 HOW TO INSERT THE CYLINDERS……………………………………………………………………………………………….. 14 HOW TO PREPARE THE CAP……………………………………………………………………………………………………… 15 HOW TO INSERT THE CORK INTO THE BOTTLE OF WINE………………………………………………………………….. 16 HOW TO REPLACE THE 17MM EXPANDABLE WITH A NEW ONE AND HOW TO PUT THE 19MM EXPANDABLE……………………………………………………………………………………………………………...
  • Page 9 ENGLISH FIG. 1 FIG. 2...

  • Page 10: Introduction

    ENGLISH INTRODUCTION Winefit EVO is a device that is used for the preservation of bottled wines, using an inert gas such as argon and an air-conditioned bottle housing. Whenever a bottle of wine is opened, the special cap is applied, which keeps it hermetically sealed. The bottle with the cap is inserted in one of the 4 available slots of the machine, the latter will keep it at the right temperature of preservation and will put it under pressure until the wine is low;...

  • Page 11: Capacitive Keyboard(Figure2)

    BUTTON FOR BOTTLE WASHING. NOTES BEFORE USE Before using Winefit EVO read the manual carefully and keep it in a safe place. Do not remove pages from the manual, do not write on the manual pages; Spaces for notes and notes are provided at the end of chapters.

  • Page 12: How To Prepare Winefit Evo

    ENGLISH HOW TO PREPARE WINEFIT EVO HOW TO SWITCH ON THE DEVICE ! Place Winefit EVO on a horizontal and stable plane. ! Plug the power cord into a local socket of the current with the same voltage as the WinefitEVO label.
  • Page 13 Figure. ! There is another switch behind the console, indicated by the arrow in the Figure. Once the Winefit EVO switch is pressed, it will light up. The Touch-screen display, after the screen with the logo, will display this screen:...

  • Page 14: How To Insert The Cylinders

    ENGLISH HOW TO INSERT THE CYLINDERS This appliance has been designed to use only one type of cylinder authorized by the WINEFIT ® Company. The use of any other cylinder makes the warranty void and compromises the general safety of the machine. The used cylinder can contain three types of pressurized gases for alimentary use according to the Need.

  • Page 15: How To Prepare The Cap

    ENGLISH HOW TO PREPARE THE CAP The cap is made up of 4 main components: the cap body, the suction pipe, the bottom filter and the steel spout. In order to use the cap correctly, the 4 components must be assembled together.

  • Page 16: How To Insert The Cork Into The Bottle Of Wine

    ENGLISH HOW TO INSERT THE SPECIAL CAP 2.0 INTO THE WINE BOTTLE Perform the following operations on a horizontal plane. Uncork the bottle using a corkscrew. ! Insert the special cap 2.0 into the newly opened bottle as shown in the figure on the left. ! Insert the cap cartridge (shown in the figure on the...
  • Page 17 ENGLISH HOW TO REPLACE THE 17mm EXPANDABLE WITH A NEW ONE AND HOW TO PLACE THE 19mm EXPANDABLE It is possible to replace the expandable gasket when it is worn or damaged following these simple operations: ! Rest the cap on a stable surface as shown in the figure and remove the suction filter.

  • Page 18: Expandable

    ENGLISH ! Turn the locking ring on the screwdriver while keeping the screwdriver pointed at the cap until it exits its seat. ! Turning the ring nut in the direction of the arrow in the figure will be easier to extract the expandable.
  • Page 19 ENGLISH ! Take the new expandable of 17mm and apply the two side washers of the same size as the images show. ! Insert the new expandable in the appropriate seat as shown in the Image. Remember to reassemble the suction tube with its filter and the operation is Completed.
  • Page 20 ENGLISH The cap comes with the expandable of 17mm gasket that can be used for most bottles of wine, but it is possible to replace it with a 19mm gasket needed for bottles with a larger diameter. To put the expandable from 19mm follow the following steps after removing the locking ring as described in the previous paragraph: ! Take the 19mm expandable and apply...

  • Page 21: Bottle Insertion

    ENGLISH BOTTLE INSERTION Once the previous operations have been performed correctly, Winefit EVO will present the screen as shown in the figure on the touch screen display. Summary of the wines Insert/change bottle Settings Washing dispensers Recharge prepaid card Operate as Follows: ! From this menu, pressing the "insert/replace bottle"...
  • Page 22 ENGLISH ! And then you will have this What did you insert? screen with three possible options, of which select the item "new bottle with other wine". Same bottle New bottle with same wine New bottle with other wine SAVE Select the vine you have entered: ! This will access the screen where the Wine 1-...

  • Page 23: How To Replace The Cylinders

    ENGLISH HOW TO REPLACE THE CYLINDERS This appliance has been designed to use only one type of cylinder authorized by WINEFIT ® Company. The use of any other cylinder makes the warranty void and compromises the general safety of the machine. The used cylinder can contain three types of pressurized gases for alimentary use according to the need.

  • Page 24: How To Use Winefit Evo

    ENGLISH PROCEDURE FOR USING WINEFIT EVO MAIN MENU After having done the procedures described above, turning on Winefit EVO will display the screen with the Logo: Then, on the display, the main menu will be displayed: Summary of the wines...

  • Page 25: Insert/Replace Bottle

    ENGLISH Inserting a bottle of wine in the first location (and so on), as explained in the preceding paragraphs, will display this screen: The value in millilitre present under each bottle, maintains the count of the volume of wine remaining according to each dispensed; also clicking above the bottle will open a card with the description of the wine.

  • Page 26: Settings

    ENGLISH SETTINGS Selecting the "Settings" item from the main menu will display this scrolling menu: Language Currency Date and time Cell temperature Measure unity Glass dose selection Use of the machine Password In the next paragraphs we will analyze one by Color layout one the various settings entries.

  • Page 27: Date And Time

    "saved settings" on the screen and then return to the settings menu. UNIT OF MEASURE On Winefit EVO you can select the unit of measure between milliliters (ml) and ounces (oz/fl); from the "settings" menu select "unit of measure" this screen will appear: Choose your measure...

  • Page 28: Using The Machine

    ENGLISH USING THE MACHINE With Winefit EVO you can make the payment with prepaid card (if the option is Available) or without, in the next paragraphs we will address both Cases. To set one mode or the other (if both are available) from the "settings" menu select "using the machine" this screen...

  • Page 29: Cell Temperature

    ENGLISH CELL TEMPERATURE Winefit EVO is designed to store the bottles located inside (or inside a cellar at controlled temperature, for optimum preservation), at a temperature ranging from 7 ° to 18 ° Celsius. You can change the temperature of the bottle compartment from the "settings" menu select "cell temperature"...

  • Page 30: Password

    The set number will be requested by the machine whenever you want to access the main menu. COLOUR MANAGEMENT Winefit EVO has LEDs for each bottle and in the Console. You can change the color of the leds, to your liking, from the menu "settings" select "color management" this screen will appear:...

  • Page 31: Washing Dispensers

    ENGLISH WASHING DISPENSERS Once all the wine in the bottle has been dispensed, it is necessary to wash the cork in order not to leave previous wine residues and to remove sediment that can damage the cork. Operate as follows: ! Selecting from the main menu Select the slot for cleaning: the item "washing dispensers"...
  • Page 32 ENGLISH ! Fill with clean and drinkable Fill in the bottle with hot water water half a bottle (or with distilled water) previously rinsed (as indicated in the display). Press the lower right arrow to Continue. NOTE: it is advisable to store the previously rinsed bottle for the next cap wash operations.

  • Page 33: Reload Prepaid Card (If Available)

    ENGLISH RESET, RELOAD AND READ PREPAID CARD FROM PC (usable with Windows operating system 10) To reset and recharge the card from the PC, proceed as follows: ! Open the "Winecard" program on your computer, this window will ! Take the NFC player and connect it to your computer via its USB Plug. ! If the player is correctly inserted and is recognized, in the Winecard window the symbol of the USB in the upper left will be activated:...
  • Page 34 ENGLISH ! Place the card on the NFC player as shown in the Figure: ! The reader will read the card and in the Winecard window, at the bottom left, the serial number of the card will appear intermittent: ! Now click on "Format card". ! If everything was done correctly the program window will mark "CREDIT 0.0000"...

  • Page 35: Credit Reading And Prepaid Card Recharge From The Machine (If Available)

    ENGLISH CREDIT READING AND PREPAID CARD RECHARGE FROM THE MACHINE To view the credit card, from the machine, proceed as Follows: ! Selecting from the main menu the item "prepaid card" will display this screen and will illuminate the NFC player of the console, marked with this symbol Display credit Recharge prepaid card...
  • Page 36 ENGLISH ! Select an amount and press save; The following screen will be displayed: Bring the prepaid card closer ! Place the prepaid card next to the reader and wait for a moment for the transaction to take place; at the end of the writing, the display will show the message "Reload performed"...

  • Page 37: Wine Delivery Menu

    ENGLISH WINE DELIVERY MENU If we have inserted at least one bottle of wine and pressing this symbol on the display from the main menu, you can access this screen: WINE POSITION 1 Nation Vintage SELECT With the arrows you can scroll from station to station, the symbol at the top indicates which of them we are in;...
  • Page 38 ENGLISH ! The screen shown in the figure Bring the prepaid closer to pay will appear, warning you that it is now possible to make the payment by placing the card next to the NFC reader within one minute of time (do not pass the card quickly to allow a correct reading).
  • Page 39 ENGLISH If the button on the console, corresponding to the chosen dose, has been pressed within Wine delivery processing… the available minute, we will be in front of the screen as shown in the figure, which shows us at what point the dispensing is.. ! Once the glass has been Wine delivery dispensed, the display will show...

  • Page 40: Notifications

    ENGLISH NOTIFICATIONS (Alerts) The notifications are shown on the top right of the display with this symbol , which shows the number of messages to be viewed; touching the symbol you access a scrolling menu which shows the list of messages. The notifications are activated for the following reasons ! The absence of one or both cylinders will trigger the notifications: "cylinder 1: no cylinder inserted"...

  • Page 41: Washing Of Drip Tray

    ENGLISH WASHING OF DRIP TRAY Whenever the drip tray becomes dirty, we recommend washing it as follows: ! Press on the glass of the pan (in the Middle) and extract it as shown in the Figures: ! Rotate the tray and the grill slightly outwards and remove them from their seats (as shown in the figures), taking care not to spill the wine collected inside.
  • Page 42 ENGLISH Winefit srl Headquarter: Via Kennedy 14/A - 50026 San Casciano V.P. - Firenze - Italia Tel. 055 0988077 - Fax 055 0988076 www.winefit.com - info@winefit.com...
