NeuLog wide range temperature logger sensor NUL-233
The NeuLog wide range temperature sensor can be used for any science experiment
which requires accurate temperature measurements such as in the fields of Physics,
Chemistry, Biology, Environmental Science, etc.
The sensor comes pre-calibrated so you can start experimentation right out of the box
using this guide.
Using the wide range temperature sensor over other temperature sensors has its
advantages:

The sensor can accurately measure between -200°C and 1200°C – so it can be
used in a direct flame.

It is extremely durable with a mesh metal wire coating.
Among hundreds of possible experimental subjects that can be studied with the
NUL-233 sensor are: exothermic and endothermic chemical reactions, heat of
combustion for different materials, metabolism, heat and energy transfer, effects of
heat on enzyme function, weather studies, material thermal conductance properties,
and many more.
This sensor is capable of measuring both in Celsius and Fahrenheit.
Celsius: The SI (International System of Units) unit of temperature.
Fahrenheit: The temperature measurement unit of the English System commonly used
in the United States.
Quick start procedure:
PC or Mac Computer
Materials needed:

NUL-233 Wide Range Temperature Sensor

USB-200 USB Module

USB to mini USB cable (included with the USB-200 module)
Your wide range temperature sensor needs to be connected to a USB-200 module.
The USB-200 module then connects to a computer via a USB to mini-USB cable.
NEULOG WIDE RANGE TEMPERATURE LOGGER SENSOR GUIDE
Please note that you cannot plug the wide range temperature sensor directly into the
computer.
The browser based application can be downloaded for free at
well as a full application user guide.
Choose "Downloads" on the main menu and then choose "Software and Application".
Procedure:
1. Install the NeuLog application.
2. Connect the USB-200 module to the PC or Mac.
3. Connect the wide range temperature sensor to the USB-200 module (they
directly plug together). Please note that there is no calibration required for this
sensor.
4. Open the NeuLog application by clicking on the shortcut on the screen.
5. Once the wide range temperature sensor module box appears on the left side of
the screen the probe has been automatically identified and you can begin
experimentation.
6. If the wide range temperature sensor is not automatically identified, click the
"Search for sensors" icon to find the sensor.
Click on the "On-line experiment" icon; this will open a graph below.
7.
Click on the "Module setup" button located in the wide range temperature sensor
8.
module box to change the sensor's settings if need be.
9. Click on the "Experiment set up" icon to change the experiment settings if need
be (experiment duration for example).
10. The wide range temperature sensor will give a live reading in its module box to
the left of the screen while plugged in.
To run an experiment and collect data click the "Run experiment" icon.
11.
To end data collection early, click the "Stop experiment" icon.
12.
Tablet, smart phone device
Materials needed:

NUL-233 Wide Range Temperature Sensor

WIFI-201 WiFi Module

BAT-200 Battery Module
Your wide range temperature sensor needs to be connected to a WIFI-201 module.
The WIFI-201 module will create a closed NeuLog WiFi network which will stream the
NeuLog data to a device of your choosing. Once your device is wirelessly connected
to the NeuLog network, you can run experiments and collect data through a browser
of your choosing.
www.NeuLog.com as
