Summary of Contents for IINNO Energy Storion SMILE5
- Page 1 Storion SMILE5 User Manual V1.1...
-
Page 2: Table Of Contents
Copyright Statement This manual is under the copyright of IINNO Energy Ltd., with all rights reserved. Please keep the manual properly and operate in strict accordance with all safety and operating instructions in this manual. Please do not operate the system without reading through the manual. -
Page 3: General Introduction
1. General Introduction 1.1 Functions Storion Smile5 is a new energy storage system specifically developed for grid applications by IINNO Energy. It can be applied in DC-coupled systems (mostly new installation), AC-coupled systems (mostly retrofit) and Hybrid-coupled systems (mostly retrofit, and PV capacity-increase), as following scheme: Pic 1. -
Page 4: System Introduction
3. System Introduction 3.1 System components Pic 2. Storion-Smile5 Delivery Scope Item Components Hybrid Inverter Display Cable Box Smile5-BAT battery 1 Smile5-BAT battery 2 4. Operation- Switch On/Off 4.1 Switch On System shall be turned on in the correct sequence to avoid any damage. - 02 - Step 1, Open cable box outer shell. -
Page 5: Switch Off
Step 3, turn on the PV switch on the cable box. Step 4, Turn on the GRID switch. Step 5, If backup load is applied, connect it to Back up ports and turn on the Back up switch; if not, then keep the Back up switch off. Note: The Backup switch is only used when a backup load is pplied. -
Page 6: Main
Name Description Object Green: The inverter is in normal state. Indicator Blue: The battery is in charging or discharging. Yellow: The inverter is in communication. Red: The inverter is in fault. Down button: Move cursor to downside or decrease value. Function Return button: Escape from current interface or function. -
Page 7: History
Solar interface displays the real-time information of PV > > > > > Solar < < < < < side: voltage U1, 360.0V current I1, power P1, voltage U2, current I2 and power P2. 1.0A 360W Solar Interface Battery interface displays the real-time information of >... -
Page 8: Emergency Situations
5. Emergency Situations Storion-SMILE5 comprises multiple batteries that are designed to prevent hazards resulting from failures. However, IINNO Energy cannot guarantee their absolute safety. Fire In case of fires, make sure that the following equipment is available near the system. -
Page 9: Online Monitoring
More detailed information can be obtained in Online Monitoring Webserver User Manual. 7. Warranty 7.1 Warranty Products that are operated strictly in accordance with the user manual and the IINNO Energy Installation Manual are covered by the warranty. Any violation of this manual may void the warranty. 7.2 Limitation of Liability Any product damage or property loss caused by the following conditions IINNO Energy does not assume any direct or indirect liability. - Page 10 IINNO Energy Ltd. +372 712 3010 sales@iinno-energy.com www.iinno-energy.com Tammsaare tee 47, Tallinn 11316, Estonia...
