Device Description
Multi radio connection MFA
Radio converter for the integration of line-dependent
continuous small servo drives in wireless
transferable signal chains. With integrated switching
power supply.
Kieback & Peter GmbH & Co KG
Tempelhofer Weg 50, D-12347 Berlin
Telephone +49 (0) 30 / 600 95-0
Telefax +49 (0) 30 / 600 95 164
E-Mail: info@kieback-peter.de
http://www.kieback-peter.de
Technical data sheet 1.15-10.002-01-en
Multi radio connection MFA
Page
2
Page
2
Page
2
Page
3
Page
3
Page
3
Page
4
Page
6
Page
6
Page
6
Page
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Multi radio connection MFA and is the answer not in the manual?

Questions and answers

Summary of Contents for Kieback&Peter Multi radio connection MFA

  • Page 1 Technical data sheet 1.15-10.002-01-en Device Description Multi radio connection MFA Multi radio connection MFA Radio converter for the integration of line-dependent continuous small servo drives in wireless transferable signal chains. With integrated switching power supply. Contents Page Notes on the device description...

  • Page 2: Safety Instructions

    Technical data sheet 1.15-10.002-01-en Multi radio connection MFA Device Description Notes on the device description The description contains instructions on using and assembling the Multi Radio Controller MFA. In case of questions which cannot be clarified with this device description, please refer to the supplier or manufacturer for further information.

  • Page 3: Application

    Technical data sheet 1.15-10.002-01-en Device Description Multi radio connection MFA Application The Multi-Radio Connection MFA provides the indirect activation of wireless control of conventional, mains-driven continuous small servo drives. Within the signal chain the MFA works as a radio converter.

  • Page 4: Assembly

    Technical data sheet 1.15-10.002-01-en Multi radio connection MFA Device Description Assembly General installation notes Devices communicating via radio can not always be assembled at arbitrary locations, as wireless data transmission is more or less strongly influenced by the constructional and spatial conditions.
  • Page 5 Technical data sheet 1.15-10.002-01-en Device Description Multi radio connection MFA The Room Module can be mounted in the wall or in a flush-mounted box. For connection, the room temperature probe has perforated bases and hood parts which can be broken off depending on the cable entry.

  • Page 6: Installation

    Technical data sheet 1.15-10.002-01-en Multi radio connection MFA Device Description Installation Warning supply voltage 230 V for MFA multi-radio connection! Electrical installation of the device connection may only be performed by qualified expert personnel (e.g. electricians)! Danger In this context, the regulations of the VDE (Association of German Electrotechnical Engineers) as well as the local regulations are to be observed.
  • Page 7 Technical data sheet 1.15-10.002-01-en Device Description Multi radio connection MFA On principle, a Radio Control Transmitting Module FCS can be effective on more than one wirelessly driven field device. Line- dependent signals (up to 8 signal chains) 0..10 V Adr.01-0...

  • Page 8: Initial Operation

    Technical data sheet 1.15-10.002-01-en Multi radio connection MFA Device Description Initial operation LED displays Function MFA receives no radio telegrams green short blinking passive operating mode; module receives radio telegrams of other transmission paths green long blinking active service mode; module receives radio telegrams of the...
