Summary of Contents for Blossom Smart Watering Controller

  • Page 1 Quick Start Guide...
  • Page 3 hello. welcome to smart watering.
  • Page 4 Introduction...
  • Page 5 myblossom.com i’m your yard’s new brain. let’s get started.
  • Page 6 Contents what’s in the box. Blossom Controller Blossom Bracket Four Wall Screws Ethernet Cord Blossom Bridge What you will need: • iOS or Android Device • Internet Router and Service...
  • Page 7 myblossom.com...
  • Page 8 Quick Start Guide connect the ethernet cable. First things irst. Connect one end of the provided Ethernet cable into the Blossom Bridge. Connect the other end of the Ethernet cable into an open port on your router.
  • Page 9 myblossom.com...
  • Page 10 Quick Start Guide plug in the Blossom Bridge. Power up by plugging the Blossom Bridge into an electrical outlet near your internet router. Note: Make sure the Bridge is plugged in directly into a power socket. Avoid any power protection strip. You should...
  • Page 11 myblossom.com...
  • Page 12 Quick Start Guide label and disconnect wires from your old controller. It is important that you keep track of your wiring for your common wire. We provide you a black label for it. If you have a pump relay wire, use the gray label for it.
  • Page 13 myblossom.com...
  • Page 14 Quick Start Guide remove the old controller. Out with the old, make way for the new. Dismount your old watering controller from the wall.
  • Page 15 myblossom.com...
  • Page 16 Quick Start Guide install the Blossom Bracket. Mount the Blossom Bracket directly on the wall with the four provided screws.
  • Page 17 myblossom.com...
  • Page 18 Wire it up. Locate the opening in the base of the Blossom Bracket. Connect the labeled wires to their corresponding colored ports. If you have a pump, use the far right gray port. Note: Discard your existing weather sensors.
  • Page 19 myblossom.com...
  • Page 20 Look for the 6-digit pairing code between the Bracket and the Controller, on the back of the Controller and secure it to the Blossom Bracket on the wall. Quick Tip: Snap a photo or write down the 6-digit pairing code for future reference.
  • Page 21 myblossom.com...
  • Page 22 Quick Start Guide plug in the Blossom Controller. Let there be power. Plug the Blossom Controller’s power cord into an available electrical outlet.
  • Page 23 myblossom.com...
  • Page 24 Quick Start Guide get the Blossom Mobile App. Download the Blossom app on the Apple App Store, Google Play Store or visit myblossom.com. The app will guide you through creating your account, syncing your device and connecting your Blossom to the Internet.
  • Page 25 myblossom.com...
  • Page 26 Quick Start Guide create a Blossom account We only need your email and a password.
  • Page 27 myblossom.com...
  • Page 28 Quick Start Guide check your email As soon as you verify your email, you will be able to continue.
  • Page 29 myblossom.com...
  • Page 30 Quick Start Guide let Blossom know your address For a better weather and forecast intelligence, let Blossom know your location.
  • Page 31 myblossom.com...
  • Page 32 Quick Start Guide check the status light This is important, in order to successfully continue, we need a Pulsating Green light.
  • Page 33 Pulsating Green The Blossom Controller is online and ready to be paired. Solid Green It seems that the Blossom Controller is having diiculty communicating through the Blossom Bridge right now. Please try these tips. No luck? tap on Solid Green and jump to “How to pair the...
  • Page 34 Quick Start Guide activate your Blossom Controller Use the pairing code you have or look for the 6-digit pairing code between the Bracket and the Controller, on the back of the Controller. Should look like this:...
  • Page 35 myblossom.com...
  • Page 36 Quick Start Guide set up your zones Blossom will locate all the zones you have. Name them and conigure them as you please.
  • Page 37 myblossom.com...
  • Page 38 Quick Start Guide you are done! Say hi to your new Smart Watering Controller :)
  • Page 39 myblossom.com...
  • Page 40 Quick Start Guide how to run your sprinklers manually Select the zones you want to water and set the duration for each zone.
  • Page 41 myblossom.com...
  • Page 42 Quick Start Guide schedule Control the watering of your plants by week or month.
  • Page 43 myblossom.com...
  • Page 44 Quick Start Guide tips to getting your Controller & Bridge talking. Try the next tips, to help your Controller communicate with the Bridge.
  • Page 45 See that the connection light is illuminated on the bridge; check your router that its connection light is on. Unplug your Blossom Controller. Wait 30 seconds, then try again. Sometimes a Blossom Controller needs to update its software. If the controller does not immediately switch to blinking green, consider letting it sit for 5 minutes or so, then unplug and try again.
  • Page 46 Quick Start Guide how to pair the Blossom Controller with WiFi Your phone will help the Blossom Controller to connect to your home network: Start by temporarily disconnect your phone from your home network, and connect to a network called: Blossom-XXXX, using the password: “12lowers“*...
  • Page 47 myblossom.com...
  • Page 48 Blossom Controller with WiFi Go back to the Blossom App, and select the network to which your Blossom Controller should connect. Once you are done, don’t forget to put your phone back to its original WiFi...
  • Page 49 myblossom.com...
  • Page 50 Quick Start Guide how to pair the Blossom Controller with WiFi Once your Blossom Controller is connected, use the paring code to activate your Controller. Look for the 6-digit pairing code between the Bracket and the Controller, on the back of the Controller. Should look like...
  • Page 51 myblossom.com Go Back...
  • Page 52 Quick Start Guide color guide The Blossom Controller will let you know its status, just check the Status Light on it.
  • Page 53 When you see one of these colors on the status lights, the Blossom Controller is... Pulsating Green Solid Blue ready for use... waiting to be paired. Solid Green Pulsating Blue waiting for Internet or watering. Powerline. Pulsating Purple Pulsating Yellow...
  • Page 54 Smart Irrigation Controller and System Limited Warranty iConservo, Incorporated’s Limited Warranty IMPORTANT INFORMATION ABOUT YOUR RIGHTS AND OBLIGATIONS, AS WELL AS LIMITATIONS AND EXCLUSIONS THAT MAY APPLY TO YOU. YOUR RIGHTS AND THIS LIMITED WARRANTY This Limited Warranty gives you speciic legal rights. You may also have other legal rights that vary by state, province or jurisdiction.
  • Page 55 DISCLAIMER OF WARRANTIES EXCEPT AS STATED ABOVE IN THIS LIMITED WARRANTY, AND TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, iCONSERVO, INC. DISCLAIMS ALL EXPRESS, IMPLIED, AND STATUTORY WARRANTIES AND CONDITIONS WITH RESPECT TO THE PRODUCT AND ITS COMPONENTS, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY, NON- INFRINGEMENT OF INTELLECTUAL PROPERTY AND FITNESS FOR A PARTICULAR PURPOSE.
  • Page 56 Apple Inc., registered in the U.S. and other Countries. Android is trademark of Google Inc., registered in the U.S. and other Countries. ©2014 Blossom. All rights reserved. Blossom and the Blossom Logo are registered trademarks of Blossom in the U.S. and other Countries.
