Clearblue CONNECTED Quick Start Manual

CONNECTED
Ovulation Test System
Read this leaflet carefully before testing
1
How to use the Clearblue® Connected app
Search for the Clearblue® Connected app and
download from your app store.
App is suitable for iPhone® or Android™
• Open the app on your phone and create your Clearblue® account.
• To finalize creating your account you'll need to click on the link sent to you by
email. Once you've done this, connect your holder following the instructions on the
app. You'll need the wake-up stick to do this.
• Once your holder is connected press the eject button to remove the wake-up stick.
• Keep the wake-up stick as you will need this again to activate Bluetooth® on
your holder.
Wake-up stick:
• The Clearblue® Connected app will tell you when to test, display your synced results
and let you record details about your period and when you had sex.
• It will also track and compare your cycles and can advise you when to test for
pregnancy.
Questions and Answers about the app
I can't connect my holder to the app. What should I do?
Check that Bluetooth® on your phone is turned on. Insert the wake-up stick and wait for
flashing symbols to appear on the holder display. If no symbols appear there is a
problem with the holder. Please call the Clearblue® Helpline. You can still test using this
holder but you'll be unable to sync results to the app.
Do I need my phone to test?
No. Test normally following the instructions from step 3. The holder will display a
flashing asterisk to show data is available to sync. When Bluetooth® on your holder and
phone is turned on, the result will sync. To turn on Bluetooth® on your holder insert the
wake up stick and wait for the Bluetooth® symbol to appear.
My result hasn't been synced to the app and it's no longer on the holder display.
What should I do?
If your test stick is still inserted into the holder eject it and the result will re-appear on
the display. While it is displayed, Bluetooth® will be activated and your result will sync to
the app if your phone has Bluetooth® turned on.
If you have ejected the test stick and the result is no longer displayed you need to insert
the wake-up stick to activate Bluetooth®. Your result will then be synced to the app if
your phone has Bluetooth® turned on. Eject the wake-up stick once your result has
been synced.
Where is my information stored?
Synced results and information you have entered on the app are stored on your phone.
When you are connected to the internet all your information is also transferred to your
personal account. This is a secure and confidential area so it's a good idea to keep your
personal account updated in case you lose or change your phone. You can check when
this was last done by going to Menu > My holder.
How does the app know the day my period is due?
The app will estimate when your period is due based on the information you have
provided on your cycle length and last period.
Can I connect more than one holder?
No, you can only connect one holder to the app at a time. Please check that you have
synced all your results before connecting a new holder. To connect a new holder go to
Menu > My holder.
When you connect a new holder your old holder will automatically disconnect and you
cannot reconnect it.
What happens if I travel outside my normal time zone?
If the time on your phone is changed to local time you may find the app requests you
test twice in 24 hours or you may miss a test depending on the time difference.
What if I change my phone?
Download the Clearblue® Connected app to your new phone and sign in with your
email and password to access your data. Your holder will continue to sync results to
your new phone.
English
2
Important points you need to read before testing
1. Peak Fertility is displayed constantly for 48 hours after it first appears. The holder will
not be able to read another test while this is displayed.
2. Every woman's cycles are unique and hormone patterns differ so the number of
fertile days you see is personal to you. In a study of 87 women, this is what we saw:
Number of High Fertility days before Peak Fertility
0-4
5-9
10+
No Peak Fertility after High Fertility
TOTAL
3
How to take a test
Determine when to start testing
• Use the table below to determine when to start testing.
• The day your period starts (first day of full bleeding) is Day 1. Your cycle length is
the total number of days from Day 1 up to and including the day before your next
period starts.
• If your cycle length varies use the shortest cycle over the last 6 to determine when
to start testing.
How long is your cycle (days)?
Start testing on the day shown
under your cycle length.
Test stick and holder:
4
Insert the test stick into the holder
a) When you are ready to test, take a test stick out of the foil and take off the cap.
b) Put the test stick into the holder making sure the arrows line up as shown.
correct
c) The first time you use the test the new cycle symbols will flash briefly.
During first use
symbols flash briefly
d) The 'test ready' symbol will then appear. Take the test straight away. If this symbol
does not appear or the screen goes blank eject the test stick and put it back into
the holder.
If symbol does not appear,
eject and re-insert
5
Take the test
a) Either...
put just the absorbent tip
pointing downwards into
3
your urine stream for
seconds 3 seconds. Take care
not to get the holder wet.
Or...
collect a sample of your
urine in a clean, dry
15
container and put just the
absorbent tip into the
seconds
sample for 15 seconds.
b) Replace the cap and wipe off any excess urine.
Keep the absorbent tip pointing down or lying flat.
% of women
66%
25%
1%
8%
100%
21 or less 22 23 24 25 26 27 28 29
5 6 6 6 7 7 7 8 9
Test stick
Cap Absorbent tip
Remove
"click"
incorrect incorrect
Remember to
insert the test
stick into the
holder before
you take the test
Remember to
keep the
absorbent tip
pointing
downwards
while testing
3. If you started testing on the right day and you see more than 9 High Fertility days you
may wish to stop testing as it's unlikely that you will see Peak Fertility this cycle. See
Q4.
4. Only test once a day until you see High Fertility. For reliable results you must use the
first urine after your longest sleep. When you see High Fertility you can test more
often. Drink normally and it's important not to urinate for 4 hours before testing again.
5. If you remove the battery from the holder you will not be able to use it again.
• If you don't know how long your cycle is, we recommend you wait at least one cycle
and note the length of it so you know when to start testing. If you don't want to wait
you can use the default cycle length of 28 days. You can select this on the app.
• It's important to start testing on the day shown in the table, for example if your cycle
lasts 27 days start testing on day 7.
• Always test using the first urine after your longest sleep.
30 31 32 33 34 35 36 37 38 39 40
10 11 12 13 14 15 16 17 18 19 20
Holder
Eject button Display screen
6
Wait for your result
Within 1 minute the test ready symbol
will flash to show the test is working.
1 5
After 5 minutes the display will show
minute minutes
your result.
Do not eject the test stick yet.
7
Read your result
Your most fertile time
(flashing
smiley face)
Low Fertility: small High Fertility: increased
chance of getting chance of getting
pregnant Having sex pregnant Have sex to
today is just for fun as increase your chances of
it's unlikely that you will getting pregnant. A rise
get pregnant. Test again in estrogen has been
tomorrow. detected. High Fertility
will be displayed until
your LH surge is detected
(Peak Fertility).
How long it will be displayed
Low and High Fertility results are displayed for
8 minutes. If you miss seeing your result, eject the
test stick and it will re-appear for another 2 minutes.
If no result is displayed see 'Holder symbols - error and other symbols'.
8
Check Bluetooth® on your phone is turned on
Your result will be synced automatically with the app providing Bluetooth® on your
phone is turned on. As soon as the result is synced the Bluetooth® and asterisk
symbol will no longer be displayed on the holder.
9
When you've finished with the test
Press the eject button to remove your test stick as soon as possible after you have seen
the result on your holder. Throw away the test stick in your normal household waste.
10
Doing your next test
Follow the instructions from step 4 using a new test stick.
41 or more
20 days before you
expect your next period
(non-flashing
smiley face)
Peak Fertility: highest
chance of getting
pregnant Have sex to
maximize your chances of
getting pregnant. Your
LH surge has been
detected - today and
tomorrow are your most
fertile days. Once the first
day of Peak Fertility is
displayed don't try to test
again this cycle.
Peak fertility is displayed
constantly for 48 hours.
