- Page 1 User Manual Relay C 3PH from 60A to 210A Rev. 01/2019 PMA-C3-60-210A www.west-cs.co.uk...
- Page 2 A publication of: Prozeß- und Maschinen-Automation GmbH P.O.Box 310 229 • D-34058 Kassel • Germany All rights reserved. No part of this document may be reproduced or published in any form or by any means without prior written permission from the copyright owner. Liability and warranty Any information and notes in these operating instructions were composed under consideration of the applicable regulations, the present state of the art and our extensive know-how and experience.
-
Page 3: Table Of Contents
Contents 1. Important warnings for safety ..........................5 2. Maintenance ................................10 3. Introduction ................................11 A thyristor unit is semiconductor device which acts as a switch formed by two thyristors in ant parallel..11 3.1. Advantages compared with analog thyristor unit ................... 11 3.2. - Page 4 13.5.5 To log in on the test view to change the digital input and analog input functions: ..........43 13.5.6 To log out the test view: ............................ 43 13.5.7 To view data on the scope: ..........................44 13.5.8 To reset the power totals: ..........................44 13.5.9 Setting Up and Using Data Logging .........................
-
Page 5: Important Warnings For Safety
1. Important warnings for safety This chapter contains important information for the safety. The not observance of these instructions may result in serious personal injury or death and can cause serious damages to the Thyristor unit and to the components system included. - Page 6 A “NOTE” marks a short message to alert you to an important detail. A “CAUTION” safety alert appears with information that is important for protecting your equipment and performance. Be especially careful to read and follow all cautions that apply to your application. A “WARNING”...
- Page 7 CAUTION: To avoid compromising the insulation, do not bend wire or other components beyond their bend radius specifications. CAUTION: Protect the power controller from high temperature, humidity and vibrations. CAUTION: The power controller warranty is void if the tested and approved fuses are not used. CAUTION: Only trained and authorized personnel should access and handle the internal electronics and they must follow proper electro-static prevention procedures.
-
Page 8: Maintenance
2. Maintenance In order to have a corrected cooling, the user must clean the heat-sink and the protective grill of the fans. The fre- quency of this servicing depends on environmental pollution. Also check periodically if the screw for the power cables and safety earth are tightened correctly (See Connection Diagram). -
Page 9: Introduction
3. Introduction A thyristor unit is semiconductor device which acts as a switch formed by two thyristors in ant parallel. To switch on the alternating current the input signal will be on and the thyristor will switch off at first Zero Crossing voltage with no input signal. -
Page 10: Overview
3.2. Overview Heater bakeout • Protects heater upon start up • Eliminates labour and time associated with checking for wet heaters Integrated semiconductor fusing, current transformer and user interface • Saves installation time and eases setup and commissioning • Delivers a user-friendly, intuitive interface Industry-leading design and serviceability •... -
Page 11: Software Configurator
4. Software Configurator Thyristor configurator software is free and is Thyristor configurator software is free and is possible download it from our site. If the Order Code is in line with requirement, then unit has been already configured in Factory and it’s ready to use. You need the software only to modify the ordered configuration. -
Page 12: Quick Start
5. Quick Start Attention: this procedure must be carried out by skilled people only. If your Relay C code is in line with what you really need, then the main configuration is already done by Producer and you just need to do the following steps: 1. -
Page 13: Basic Connections And Sizing
6. Basic Connections and sizing Star wiring with resistive load (control on two phases with PMA-Relay C-3PH) 1,73V V = Nominal voltage of the load I = Nominal current of the load P = Nominal power of the load Delta wiring with resistive load (control on two phases with PMA-Relay C-3PH) 1,73V V = Nominal voltage of the load I = Nominal current of the load... -
Page 14: Identification
7. Identification 7.1. Identification of the unit Caution: Before to install, make sure that the Thyristor unit have not damages. If the product has a fault, please contact the dealer from which you purchased the product. The identification’s label gives all the information regarding the factory settings of the Thyristor unit, this label is on the unit, like represented in figure. -
Page 15: Order Code
8. Order Code Current - Fuses 60 A - Fixed Fuses Included 90 A - Fixed Fuses Included 120 A - Fixed Fuses Included 150 A - Fixed Fuses Included 180 A - Fixed Fuses Included 210 A - Fixed Fuses Included MAX VOLTAGE MAIN SUPPLY VOLTAGE 1* 480 V 600 V... -
Page 16: Notes On The Options
Current Limit + Datalogger Current Limit + Datalogger + Energy totalizer Current Limit + Heaterbreak Alarm (HB) Current Limit + Heaterbreak Alarm (HB) + Energy totalizer Current Limit + Heaterbreak Alarm (HB) + Datalogger Current Limit + Heaterbreak Alarm (HB) + Datalogger + Energy totalizer FAN VOLTAGE No fan <... -
Page 17: Technical Specifications
9. Technical specifications 9.1. General features Cover and Socket PolymericV2 material Utilization Category AC-51 AC-55b IP Code Method of Connecting Load in Delta, Load in Star Auxiliary voltage Order Code RC3_ _ _-_1 = line voltage 100/120V voltage range 90:135V (8 VA Max) Order Code RC3_ _ _-_2 = line voltage 200/208/220/230/240V voltage range 180:265V (8 VA Max) Order Code RC3_ _ _-_3 = line voltage 277 voltage range 238:330V (8 VA Max) -
Page 18: Environmental Installation Conditions
9.5. Environmental installation conditions Ambient temperature 0-40°C (32-104°F) at nominal current. Over 40°C-104°F use the derating curve. Storage temperature -25°C to 70°C -13°F to 158°F Installation place Don’t install at direct sun light, where there are conductive dust, corrosive gas, vibration or water and also in salty environmental. -
Page 19: Installation
10. Installation AIR FLOW OUT (V) Before to install, make sure that the Thyristor unit have not damages. If the product has a fault, please contact the dealer from which you purchased the product. Verify that the product is the same thing as in aspiration ordered. -
Page 20: Dimensions And Weight
10.1. Dimensions and weight Type Weight 3PH 60A no Fan 279 mm 269 mm 170 mm 10.2 kg 3PH 90-210A with Fan 279 mm 273 mm 170 mm 10.6 kg 10.2. Fixing holes 129,5 129,5 3PH (60A no Fan): 3PH (90-210A with Fan): 260 www.west-cs.co.uk... -
Page 21: Wiring Instructions
11. Wiring instructions The Thyristor unit could be susceptible to interferences lost by near equipments or by the power supply, for this reason in accord to the fundamental practices rules is opportune take some precautions: • The coil contactor, the relays and other inductive loads must be equipped with opportune RC filter. •... -
Page 22: Control Terminals
11.3. Control Terminals Warning: Before connecting or disconnecting the unit check that power and control cables are isolated from voltage sources. 11.3.1. Terminal block M1 Terminal Description 0V GND COM I - Common Digital Input DI 2 – Enable Digital Input DI 1 - Configurable Input + Analog Input1 (0-10Vdc/4-20mA Analog Setpoint) - Analog Input1 (0-10Vdc/4-20mA Analog Setpoint) -
Page 23: Schematic
11.4. Schematic Option Second Ethernet Profibus Serial RS485 Branch Circuit Protection +24V MICRO USB 2.0 Function Thermal SC/HB Analog Inp.1 Analog Inp.2 Analog SetPoint Reference Ext.FeeDBack NOTE: *1 The user installation must be protecting by electromagnetic circuit breaker or by fuse isolator. The Fuse must be branch circuit protection. -
Page 24: Ssr Control Input Schematic
11.4.1 SSR Control Input Schematic For SSR input follow the schematic below and configure Digital Input 1 as Fast enable. Analog Input 1 www.west-cs.co.uk... -
Page 25: Connection Diagram For 3 Phases
11.5 Connection Diagram for 3 phases Caution: this procedure must be performed only by qualified persons. 131415 16 Analog Inp.1 0-10VDC /4-20mA ANALOG SET POINT Analog Inp.2 0-10VDC /4-20mA SLAVE OUT Reference Ext.FeeDBack RETRANS. OUT Relay Thermal or SC/HB Fan Supply (only from 90 to 210A) See order code for the Value Note: Aux Voltage and Load... -
Page 26: Control Panel
12. Control Panel The Control Panel is placed on the front of the thyristor unit, on his display you can visualize the alarms, the input and output signals and all the configuration parameters. Relay C Relay C Relay C Relay C Iout0.0A Iout0.0A Aux High... -
Page 27: Menu Navigation
12.1. Menu navigation The menus are accessible using the control panel keypad and display. Choose Enter Choose Edit HOME PAGE Menu Password Parameter Parameter Relay C Relay C Relay C Relay C Iout0.0A Password Set Point Iout0.0A 100% SP 100% Iout0.0A Set Point Menu... -
Page 28: Control Panel Led
12.2. Control Panel Led The four indicators on the control panel show the general state of the power controller. 1 Local/Remote Flashing Power output set locally or via Relay C communications Aux High Power output set remotely (via SP 100% analog input) 2 Enable Output enabled... -
Page 29: Parameter List
12.4. Parameter list This chapter describes the parameter on the menus accessed via the control panel and Configurator software. To learn how to access the menus described below see “Menu navigation” chapter. 12.4.1 Operator Menu This section describes each item on the operator menu. Use this menu to view the measured values and basic settings of the power controller. -
Page 30: Setup Menu
12.5 Setup Menu This section describes each item on the setup menu. Use this menu to configure the power controller for the load. The password to access this menu is 2. Parameter Modbus Par. Description Range Unit Name Address Type Set the percentage by which the set point is scaled. - Page 31 Option cont. Value Phase angle Soft Start Burst Firing Delay Trigger DEFAULT: Burst Firing Parameter Modbus Par. Description Default Range Unit Name Address Type Set the minimum number of On cycles and off cycles for Read Min Cycles 0 to 999.9 n°...
-
Page 32: Hardware Menu
Option Value DEFAULT: Off Modbus Par. Parameter Name Description Default Range Unit Address Type Read Logging interval Set how often data is logged 5 sec 0 to 255 Write Read Heater Bakeout Enable or disable the heater bakeout feature Write Option Value DEFAULT: Off... - Page 33 Option Description Value Enable Enable power output Voltage Feed-back Use voltage feed-back when on Local / Remote Local when on / Remote when off Phase Angle Use phase angle firing when on Set point Analog In 1/2 Select remote set point source: analog input 1 when off or analog input 2 when on Logging Enable logging...
- Page 34 Modbus Par. Parameter Name Description Default Address Type I Limit Local / Read Choose how the current limit is set 14,bit 4 Remote Write Option Description Value Local Set point set via keypad or commu- nication Analog In2 Set point set via analog input DEFAULT: RMS voltage output Local...
-
Page 35: Communication Menu
Modbus Par. Parameter Name Description Default Address Type Choose wich parameter is displayed on the home Read Startup Display page at power-up Write Option Value Current Voltage Power DEFAULT: Voltage 12.5.4. Communication Menu This section describes each item on the communication menu. Use this menu to configure the communication op- tions. -
Page 36: Monitoring Menu
Modbus Par. Parameter Name Description Default Range Unit Address Type Set the amount of time to wait for a Watchdog Reset Read message before triggering the watchdog 0 to 255 Time Write error Indicate the IP address of the WiFi 94-95 Read Wi-Fi Address... - Page 37 Option Value Modbus Par. Parameter Name Description Address Type Read Digital In 2 Indicate the state of the signal to digital input 2 13 bit9 Only Option Value Modbus Par. Parameter Name Description Address Type Indicate whether or not the power controller is enabled. Read Enable The enable signal must be on for the unit to output power...
- Page 38 Option Description Value 1 Leg Single Phase 2 Leg Two Leg, three phase 3 Leg Three Leg, three phase 3 Leg PA Three Leg, three phase with phase angle capability 9999 Modbus Par. Parameter Name Description Range Unit Address Type Indicates the maximum voltage rating of the Read Max Voltage...
-
Page 39: Using The Configurator
13. Using the Configurator Configurator software can be used like an alternative of the power controller’s keypad and set the advanced features not available via the power controller’s onboard user interface. Here will explain how use it. 13.1 Typical Uses The software may be used during commissioning to: •... -
Page 40: Using The Configurator
Procedure to communicate with a power controller: 1) if used direct USB connection: - Connect the USB cable between the computer and the micro USB connector on the power controller’s keypad - if necessary, Wait for the USB driver to install. 2) if used RS-485 connection connect the power controller terminal to computer RS485 port. -
Page 41: To Edit A Setting In A Recipe
13.5.2 To edit a setting in a recipe: 1) Click Simple, if not already on the simple view 2) Click Open existing recipe 3) Locate and select the recipe file and click Open 4) Click OK 5) Click the menu with the setting you want to change - SETUP - ADVANCED SETUP - HARDWARE... -
Page 42: To View Data On The Scope
13.5.7 To view data on the scope: 1) Click Test, if not already on the test view 2) Click Online 3) Click Load Analyzer 4) For each of up to three channels (Ch 1 to Ch 3): - With PV1 choose the value to monitor - Select Show - Click the colour swatch to change the colour - Click the button to turn the channel on. -
Page 43: To Retrieve A Data Log File From The Power Controller
13.5.10 To retrieve a data log file from the power controller: 1) Click Test, if not already on the test view 2) Click Online 3) Click Load Analyzer 4) Click Connect 5) Select a file from the list 6) Click Download 7) Select a location and click Save 8) Wait for the file to download. -
Page 44: Test Section
To manage recipe click on: Create a New recipe: create a recipe file with the standard default settings Open existing recipe: open an existing recipe file Upload from unit: create a new recipe with the value uploaded from a connected power controller Close: close the current recipe Save: save the recipe in a file Save as: save a copy of the recipe in a file... - Page 45 Status and Setup Indicators: Digital input status: light on when the input is a a closed circuit Enable indicator: light on when the power controller is enabled Enable/Disable button: click on to enable the power controller if a digital input is not configured for this function ON indicator: light on when there is demand for the output to be on SC indicator: light on when there is a shorted SCR alarm active...
-
Page 46: Load Analyzer
NOTE! The Load Calibration settings, Load Voltage and Load Current define 100% power for the load. Energy Monitor: indicates power, power factor and energy usage over time which may be reset with the Reset Tot button. Data Log: If present is used to configure the data logging feature data logs. -
Page 47: Data Log Window
13.6.5 Data Log Window In the power controller the data log window is used to manage files and set up logging parameter like log interval time and date/time in rtc Log Enabled/Log Disabled slider: Enable and disable data logging function. Log Time: the time between data log records in seconds Config: opens the data log configuration window to customize the variable to log File List: lists the data log files available in the power controller... -
Page 48: Msg View
13.6.7 MSG view Message view display the communication activity between the computer and the power controller. PORT COM: use this view to see when the COM port is accessed and its settings MODBUS: Modbus communication protocol area READ Area: use this view to see parameters being polled READ Area ->... -
Page 49: Firing Type
14. Firing type Choose a correct firing type allows to optimize the thyristor unit for the installed load. The firing type has already configured in line with customer requirements that are defined in the Order Code. The Order Code is written on the identification label. However, if you wish to change the firing type you can use the software configurator or the Control Panel. -
Page 50: Soft Start With Burst Firing
14.4 Soft Start with Burst Firing This is an additional function to the Burst Voltage Supply (V) Firing. The unit start in phase angle mode with a ramp starting from zero up to the full tension in the cycles number set in the Load Voltage (V) parameter. -
Page 51: Delay Triggering With Burst Firing
14.7 Delay Triggering with Burst Firing Without Delay Triggering With Delay Triggering The Delay Triggering firing is used the control a primary of transformer coupled with the normal Transient over-current resistances on the secondary (N.B. don’t connect cold resistances on Delay angle (0°... -
Page 52: Current Limit
15. Current Limit The Current Limit is available on REVO CL with Phase Angle firing mode only. It control the firing angle of the thyristor to maintain the three RMS current under the set value. When the current exceeds this value, the voltage is decreased up to reach the current limit set I load ≤... -
Page 53: Bakeout In Function
16. Bakeout in function 16.1 What is heater bakeout? If a MgO-insulated heater element shuts down for a long period of time (or sits in storage), it can absorb moisture. If full power is applied, excessive current can damage the heater or blow fuses. The heater bakeout feature soft starts the load to remove moisture from the heater and prevent blown heaters and fuses. -
Page 54: Control Mode (Feed-Back)
17. Control Mode (feed-back) The Control Mode (feed-back) type has already configured in line with customer requirements that are defined in the Order Code. The Order Code is written on the identification label. However, if you wish to change the Control Mode (feed-back) type you can use the software configurator or the Control Panel. -
Page 55: Supply The Electronic Board
18. Supply the Electronic Board The Relay C thyristor unit, to work, requires a voltage supply for the electronic boards. The Max consumption is 10VA. The voltage supply for the electronic boards is configured in line with customer requirements that are defined in the Order Code. -
Page 56: Rs485 Serial Port
19. RS485 Serial port M1 Terminal Description RS485 A+ RS485 B- The serial communication port RS485 is available on the Command. On this port may be done a network up to 127 Relay C. 20. Fieldbus communication option Other serial communication port are available as option, see Communication Manual for details. Ethernet Configuration Profibus Configuration Second Serial 485 Configuration Connectors M4... -
Page 57: Internal Fuse
21. Internal Fuse The thyristor unit have internal fuse extrarapid at low I²t for the thyristor protection of against the short-circuits. The Fuses must have I²t 20% less than thyristor’s I²t. The warranty of thyristor is null if no proper fuses are used. Type Fuse Code Spa- Current (ARMS) - Page 58 21.1 Fuses Replacement Open the cover and remove the screws, then replace it with the correct fuse, use the screws with a proper suggested torque indicated below: Torque Torque Type Screw Screw Lb-in (N-m) Lb-in (N-m) 60-120A 44.2 (5.0) 31 (3.5) 150-210A 44.2 (5.0) www.west-cs.co.uk...
