Compact Inbay Control
These Instructions Contain General Data. Any Deviation From Customers Prints Or Specifications Should Be
Clarified Before Proceeding With Lift Installation.
IMPORTANT
Check the containment tube for holes due to shipping damage. Do not install a damaged
containment tube. Contact Rotary Lift Customer Service. If the lift has a chance to be exposed to the
elements, protect the lift.
© February 2010 by Rotary Lift. All rights reserved. CO7473.1
SL210i/SL212i
(800 Series) (1Ø & 3Ø 208V-240V) (3Ø 480V)
SL210i Moveable Pad Capacity 8,000 lbs.
SL210i Capacity 10,000 lbs.
SL212i Capacity 12,000 lbs.
Attention!!!
*PLP20447
LP20447
*
IN20481
Rev. C 2/4/2010
I
I
N
N
S
S
T
T
A
A
L
L
L
L
A
A
T
T
I
I
O
O
N
N
I
I
N
N
S
S
T
T
R
R
U
U
C
C
T
T
I
I
O
O
N
N
S
S
