Stewart Filmscreen Corp AVS-1005 Owner's Manual

Avs—automatic vertical screen
Hide thumbs

Advertisement

Table of Contents

AVS-1005
T
O T H E I N S T A L L E R
: B
E S U R E T O L E A V E T H I S M A N U A L W I T H T H E O W N E R
AVS—Automatic
Vertical Screen
O W N E R ' S
M A N U A L
To the Owner
To the Owner
To the Owner
Installation Instructions
Installation Instructions
Installation Instructions
Operating the Screen
Operating the Screen
Operating the Screen
Maintenance
Maintenance
Maintenance
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AVS-1005 and is the answer not in the manual?

Questions and answers

Related Manuals for Stewart Filmscreen Corp AVS-1005

Summary of Contents for Stewart Filmscreen Corp AVS-1005

  • Page 1 AVS-1005 O T H E I N S T A L L E R AVS—Automatic Vertical Screen O W N E R ’ S E S U R E T O L E A V E T H I S M A N U A L W I T H T H E O W N E R...
  • Page 2 Printed in U.S.A. ©2004, 2005 Stewart Filmscreen Corporation Stewart Filmscreen reserves the right to make changes to the product specified in this document. From time to time, this document is updated. Current versions of documentation are posted on the Stewart Filmscreen website at www.stewartfilm.com.

  • Page 3: Table Of Contents

    AVS—Automatic Vertical Screen O W N E R ’ S M A N U A L Contents To the Owner ........2 Preparing the Installation .

  • Page 4: To The Owner

    O THE WNER Audience right Electrical connections: AC, control switch Door Case / housing Congratulations on your purchase of the finest optical viewing screen available anywhere in the world! Please take a moment to review this manual—it will help ensure you many years of trouble-free service from your new Stewart Filmscreen product.

  • Page 5: Preparing The Installation

    REPARING THE NSTALLATION Automatic Vertical Screen: Owner’s Manual Note: This manual refers to “AC” to represent electrical power. Your location may use 120 V, 220 V or other electrical power. Screen systems are manufactured using the electrical power type specified for the location. Use appropriate power sources for your location.

  • Page 6: Installation And Electrical Hook-Up

    NSTALLATION AND AC connection Figure 2. AC connection LECTRICAL Caution Professional techniques need to be used when making any electrical connection. A qualified electrician should perform these procedures. Be sure to follow all standard safety procedures for installing electrical devices. Do not disassemble or alter the configuration of the motor or the unit's electrical connections.
  • Page 7 Automatic Vertical Screen: Owner’s Manual Installing the low-voltage 3-button switch on the wall The Stewart Filmscreen low-voltage control allows the use of Class 2 low- voltage wire to connect to the supplied 3-position momentary wall switch or auxiliary AV switching systems. The switch control plate is connected to the unit’s J-box at the factory.

  • Page 8: Operating The Screen

    PERATING THE CREEN WARNING! When operating the screen: Stand clear from the screen when it is in motion. Supervise children and animals when the screen is in motion. Keep hands and limbs away from the door and arm assemblies when the unit is in operation.

  • Page 9: Adjusting The Screen Extension

    DJUSTING THE CREEN Yellow (do not adjust) White (adjusts open screen position) Figure 5. Limit switches Automatic Vertical Screen: Owner’s Manual XTENSION The extension and retraction limit switches have been preset at the factory. In general, we advise you to avoid readjusting these switches. In rare cases, to enable proper alignment of the displayed image on the screen, you may need to adjust the extension of a screen.

  • Page 10: Screen Care And Cleaning

    A factory authorized returned screen arriving prepaid to our facility for inspection and proved defective due to an inherent manufacturing fault will be repaired or replaced by Stewart Filmscreen Corp. This warranty expressly does not cover any costs of removal, installation, framing, or other incidental costs to replacing the screen or returning it to the manufacturer.

  • Page 11: Troubleshooting

    ROUBLESHOOTING Problem description Screen will not operate. Door will not operate. Screen will not roll up or down (even though power is available). Screen roller chatters when power is activated. Unit hums in retract mode. Screen drops when retracted (grinding noise occurs). Screen continues past fully extended stop position.
  • Page 12 www.stewartfilm.com 1-800-762-4999 Fax (310) 326-6870...
