MANUAL SOLO
Ver 1.5
Updated: 2013-10-25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Arctiq and is the answer not in the manual?

Questions and answers

Summary of Contents for Mecaterm Arctiq

  • Page 1 MANUAL SOLO Ver 1.5 Updated: 2013-10-25...

  • Page 2: Table Of Contents

    Safety regulations ........................6 Component overview ................7 ArctiQ ............................7 ArctiQ EVI ..........................8 Aqua ............................9 Installation of ArctiQ & ArctiQ EVI ........... 10 Positioning ........................... 10 Pipe installation ........................13 Installation of Aqua ................. 15 Positioning ........................... 15 Pipe installation ........................
  • Page 3 SoloBasiC – Set condensation ..................42 SoloBasiC – floating condensation ................... 43 SoloDigitaL .......................... 44 Service and maintainance .............. 45 ArctiQ & ArctiQ EVI ......................45 Manual defrost ........................46 Aqua ............................. 47 R/T tables sensors ......................48 Technical data ................. 49 ArctiQ ...........................

  • Page 4: Introduction

    (indirect solar energy) and, using a cooling process, transfer heat to your boiler system, thereby providing you with inexpensive energy. The Mecaterm ArctiQ model is a very reliable heat pump that operates at temperatures as low as –15ºC and produces water temperatures of up to 60ºC. The effectively sound-insulated compressor and the optimized heat exchanger offer high operating efficiency.

  • Page 5: Aqua

    Aqua uses the same reliable components as the related ArctiQ and ArctiQ EVI models, as well as being fitted with extra-thick sound insulation to reduce disturbing noise levels.

  • Page 6: Delivery

    Check the following points when your pump has been delivered and when installing the pump: • The ArctiQ, ArctiQ EVI and Aqua pumps must be transported and stored in a vertical position. • Remove packaging and check that the product has not been damaged in transit. Report any transit damage to the freight agent.

  • Page 7: Component Overview

    P a g e OMPONENT OVERVIEW RCTI Evaporator Defrost sensor Expansion valve Sight glass Check valve Filter drier/receiver Primary flow temp sensor Condensor Air vent valve Control unit Return flow temp sensor Bulb expansion valve 4-way valve Discharge gas temp sensor ¼”...

  • Page 8: Arctiq Evi

    P a g e Evaporator Q EVI RCTI Economizer Defrost sensor Main expansion valve EVI expansion valve Check valve Sight glass Solenoid valve EVI Filter drier/receiver Primary flow temp sensor Control unit Return flow temp sensor Bulb main expansion valve 4-way valve Discharge gas temp sensor ¼”...

  • Page 9: Aqua

    P a g e Evaporator Condensor Brine in temp sensor Expansion valve Filter drier/receiver Compressor Variable speed charge pump Return flow temp sensor Drain plug condensor Primary flow temp sensor Discharge gas temp sensor High pressure switch, 29bar ¼” schrader high pressure Sight glass ¼”...

  • Page 10: Installation Of Arctiq & Arctiq Evi

    NSTALLATION OF RCTI RCTI This chapter is intended for installers of the heating system. It describes how to install the ArctiQ and ArctiQ EVI air-water heat pump models. ► Please note that the commissioning report in the end of this manual must be filled in once the product is installed.
  • Page 11 P a g e | 11  Defrosting can entail a certain amount of condensation from the battery, which must be drained off, for instance, using a gravel bed and to prevent the water from running off to form ice on open surfaces. ...
  • Page 12 P a g e | 12...

  • Page 13: Pipe Installation

    Pipe dimensions Connection heat Minimum connection Model Size Nominal flow pump pipe dimension 800l/h 22mm ArctiQ 10,5 cu28 1100l/h 28mm 1600l/h 22mm 1000l/h ArctiQ EVI cu28 1300l/h 28mm 1900l/h Pressure drop condenser ArctiQ and ArctiQ EVI...
  • Page 14 P a g e | 14  A metal-enclosed hosing can easily be coupled between the connecting pipe and the heat pump's condenser to prevent any vibrations/noise from being transferred to the radiator system in the house.  Note the coupling direction of the connecting pipes/hoses on the heat pump that is displayed on the side of the condenser as outlined in figure below.

  • Page 15: Installation Of Aqua

    RINE MEDIUM Dimensioning The collector for earth/bedrock/ground water/lake heat, etc. is dimensioned according to a computerised calculation program. Mecaterm can assist with this type of calculation. Insulation The indoor brine medium piping must be insulated with a moisture barrier material to prevent condensation from dampness.
  • Page 16 P a g e | 16 Brine fluid The brine medium should contain antifreeze medium, such as propylene glycol, to maintain fluidity down to temperatures of -15ºC. Collector hose The collector hose, PEM 40 x 2.4 PN 6.3, is used as standard. Every metre of hosing holds about 1 litre of fluid.
  • Page 17 P a g e | 17 Schematic connection diagram Description Brine to heat pump (in) Brine from heat pump (out) Filling valve (including shut off valves & dirt filter) Safety valve, 3 bar Level tank (expansion) Shut off valve Water from heat pump (primary flow) Water to heat pump (return flow) Arbitrary boiler/accumulator tank...
  • Page 18 P a g e | 18 Pressure drop evaporator Aqua with 30% ethylene glycol in carrier Aqua 5/8 Aqua 10/12/17 Circulation pump curve for Aqua 5/8 Circulation pump curve for Aqua 10/12/17...

  • Page 19: Heating Medium

    In this case the software will control the speed of the charge pump in order to achieve the desired value. (If a Mecaterm boiler is used the speed will vary depending on the boilers need.) Pressure drop condensor Aqua.

  • Page 20: Electrical Installation

    P a g e | 20 LECTRICAL INSTALLATION The electrical installation must be carried out by an authorised electrician and according to local regulations. VERVIEW 230V relays 12VDC power supply Contactor compressor Soft starter NTC thermistors Current transformer 230V connection Display+buttons Power supply connection Low voltage connections...

  • Page 21: High Voltage Supply

    Max phase load Recommended fusing cable area 5,2A 10A (C) 1,5mm² ArctiQ 10,5 7,4A 11,4A 16A (C) 2,5mm² 6,2A 10A (C) 1,5mm² ArctiQ EVI 9,0A 16A (C) 2,5mm² 12,3A 4,8A 5,7A 10A (C) 1,5mm² Aqua 7,2A 8,2A 11,6A 16A (C) 2,5mm²...

  • Page 22: Low Voltage Connections

    → Should not be connected → Optional connection A/W=ArctiQ and ArctiQ EVI, B/W=Aqua ¹If floating condensation will be used outdoor sensor must be installed. ²Outdoor sensor can be installed in heat pump or in Mecaterm boiler/MasterLogiQ ³ModBus demands an extra expansion circuit board.

  • Page 23: Overview Low Voltage Connections

    Please read more in chapter “Control mode” (Only valid for ArctiQ and ArctiQ EVI. Aqua has a integrated pwm controlled charge pump installed from factory) OUTD SENS is the connection for the outdoor sensor shipped together with the heat pump.

  • Page 24: Control Modes

    Optional connections - Outdoor sensor (if floating condensation should be used with Aqua) - PWM (only for ArctiQ and ArctiQ EVI if pwm pump should be used) - Alarm (only if the accessory SoloAlarm should be installed - Control of external energy source with the digital output “HEATER”...
  • Page 25 | 25 Outdoor sensor Outdoor sensor must always be installed for the air/water models ArctiQ and ArctiQ EVI. For the Aqua heat pump it’s only necessary to install it if the system should operate at floating condensation which is described later in his chapter.
  • Page 26 P a g e | 26 Adjust the heating curve There are 3 ways to control how the heat pump will operate against the tank with floating condensation. Heat at outdoor temperature -15°C Default setting for heat at -15°C is 50°C, i.e. when outdoor temperature is -15°C the set point for heat pump will be 50°C.

  • Page 27: Controlling Of External Heat Source

    P a g e | 27 Summer time charge The last adjustment is a setting that gives possibility to change to set condensation at a desired outdoor temperature, often referred as “summer charging”. At the set temperature the heat pump starts to charge until return temperature reaches maximum set flow temperature - 12°C .

  • Page 28: Solodigital

    - Outdoor sensor (only for ArctiQ and ArctiQ EVI) - CTRL Optional connections - PWM (only for ArctiQ and ArctiQ EVI if pwm pump should be used) - Alarm (only if the accessory SoloAlarm should be installed Charge pump (only ArctiQ and ArctiQ EVI) As for control mode SoloBasiC there are 2 different options for controlling of the charge pump, standard non-controlled or pwm-controlled charge pump.

  • Page 29: The Display

    P a g e | 29 HE DISPLAY The display on the heat pump board consists of four 7-segment display units and 3 buttons. The display can show both errors and actual values and is also used for setting of the different control modes and parameters which are presented in this chapter EST MODE In normal mode, i.e.

  • Page 30: Errors

    P a g e | 30 RRORS If any error is present the display will show it and “Actual values” cannot be seen. However it’s still possible to switch to “Set mode” even if errors are present. When an error is present the display will show “Er” and a number. If “Er”...
  • Page 31 P a g e | 31 ABLE CTUAL VALUES Observe that this mode is not available if errors are present. To make sure that you are in this menu observe the first decimal point. If it is not flashing you are in the actual values menu. The first character in the view is the ID, for example, 0, 1, 2, 3 and so on.
  • Page 32 EVI only or if floating condensation used. Outdoor temperature too low. ArctiQ is limited to ArctiQ and ArctiQ -15C and ArctiQ EVI to -25C. EVI only. 0 = Operation possible 1 = Outdoor temperature too low Countdown to possible defrosting cycle in minutes. At...
  • Page 33 Not affected 0 = Mode “SoloBasiC” of factory 1 = Mode “SoloDigitaL” reset. 2 = Mode “Mecaterm boilers” 3 = Mode “Multi control” CAN id. (Only relevant for multi Mode controlling of several heat pumps) “Multi” only Choice for running with set or floating condensation with runmode SoloBasiC.
  • Page 34 ArctiQ&Aqua, Max flow temperature from heat pump. 60,0 temp=62C (Observe that for ArctiQ and ArctiQ EVI 5 6. 5 58,0 25,0 maximum temperature will decrease at 62,0 ArctiQ EVI, low outdoor temperatures.)
  • Page 35 9. 7 -3,0 +3,0 protectors cut out value. Setting to confirm if a pwm controlled charge pump is installed or not. ArctiQ & ArctiQ EVI 0 = Pwm charge pump not installed only 1 = Pwm charge pump installed Visible for 8.
  • Page 36 P a g e | 36 ABLE RRORS Following table gives information of what the different error codes means and also possible causes for the initiation. Observe that if the “ER” is flashing the error cannot be reset. Many errors can be present at the same time.
  • Page 37 Hotgas temp high This error is initiated if the discharge gas temperature on the compressors discharge pipe gets too high. Maximum allowed temperature for ArctiQ and Aqua is 140°C and for ArctiQ EVI 130°C. E R 1 0 Possible causes 1.
  • Page 38 P a g e | 38 Low delta T warning This error is initiated if the temperature difference over the heat pump, i.e. flow temperature – return temperature, is too low at present operation point. E R 1 3 Possible causes 1.
  • Page 39 E R 2 3 Possible causes 1. Wrong flow direction on water pipes 2. 4-way valve malfunction (only ArctiQ and ArctiQ EVI) 3. Wrong mounting of water temperature sensors 4. Malfunction on water temperature sensors Repetitive stops on maximum heat pump temperature This error is initiated if the heat pump stops on maximum allowed temperature 5 times during 1 hour.
  • Page 40 P a g e | 40 Phase L1 missing This error is initiated if phase L1 is missing in the heat E R 2 5 pump. Possible causes 1. Fuse broken on power lines to heat pump Phase L2 missing This error is initiated if phase L2 is missing in the heat E R 2 6 pump.

  • Page 41: Quick Start Guide

    P a g e | 41 UICK START GUIDE This guide will help you do the most crucial settings in order to get the heat pump running. However it is recommended to read the details in this manual to get the full picture of how the heat pump will operate.

  • Page 42: Solobasic - Set Condensation

    P a g e | 42 C – S ET CONDENSATION 1. Choose SoloBasiC control mode by setting “b” to 0. Confirm with “OK” 2. Chose set condensation by setting “d” to 0. (This is factory preset value.) 3. Set desired tank (return) temperature by setting the parameter “J”...

  • Page 43: Solobasic - Floating Condensation

    P a g e | 43 C – FLOATING CONDENSATION 1. Choose SoloBasiC control mode by setting “b” to 0. Confirm with “OK” Chose floating condensation by setting “d” to 1. It’s possible to also change the slope and settings of heating curve. See chapter “Set or floating condensation”.

  • Page 44: Solodigital

    P a g e | 44 IGITA 1. Chose SoloDigitaL control mode by setting “b” to 1 2. Go to actual values by holding OK button for 2 seconds and find the view “1” 3. Make sure that the view “1” is showing a 1 and not a 0 when the CTRL-switch is closed. Switch closed ->...

  • Page 45: Service And Maintainance

    In rare cases, a thin coating may form on the stainless steel. If this occurs, there are special cleaning agents available for stainless steel, such as Avesta OriginalFinish, a rust remover. This agent can be ordered from Mecaterm.  Check once a year that the inspection glass in the heat pump is clean and not filled with bubbles when in use.

  • Page 46: Manual Defrost

    | 46 ANUAL DEFROST Only of interest for ArctiQ and ArctiQ EVI At extreme conditions it might sometimes be necessary to perform a manual defrost of an air/water heat pump. In order to achieve this first of make sure that the circulation pump (charge pump) is running.

  • Page 47: Aqua

    P a g e | 47  Check once a year that the inspection glass in the heat pump is clean and not filled with bubbles when in use. Any bubbles may indicate low freezing medium levels and a service technician should be contacted.

  • Page 48: R/Ttables Sensors

    P a g e | 48 TABLES SENSORS Water / Brine / Defrost sensor Hot gas sensor Temp Temp Temp Temp R (kΩ) R (kΩ) R (kΩ) R (kΩ) (°C) (°C) (°C) (°C) 11,50 2,34 163,4 10,94 2,25 147,6 10,42 2,16 133,5 9,92...

  • Page 49: Technical Data

    P a g e | 49 ECHNICAL DATA RCTI Technical data ArctiQ 7,5 ActiQ 10,5 ArctiQ 16 Product number 9774704201 9774704301 9774704401 Measures (w x h x d) 1205 x (950-1040) x 605 mm 1205 x (1280-1570) x 605 mm...

  • Page 50: Arctiq Evi

    P a g e | 50 Q EVI RCTI Technical data ArctiQ EVI 10 ActiQ EVI 14 ArctiQ EVI 20 Product number 9774704501 9774704601 9774704701 Measures (w x h x d) 1205 x (950-1040) x 605 mm 1205 x (1280-1570) x 605 mm...

  • Page 51: Aqua

    P a g e | 51 Technical data Aqua 5 Aqua 8 Aqua 10 Aqua 12 Aqua 17 Product number 9774704801 9774700601 9774704901 9774700701 9774700801 Measures (w x h x d) 598 x 900 x 650 mm Weight 115kg 120kg 127kg 137kg 142kg...

  • Page 52: Spare Part List

    P a g e | 52 PARE PART LIST Q EVI RCTI RCTI Article number Component ArctiQ 7,5 ArctiQ 10,5 ArctiQ 16 EVI 10 EVI 14 EVI 20 Compressor 520933800 520879800 520964700 520606300 520990000 521019500 Receiver drier 520837800 520837800 520837800...

  • Page 53: Commissioning Report

    OMMISSIONING REPORT DATA INSTALLER Model: Order number: Company: □ □ □ ArctiQ ArctiQ EVI Aqua Heat pump serial number: Date: Address: Electricity metre reading: Postal address: Signature: INSTALLATION CHECK The system is filled with water and has been Name in Block Letters: □...

  • Page 54: Electrical Diagram

    P a g e | 54 LECTRICAL DIAGRAM...
  • Page 55 P a g e | 55...
  • Page 56 P a g e | 56 Mecaterm Blidogatan 34 211 24 Malmoe Sweden +4640385060 www.mecaterm.se...
