Summary of Contents for TSI Instruments 854033
- Page 1 INSTALLING THE ENCLOSURE HEATER MODEL 854033 QUICK START GUIDE P/N 6008412, REVISION B JANUARY 2016 _______________ TSI and TSI logo are registered trademarks of TSI Incorporated.
- Page 2 This guide will help you quickly install the Enclosure Qty. Item Description Reference Picture Heater (854033) for the Environmental Enclosure Heater (854030). Unpacking 1. Unpack the enclosure heater and verify that all the items listed in the following table are present.
- Page 3 3. Mount the Heater Power Supply onto the upper DIN 6. Install the Heater onto the DIN Rail and Plug into the Rail by hanging the top bracket clips on the DIN Rail two Phoenix Connectors just installed to the right of and snapping the bottom back into place.
-
Page 4: Operating Instructions
9. Remove vent plugs when weather conditions do not require use of the heater. Twist vent cover counter clockwise to remove vent plugs. Hand-tighten after removing plug. Operating Instructions 1. The heater thermoset is preset, no adjustment or setting is required. Thermostat will turn heater on automatically when the temperature inside the enclosure reaches approximately +5°C (41°F).
