Sanit-ICE
®
Installation & Operation Manual
Ozone System
OptiPure, a Division of Aquion, Inc.
Commercial Water Filtration Systems
101 S. Gary Ave., Suite A, Roselle, IL 60172 • 972.881.9797
E-mail: info@optipure.net • www.optipurewater.com • Copyright © 2018 - OptiPure
Reproduction of any kind is prohibited • LIT375 • REV0083018
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for OptiPure Sanit-ICE
- Page 1 OptiPure, a Division of Aquion, Inc. Commercial Water Filtration Systems 101 S. Gary Ave., Suite A, Roselle, IL 60172 • 972.881.9797 E-mail: info@optipure.net • www.optipurewater.com • Copyright © 2018 - OptiPure Reproduction of any kind is prohibited • LIT375 • REV0083018...
- Page 3 Therefore, the information contained in this manual may not conform in every respect to earlier versions of OptiPure systems found in the field. If you have any questions, please contact your OptiPure dealer or the OptiPure service...
-
Page 4: Table Of Contents
ABLE OF ONTENTS Theory of Operation ..............3 Instructions ................4 Installation Procedures ............6 Figure 1 – Feature Callout ..........7 Figure 2 – Typical Installation ..........7 Operating Instructions ............8 Figure 3 – Summary of LED Indicators ......8 Trouble Shooting .............. -
Page 5: Theory Of Operation
System is an environmentally friendly device allowing you to infuse dissolved ozone into an ice maker water reservoir. Using only a ® small amount of electricity, the Sanit-ICE System takes oxygen from the air and converts it into ozone (O ), a very powerful natural oxidizer, and then bubbles that ozone into the water sump inside the ice machine. -
Page 6: Instructions
1. Save These Instructions. Before using, please read the owner’s manual carefully 2. Disconnect power before servicing ® 3. Make sure the Sanit-ICE System is horizontal. See installation instructions. Do not mount to a wall vertically or at any angle. The unit may also be placed on a flat horizontal surface. - Page 7 Instructions 11. GROUNDING INSTRUCTIONS – This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current. This appliance is equipped with a cord having an appliance-grounding conductor and a grounding plug.
-
Page 8: Installation Procedures
® • The Sanit-ICE System is to be mounted no further than 10 feet from the point of use. • Mount the Sanit-ICE System above the entry point of the ozone line into the ice machine. ® Mount the Sanit-ICE System •... - Page 9 • Run tubing through grommet installed in ice maker. Attach the opposite end of the tubing to the barbed fitting of the diffuser provided and place the diffuser into the water reservoir. ® • Plug the Sanit-ICE System into a GFCI protected outlet. Feature Callout Figure 1...
-
Page 10: Operating Instructions
® In the event of power loss, the Sanit-ICE System will remember what profile it was set at, and resume function when it receives power again. -
Page 11: Trouble Shooting
Red Light Illuminated ® The light on the Sanit-ICE system will turn red after the ozone cell has run for approximately 9000 hours. This will typically take between 1 and 3 years depending on which mode the unit is in. At this time the unit needs to be serviced. -
Page 12: Appendixa - Specifications
A - S PPENDIX PECIFICATIONS System Dimensions 10W x 5.6T x 3.6D inches (254W x 142T x 92D mm) Outlet 3/16” Barb Power 120/240 VAC, 50/60 Hz Power Connection 6’ (1.8m) 3-prong cord Mounting Z-bar Ambient Conditions 32-95 °F (0-35 °C) 10-90% RH non-condensing Shipping Weight 3.5 lbs (1.6 kg) - Page 13 Appendix A – Specifications Ozone Cell Ozone Generator Ozone Outlet Power Supply Air Compressor Power Cord Control Board - 11 -...
- Page 14 90 days of the original shipment from OptiPure; 2) The warranty period shall begin on the date of the bill of sale to the end user if the installation date is more 90 days after the original shipment date.
-
Page 15: Appendix B - Warranty Information
Appendix B – Warranty Information that you insure the shipment for the amount you originally paid for the product and/or part. If, after the product and/or part is returned prepaid and evaluated by OptiPure, it proves to be defective while under warranty, OptiPure will, at its election, either repair or...
