IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1.
CAUTION – This fixture provides more than one power supply output source. To reduce the risk of electrical
shock, disconnect both normal and emergency sources by turning off the A.C. branch circuit.
2.
CAUTION – This is a sealed unit. Replace the entire unit when necessary.
3.
DO NOT USE OUTDOORS. The ETS is for use with grounded, UL Listed, indoor fixtures. Not for use in
heated air outlets or hazardous locations.
The ETS requires an unswitched A.C. power source of either 120 or 277 volts. Properly cap the unused
4.
A.C. lead.
5.
Do not mount near gas or electric heaters.
The ETS should be mounted in locations and at heights where it will not readily be subjected to tampering by
6.
unauthorized personnel.
7.
The ETS is compatible with all A.C. magnetic and electronic ballasts.
8.
The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
9.
Do not use this equipment for other than intended use.
10.
Install in accordance with the National Electrical Code and local regulations.
11.
Installation and servicing should be performed by qualified personnel.
12.
Lighting fixture manufacturers, electricians, and end-users need to ensure product system compatibility before
final installation.
INSTRUCTION MANUAL
SAVE THESE INSTRUCTIONS
ETS
EmERgENCY
TRANSFER SWITCH
SERIES A
Advertisement
Related Manuals for IOTA ETS
Summary of Contents for IOTA ETS
-
Page 1: Instruction Manual
A.C. lead. Do not mount near gas or electric heaters. The ETS should be mounted in locations and at heights where it will not readily be subjected to tampering by unauthorized personnel. The ETS is compatible with all A.C. magnetic and electronic ballasts. -
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS CAUTION: Before installing, make certain the A.C. power is off. 1. MOUNTING THE ETS Remove the ballast channel cover. Mount the ETS in the ballast channel at least ½″ away from the A.C. ballast(s). 2. WIRING Refer to the wiring diagrams on the back page for the appropriate wiring of lamp(s) and ballast. Install in accordance with the National Electrical Code and local regulations. - Page 3 All lamps in the fixture are illuminated at full light output for as long as gen- erator power is available. When the A.C. power is restored, the ETS switches the system back to the Normal Mode.
- Page 4 TYPICAL WIRING DIAGRAMS For wiring diagrams of ballasts not shown, consult our Customer Service. 1. TYPICAL BALLAST/GENERATOR APPLICATION TYPICAL GENERATOR APPLICATION WHT/BLK WHITE AC BALLAST BLK/ORG BLACK ORG (277V) SELECT PROPER VOLTAGE � BLK (120V) EMERGENCY LEAD. CAP UNUSED LEAD. TRANSFER WHITE SWITCH...
