Operating Instruction and safety manual
Residual risks
Even when the tool is used as prescribed it is not possible to eliminate all residual risk factors. The following
hazards may arise in connection with the tool's construction and design:
1. Damage to lungs if an effective dust mask is not worn.
2. Damage to hearing if effective hearing protection is not worn.
3. Health defects resulting from vibration emission if the power tool is being used over longer period of time or not
adequately managed and properly maintained.
4.
Wear eye protection.
1
Air Hammer 27621
125mm Air Hammer
Model No.: 27621
Round chisels
IMPORTANT:
Upon receipt of the product,
read and follow all safety rules,
operating instructions before first use it.
And retain this manual for future reference.
Hex chisels
2013
2014
Advertisement
Table of Contents
Summary of Contents for Rongpeng 27621
- Page 1 Operating Instruction and safety manual 125mm Air Hammer Model No.: 27621 Round chisels Hex chisels IMPORTANT: Upon receipt of the product, read and follow all safety rules, operating instructions before first use it. And retain this manual for future reference.
-
Page 2: Important Safety Rules
-- of the risk of a whipping compressed air hose. -- to observe that only lubricants recommended by the manufacturer shall be used -- to release the start and stop device in the case of an interruption of the energy supply Air Hammer 27621... -
Page 3: Air Supply
Use the proper lubricant in the air line lubricator. The lubricator should be of low air flow or changing air flow type, and should be kept filled to the correct level. Use only recommended lubricants, specially made for pneumatic applications. Substitutes may harm the rubber compounds in the tools O-rings and other rubber parts. Air Hammer 27621... -
Page 4: Loading And Operation
Grit or gum deposits in the tool may also reduce performance. If your model has an air strainer (located in the area of the air inlet), remove the strainer and clean it. 5. When not in use, disconnect from air supply, clean tool and store in a safe, dry, childproof location. Air Hammer 27621... -
Page 5: Troubleshooting
Disconnect supply. ■ Tool will not shut off Replace ‘O’ ring . ‘O’ rings throttle valve ■ ■ dislodged from seat inlet valve. Note: Repairs should be carried out by a qualified person. Air Hammer 27621... - Page 6 Cylinder Front handle sleeve Piston Valve stem Valve cap O-ring 14*2 Cap slice O-ring 4*2 Cap seat O-ring 4*1.1 Housing Valve stem seat Housing cover Valve stem spring Bolt M6*8 Trigger Trademark label Bolt M4*8 Pin 3*22 Air Hammer 27621...
