- Page 1 Getz Equipment Innovators Part No.: 3G59558 Water Reclaim Tank Revised 11-8-2017...
-
Page 2: Limited Warranty
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. To obtain performance to the obligation of the warranty, write to Getz Equipment Innovators, 2320 Lakecrest Drive, Pekin IL 61554, USA for instructions. - Page 3 Getz Equipment Innovators Water Reclaim Tank (3G59558) Table of Contents Page ……………………………… Requirements, Drawing, Parts List ……………………………… Mounting and Installation Instructions ………………………………. Mounting and Installation Instructions, Continued ………………………………. Operating Instructions & Trouble Shooting...
- Page 4 Getz Equipment Innovators (3G59558) Power Source: A 120AC or power inverter if used in a mobile application Safety Requirements: Safety Glasses DRAWING 1 DRAWING 1 ITEM PART # DESCRIPTION ITEM PART # DESCRIPTION 1G0032 Tubing ½ I.D. Clear Vinyl 1G0588 Threaded Bushing CPVC 1 ¼...
- Page 5 Getz Equipment Innovators (3G59558) Mounting/Installation Instructions: 1. Remove zip ties to free up the hoses and wiring. 2. Mount the red plate roughly 15 inches down from the bottom of the top plate on the stand, using supplied 5/16 head SDS screws. You will need to remove the filter housing to access the bottom mounting holes.
- Page 6 Getz Equipment Innovators (3G59558) 4. Connect the hose with the brass garden hose fitting to the water inlet of the tester 5. Mount switch plate to the top plate of the hydro tester. 6. Plug the pump into a 120V receptacle. Make sure the switch for the pump is in the off position.
- Page 7 Getz Equipment Innovators (3G59558) Operating Instructions: 1. Fill water tank to the 5-gallon mark 2. To begin filling the cylinder, open all the valves on the tester and turn the switch on to start the water pump 3. Once the cylinder is full, keep the water pump on and follow the operating procedures for the hydrostatic tester.
