DF-C 63XXX & 61XXX Series User's Manual
Version 28.04.2019
DF-C 63XXX & 61XXX Series
AC Laboratory Power Supplies
by DSC-Electronics Germany
User's Manual
DSC-Electronics Germany • Georgstraße 36 • 53111 Bonn
DSC-Electronics Germany • Georgstraße 36 • 53111 Bonn
•
•
Georgstraße 36
53111 Bonn
Advertisement
Summary of Contents for DSC ELECTRONICS DF-C 63 Series
- Page 1 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 DF-C 63XXX & 61XXX Series AC Laboratory Power Supplies User’s Manual • • by DSC-Electronics Germany Georgstraße 36 53111 Bonn DSC-Electronics Germany • Georgstraße 36 • 53111 Bonn DSC-Electronics Germany • Georgstraße 36 • 53111 Bonn...
- Page 2 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 1. Connection Our devices are pre-configured to the power grid chosen with order (if not specified otherwise, our devices are manufactured for the EU power grid 230V 50Hz / 400V 50Hz). Subsequent adjustment after delivery is not possible. Connecting the device to an unsuitable power source will void any warranty.
- Page 3 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 2. General Please read through and understand this Operation Manual before operating the product. After reading always keep the manual nearby so that you may refer to it as needed. When moving the product to another location, be sure to bring the manual as well.
- Page 4 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 2.2 Safety Guidelines Please follow the safety guidelines when using and putting the device into operation in order to prevent safety risks and to ensure the correct operation of the product. Before connecting the device to the local power supply, make sure that the device is switched off.
- Page 5 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 3. Operation Instructions 3.1 Front Panel Description 63XXX Series Fig.1: Front Panel 63XXX Series (CV Version) Name Description Voltage Phase A Voltage set or actual value of Phase A Voltage Phase B Voltage set or actual value of Phase B Voltage Phase C Voltage set or actual value of Phase C...
- Page 6 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 3.2 Front Panel Description 61XXX Series Fig.2: Front Panel 61XXX Series (CV Version) Name Description Frequency Output frequency „Hz“ Voltage Voltage set or actual value Current Current actual value Power / Power Factor Power or Power Factor display Display Mode Active „A“...
- Page 7 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 3.3 Power ON Set the „ON / OFF“ switch to the ON position to turn on the device. The device is equipped with a soft-start delay which slowly charges the capacities in the power supply to limit the high inrush currents. After about 10 seconds, the power supply will switch into stand-by mode.
- Page 8 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 4. Optional: Analogue In- / Outputs Devices of the DF-C series can optionally be equipped with analogue inputs / outputs for setting and reading the output parameters. The analogue outputs / inputs are accessible via a labeled terminal block which is located either on the back, the front or behind the service door (depending on device model).
- Page 9 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 B). Output with potential to input (potential to input PE) Connections output L (1, 2, 3): Phase N: Neutral → Bridge to input N GND: Do not connect Connections input L1: Input phase 1 L2: Input phase 2 L3: Input phase 3 N: Neutral conductor...
- Page 10 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 Communication Protocol for DF-C63XXX Series Power Supplies Interface: RS-232 (9 pin female) / RS-485 (2 pin male) Command format: Asynchronous, 1start bit, 8 data bits, 1 stop bit Baud rate: 9600 Communication mode: ASIIC code, “X”...
- Page 11 DF-C 63XXX & 61XXX Series User’s Manual Version 28.04.2019 Communication Protocol for DF-C61XXX Series Power Supplies Command Function Response Description Output START Received The command is accepted Error The power supply is not in standby mode or output may be already active Output STOP Received...
