Phantom™ Tensioned Sports Cage
Installation Instructions
Parts List for Standard-Span Systems:
(1) Phantom™ Tensioned Sports Cage with three (3) top tensioning cables installed
(3) 2:1 Tensioning Assemblies with black nylon tensioning halyards
(3) Telescoping Reach Poles*
(3) Intermediate Cables (only for spans over 69' for 55' cage and 84' for 70' cage)
*Short-Span Systems omit Reach Poles and substitute the following:
(3) Anchor-End Blocks with black nylon anchoring halyards
(3) Rope Cleats
(6) 1/4"-20 x 2" Pan Head Screws
Additional Parts Required (must be supplied by customer):
(6) 3/8" steel eyebolts
(6) wall anchors to receive 3/8" eyebolts rated to support a minimum 250-lb. load
(6) wall anchors to receive 1/4" screws for Rope Cleats (Short-Span Systems only)
Tools Required for Set-up:
- pliers
- step ladder
- drill
Page 1 of 9
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Phantom Tensioned Sports Cage System
- Page 1 Phantom™ Tensioned Sports Cage Installation Instructions Parts List for Standard-Span Systems: (1) Phantom™ Tensioned Sports Cage with three (3) top tensioning cables installed (3) 2:1 Tensioning Assemblies with black nylon tensioning halyards (3) Telescoping Reach Poles* (3) Intermediate Cables (only for spans over 69’ for 55’ cage and 84’ for 70’ cage)
- Page 2 Initial Set-Up Procedure: 1. Determine which wall in your facility to define as the Tensioning Wall and which to define as the Anchoring Wall (see Figures 1-1 and 2-1, or 4-1 for Short-Span Systems). The Tensioning Wall will have the 2:1 Tensioning Assemblies attached to it with tensioning halyards hanging down to the floor.
- Page 3 6. Attach one Anchor-End Block to each eyebolt on the Anchoring Wall by unscrewing the clevis pin to remove the clevis (similar to procedure for Tensioning Blocks in Step 3). You may need pliers to loosen the pin initially. Hang the clevis onto the eyebolt, re-insert the pin to attach the Anchor-End Block, and tighten by hand.
- Page 4 This completes the set-up – you are now ready to begin using the cage. After the initial installation of the 2:1 Tensioning Assemblies, the set-up time required for the Phantom™ Tensioned Sports Cage System should be less than 5 minutes from storage to hitting! 4.
- Page 5 Have two people each take one set of steel rings and pull the net out of the container as they walk toward opposite walls. Thank you for your purchase of the Phantom™ Tensioned Sports Cage System! We hope you enjoy the simplicity and ease of use it provides.
- Page 6 7'-6" 7'-6" 7'-6" 7'-6" SEE CHART 14'-0" BELOW TENSIONING ANCHORING WALL WALL TENSIONING WALL MOUNTING HEIGHTS 55' Phantom™ Cage 70' Phantom™ Cage WALL SPAN HEIGHT WALL SPAN HEIGHT UP TO 80' 14'-0" UP TO 100' 14'-0" 80' - 90' 14'-6"...
- Page 7 STANDARD-SPAN ATTACHMENT DETAIL TENSIONING ANCHORING WALL WALL 2:1 TENSIONING ASSEMBLY REACH POLE BIT CLIP INTERMEDIATE CABLE (IF INCLUDED) TENSIONING CABLE BIT CLIP BIT CLIP TENSIONING HALYARD INSET "A" - TENSIONING BLOCK DETAIL CLEVIS PLEASE NOTE: IT IS NORMAL TO EXPECT 18" TO 24" OF SAG THROUGHOUT THE CAGE, ALTHOUGH LESS CAN BE ATTAINED BY INCREASING TENSION ON THE HALYARDS.
- Page 8 TELESCOPING REACH POLE INSTRUCTIONS REACH POLE SHORTENED FOR STORAGE USE TWIST-LOCK TO SECURE POLE POSITION FOR STORAGE/USE REACH POLE EXTENDED FOR USE...
- Page 9 SHORT-SPAN ATTACHMENT DETAIL TENSIONING ANCHORING WALL WALL 2:1 TENSIONING ASSEMBLY ANCHOR-END BLOCK BIT CLIP INTERMEDIATE CABLE (IF INCLUDED) TENSIONING CABLE BIT CLIP ANCHORING HALYARD BIT CLIP TENSIONING HALYARD ROPE CLEAT INSET "A" - TENSIONING BLOCK DETAIL CLEVIS PLEASE NOTE: IT IS NORMAL TO EXPECT 18" TO 24" OF SAG THROUGHOUT THE CAGE, ALTHOUGH LESS CAN BE ATTAINED BY INCREASING TENSION ON THE HALYARDS.
