Summary of Contents for Kingwon Wireless Video Link KWO1000
- Page 1 KWO1000 User Manual Model:1003+1004 Version:1.0...
-
Page 2: Table Of Contents
Contents About this manual Packing list Brief introduction Features Mechanic information Wireless HD Transmitter:1003 Wireless HD Receiver:1004 Interface information Wireless HD Transmitter:1003 Wireless HD Receiver:1004 Installation instructions Wireless HD Transmitter:1003 Wireless HD Receiver:1004 Product specifications OLED Screen Description Trouble Shooting Notices Description... -
Page 3: Packing List
FORWORD BRIEF INTRODUCTION - Please read this manual carefully before using this product The wireless transmission system can help a variety of video and retain it properly for future reference. transmission platform to achieve easy to carry,install fast,real zero-wiring,plug&play,change the traditional site wiring and - If there is any doubt or difficulty in the process of product usage, please feel free to contact us or the dealer. -
Page 4: Mechanic Information
MECHANIC INFORMATION TX:1003 RX：1004 5.8G Antenna Interface 5.8G Antenna Interface TALLY OUT TALLY IN V-MOUNT V-MOUNT Audio IN Audio out RS232 RS232 HDMI IN HDMI OUT OLED Screen OLED Screen CH Button CH Button Mode switch button Mode switch button OK Button SONY F-Type OK Button... -
Page 5: Interface Information
INTERFACE INFORMATION 7. RS232 TX:1003 1. MODE Button item Parameter Remark item Parameter Remark 3S long press Frequency witching MODE Button（SW2 ) Switch RTSP and point- 6S long press Default set with out to-point mode P12V ( reserved for 12V voltage output) 2. - Page 6 RX:1004 7. RS232 1. MODE Button item Parameter Remark Switch RTSP and point- 6S long press MODE Button to-point mode item Parameter Remark 2. CH Button Default set with out P12V item Parameter Remark ( reserved for 12V voltage output) 3S long press Frequency witching CH Button...
-
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS Note: When transmitter 1003 SDI output, the SDI output can only be used if SDI under loop output. TX: 1003 4. Audio input, transmitter 1003 connected to the microphone, 1. Install four 5dBi antennas on the transmitter (MODE key press 3S can switch the internal and external sound). install antennas Connect the microphone SDI monitor... - Page 8 3. For Receiver outputs, all HDMI/SDI interface can output synchronously. RX:1004 The Signal icon shows as a "X" in OLED when network between Transmitter 1. Install four 5dBi antennas on the receiver and Receiver disconnected or connecting; the Signal icon display properly when network connected."VIDEO"...
-
Page 9: Product Specifications
PRODUCT SPECIFICATIONS RX: 1004 TX: 1003 Operating 5190MHz，5230 MHz，5270 MHz，5310 MHz，5510 MHz，5550 MHz， Operating 5190MHz，5230 MHz，5270 MHz，5310 MHz，5510 MHz，5550 MHz， Frequency 5590 MHz，5630 MHz，5670 MHz，5755 MHz，5795 Mhz Frequency 5590 MHz，5630 MHz，5670 MHz，5755 MHz，5795 Mhz Antenna Mode 4*4 5dBi External antenna Antenna Mode 4*4 5dBi External antenna Modulation Mode... -
Page 10: Oled Screen Description
OLED SCREEN OLED SCREEN DESCRIPTION Indication Icon Model Status Contents Connecting Signal icon 1. AUDIO 2.Signal icon Signal bar Network connection success (Blank) No Video input VIDEO VIDEO 3.VIDEO Video source connected VIDEO successfully 4.Mode RTSP RTSP Video RTSP Streaming Mode Point to Point Transmitting (Blank) -
Page 11: Trouble Shooting
TROUBLE SHOOTING Troubles & Possible Reasons: Solutions: Video works but audio fails Troubles & Possible Reasons: Solutions: Restart transmitter Video input without audio Displaying “Link Connecting...” for long time The transmitter in external audio input mode Switch the transmitter to embedded audio Transmitter is not electrified. -
Page 12: Notices Description
NOTICES DESCRIPTION 1. Please do not plug or unplug the HDMI cables on transmitter& receiver when the transmission kit are powered on during normally using transmission kits. 2. Please connect the transmitter with video source and the receiver with monitor/TV via HDMI cables before power on the transmission kit. 3.
