EXA 96 - EXA NET 96
INSTALLATION GUIDE

COPYRIGHT

Electrex is a trademark of Akse S.r.l. All rights reserved.
It is forbidden to duplicate, adapt, transcript this document without Akse written
authorization, except when regulated accordingly by the Copyright Laws.

WARRANTY

This product is covered by a warranty against material and manufacturing defects for a 24
months period from the manufacturing date.
The warranty does not cover the defects that are due to:
• Negligent and improper use
• Failures caused by atmospheric hazards
• Acts of vandalism
• Wear out of materials
• Firmware upgrades
Akse reserves the right, at its discretion, to repair or substitute the faulty products
The warranty is not applicable to the products that will result defective in consequence of
a negligent and improper use or an operating procedure not contemplated in this manual.

RETURN AND REPAIR FORMALITIES

Akse accepts the return of instruments for repair only when authorized in advance. The
transport costs are at customer charge.

RE-SHIPPING OF REPAIRED PRODUCT

The terms for re-shipment of repaired products are ex-works, i.e. the transport costs are
at customer charge.
Products returned as detective but found to be perfectly working by our laboratories, will
be charged a fl at fee to account for checking and testing time irrespective of the warranty
terms.

SAFETY

This instrument was manufactured and tested in compliance with IEC 61010-1 CAT III -
300V class 2 standards for operating voltages up to 300 VAC rms phase to neutral.
In order to maintain this condition and to ensure safe operation, the user must comply with
the indications and markings contained in the following instructions:
• When the instrument is received, before starting its installation, check that it is
intact and no damage occurred during transport.
• Before mounting, ensure that the instrument operating voltages and the mains
voltage are compatible then proceed with the installation.
• The instrument power supply needs no earth connection.
• The instrument is not equipped with a power supply fuse; a suitable external
protection fuse must be foreseen by the contractor.
• Maintenance and/or repair must be carried out only by qualifi ed, authorized
personnel
• If there is ever the suspicion that safe operation is no longer possible, the instrument
must be taken out of service and precautions taken against its accidental use.
• Operation is no longer safe when:
1) There is clearly visible damaged.
2) The instrument no longer functions.
3) After lengthy storage in unfavorable conditions.
4) After serious damage occurred during transport
The instruments must be installed in respect of all the local regulations.

OPERATOR SAFETY

Warning: Failure to observe the following instructions may lead to a serious danger of
death.
• During normal operation dangerous voltages can occur on instrument terminals and
on voltage and current transformers. Energized voltage and current transformers
may generate lethal voltages. Follow carefully the standard safety precautions while
carrying out any installation or service operation.
• The terminals of the instrument must not be accessible by the user after the installation.
The user should only be allowed to access the instrument front panel where the
display is located.
• Do not use the digital outputs for protection functions nor for power limitation functions.
The instrument is suitable only for secondary protection functions.
• The instrument must be protected by a breaking device capable of interrupting both
the power supply and the measurement terminals. It must be easily reachable by the
operator and well identifi ed as instrument cut-off device.
• The instrument and its connections must be carefully protected against short-circuit.
Precautions: Failure to respect the following instructions may irreversibly damage to the
instrument.
• The outputs and the options operate at low voltage level; they cannot be powered by
any unspecifi ed external voltage.
• The application of currents not compatible with the current inputs levels will damage
to the instrument.
Further documentation may be downloaded from our web site www.electrex.it.
This document is owned by company AKSE that reserves all rights.

DECLARATION OF CONFORMITY

Akse hereby declares that its range of products complies with the following directives EMC
2014/30/EU, 2014/35/EU and complies with the following product's standard CEI EN
61326 - Ed. 2.0 (2012) – IEC 61326 - Ed. 2.0 (2012), CEI EN 61010- Ed. 3 (2010) – IEC
61010- Ed. 3 (2010). The product has been tested in the typical wiring confi guration and
with peripherals conforming to the EMC directive and the LV directive.

MECHANICAL CHARACTERISTICS

Case
Self-extinguishing plastic material class V0
Protection degree
IP40 on front panel, IP20 terminals side
Size
96 x 96 x 72 mm

VOLTAGE INPUT

Direct insertion
Up to 300 Vrms phase-neutral or 520 Vrms phase to phase
With external VT:
Primary: programmable (max. 400 kV)
Secondary: programmable (max. 300 V)
Overload: 900 Vrms phase to phase for 1 sec
Aux. power supply
85/265Vac +/- 10% 50/60Hz
Self consumption:
< 2 watt

MODELS

PFNE9-11109-000
EXA RJ45 96 85-265V
ENERGY ANALYZER & DATA MANAGER
PFNE9-11709-0M0
EXA RJ45 96 85÷265V
ENERGY ANALYZER & DATA MANAGER
PFNE9-11509-110
EXA RJ45 96 85÷265V
ENERGY ANALYZER & DATA MANAGER
PFNE9-11509-A10
EXA NET 96 WEB LOG 8 CHARTS 85÷265V
ENERGY ANALYZER & WEB DATA MANAGER
PFNE9-11A09-110
EXA NET WI-FI EDA 96 WEB LOG 8 85÷265
ENERGY ANALYZER & WEB DATA MANAGER
PFNE9-11509-F10
EXA NET 96 WEB LOG 8 FULL 85÷265V
ENERGY ANALYZER & WEB DATA MANAGER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Electrex EXA 96 and is the answer not in the manual?

Questions and answers

Summary of Contents for Akse Electrex EXA 96

  • Page 1 • Wear out of materials • Firmware upgrades Akse reserves the right, at its discretion, to repair or substitute the faulty products The warranty is not applicable to the products that will result defective in consequence of a negligent and improper use or an operating procedure not contemplated in this manual.
  • Page 2 SETUP Using the + and - corresponding keys select the type of insertion Press Menù/Enter key. desired (default: 3P-4W / three phase STAR type); then press the key corresponding to the Sav menu voice in order to save the setting. 3P-4W 1P-2W 2P-2W...
  • Page 3 Using the keys corresponding to Up DHCP is by default disabled. and Down select CTS; then press the Use the keys corresponding to Up key corresponding to the Edt menu and Down to select the desired voice; voice in order to edit the secondary then press the key corresponding to NET MASK 255.255.255.0...
  • Page 4 In order to edit the GATEWAY address (if needed) use the keys corresponding to Up and Down to select GATEWAY; then press the key IP ADDR 192.168.27.1 corresponding to the Edt menu voice. NET MASK 255.255.255.0 GATEWAY 127.0.0.1 DHCP DISABLED <...
  • Page 5 Via Aldo Moro, 39 42124 Reggio Emilia Italy Made Italy Tel. +39 0522 924 244 Fax +39 0522 924 245 info@akse.it www.akse.it Pensato, progettato e prodotto in Italia Subject to modifi cation without notice. P.I. 01544980350 R.E.A. 194296 Cap.
