Installation and
commissioning manual
MDX-I/O LITE
Additional I/O module
POWERDRIVE MD2/FX
Part number: 5215 en - 2017.08 / c

Advertisement

Table of Contents
loading

Summary of Contents for Leroy-Somer Nidec MDX-I/O LITE

  • Page 1 Installation and commissioning manual MDX-I/O LITE Additional I/O module POWERDRIVE MD2/FX Part number: 5215 en - 2017.08 / c...
  • Page 2 NOTE LEROY-SOMER reverses the right to modify the characteristics of its products at any time in order to incorporate the latest techno- logical developments. The information contained in this document is therefore liable to be changed without notice. CAUTION For the user’s safety, the variable speed drive to which the module covered by these instructions is fitted must be connected to...
  • Page 3 SAFETY AND OPERATING INSTRUCTIONS FOR VARIABLE SPEED DRIVES (In accordance with the low voltage directive 2006/95/EC) Throughout the manual this symbol warns of consequences which may arise from inappropriate use of the drive, since electrical risks may lead to material or physical damage as well as constituting a fire hazard. 1 - General Depending on their degree of protection, variable speed drives Variable speed drives contain parts which are sensitive to...
  • Page 4 NOTE MDX-I/O LITE Installation and commissioning manual 5215 en - 2017.08 / c...
  • Page 5: Table Of Contents

    CONTENTS 1 - GENERAL INFORMATIONS ..........................6 1.1 - General ................................ 6 1.2 - Dimensions ..............................6 2 - INSTALLATION ..............................7 2.1 - MDX-I/O LITE module ..........................7 2.2 - MDX-I/O LITE module combined with a CM-Fieldbus option ............... 7 2.3 - Grounding bracket ............................
  • Page 6: General Informations

    GENERAL INFORMATION 1 - GENERAL INFORMATION 1.1 - General The MDX-I/O LITE module is used to increase the number of drive inputs and outputs. This option is fully configurable. Details of functions: - 1 analog input - 2 analog outputs - 1 temperature sensor input - 2 digital inputs - 1 digital output...
  • Page 7: Installation

    INSTALLATION 2 - INSTALLATION 2.2 - MDX-I/O LITE module combined with a CM-Fieldbus option • Before carrying out any work on the drive, disconnect and padlock the isolating switch in the 2 options are needed: switchboard. • After the drive is switched off, the external control circuits MDX -I/O LITE module CM-Fieldbus can retain a dangerous amount of voltage.
  • Page 8: Connections And Characteristics

    CONNECTIONS AND CHARACTERISTICS 3 - CONNECTIONS AND CHARACTERISTICS • Check that the DC bus has discharged before any work is carried out (wait at least 10 minutes after powering down). For the safety instructions relating to the drive, please refer to the manual supplied with the product. •...
  • Page 9: Characteristics

    CONNECTIONS AND CHARACTERISTICS 3.2 - Characteristics • PX4 connector Analog input 4 Facory setting No assignment ± 10V bipolar analog voltage in common mode or Input type unipolar current (0 to 20mA, 4 to 20mA) Resolution 11 bits + sign Sampling period 2 ms Input filter bandwidth...
  • Page 10: Commissioning

    COMMISSIONING 4 - COMMISSIONING • The drives use software which is adjusted by parameters. The performance levels obtained depend on the parameter setting. Inappropriate settings may have serious consequences for personnel and machinery. • The drive parameters must only be set by appropriately qualified and experienced personnel. 4.1 - General The MDX-I/O LITE module parameters are set using menu 19.
  • Page 11 COMMISSIONING • Analog input and outputs AI4 current loop Analog AI4 signal input 4 type Analog destination 19.41 19.42 input 4 19.45 filter 0-20 mA Analog X - 1 19.40 20-0 mA input AI4 00.00 scaling 4-20 mA with detection 20-4 mA with 19.43 detection...
  • Page 12: Explanation Of Parameters

    COMMISSIONING 4.3 - Explanation of parameters 19.20 : Digital output 2 invert Adjustment range : No (0) or Yes (1) Factory setting : No (0) : Option type 19.01 Format : 8-bit This parameter is used to invert the state of the digital output. Adjustment range : 0 to 512 No (0): not inverted.
  • Page 13 COMMISSIONING : DI6 input destination 19.32 : AI4 current loop 19.42 Adjustment range : 00.00 to 21.51 : 00.00 Factory setting Adjustment range : Active (0) or Format : 16-bit Lost (1) This parameter is used to select the digital input destination. Format : 8-bit In 4-20 mA or 20-4 mA current mode with or without detection,...
  • Page 14 COMMISSIONING : Analog output 2 19.56 : Analog output AO3 19.50 filter level Adjustment range : None (0), 4 ms (1), Adjustment range : ±100.00 % 8 ms (2), 16 ms(3), 32 ms (4). Format : 16-bit Factory setting : 8 ms (2) Indicates as a percentage the analog output level, before Format : 8-bit...
  • Page 15: Diagnostics

    DIAGNOSTICS 5 - DIAGNOSTICS Trip name Cause Remedies DO2 MDX-I/O The DO2 output load current is > 200mA Check that DO2 is not short-circuited overload Communication problem between the drive and the MDX-I/O Check the MDX-I/O LITE mounting MDX-I/O LITE option serial link 24V MDX-I/O The 24V load current is too high...
  • Page 16 IMP210NO133 Moteurs Leroy-Somer Headquarter: Boulevard Marcellin Leroy - CS 10015 16915 ANGOULÊME Cedex 9 Limited company with capital of 65,800,512 € RCS Angoulême 338 567 258 www.leroy-somer.com...
