Summary of Contents for Digital Watchdog DW-708N Series
- Page 1 ¢ ¡ £ ¥ ¤ § ¦ ¨ £ © £ ¥ ¤ ¥ § ¦ ¤ ! ¥ " # ¤ ¢ ¡ $ # % ! © % ¢ " # & ! ¥ ¡ ' ( # £ § ) % ! © £ 0 " 1 ¦ 2 £ ! 3 1 ¤ ¢ # 4 5 £ ¥ £ ¢ 6 ¢ # ¤ ¢ # § ' 7 ) % ! © ) 8 "...
- Page 2 6/7 Series Manual 6/7 Series Manual If you require additional copies of this manual, please print the manual contained in the CD provided with your purchase.
- Page 3 Thank you for purchasing this product. This DVR is produced by the most advanced technology and its quality is guaranteed by strict reliability and compatibility testing. This product manual provides necessary information for the correct use of this product and also contains some useful tips. Please read this manual thoroughly before using in order to prevent possible breakdown due to any mishandling.
- Page 4 Please be aware of the following precautions before installing the DVR. • Avoid positioning the DW-6/7 series in any place where the unit may come into contact with moisture, dust, or soot. • Avoid placing in direct sunlight or near heating appliances. •...
- Page 5 The following are warnings and cautions for the safety of the users and for the prevention of any property damage. Please read below thoroughly. Warning and Caution signs If you are not aware of this If you are not aware of this Warning Caution warning, you may be seriously...
- Page 6 Warning Do not attempt to disassemble, repair, or modify Install the system in a cool place without direct sunlight and always maintain room temperature. the system on your own. It is extremely dangerous due to high voltage running through the system. Avoid candle light and heat-generating devices such as heater.
- Page 7 Warning When the system’s battery is depleted, you must If the system’s HDD has exceeded its life span, change it with the same or equivalent type of you may not be able to recover any data stored battery specified by the manufacturer. Depleted inside the HDD.
- Page 8 Caution Do not install the system in a place with high Install the system in a place with appropriate magnetic, electric wave, or wireless devices such moisture and temperature level. as radio or TV. • Avoid installing the system with high (over 40 •...
- Page 9 Caution The system can be damaged from a strong impact The outlet must be placed on the ground. or vibration. Avoid throwing objects within the vicinity of the system. If there is strange sound or smell, unplug the Avoid direct sunlight or any heating appliances. power cable immediately and contact the service Center.
- Page 10 Please check to make sure the following equipment are included when you purchased DVR. If any items are missing, contact your dealer. (The user manual will be included either inside the product software CD or a quick Manual including important contents.) (Manual/Software) Remote Controller Manual (Site/Center)
-
Page 11: Table Of Contents
Chapter 1. Introducing your real time DVR 1.1 Front Panel………………………………………..……………………………………………………………………15 1.2 Rear Panel…………………………………………………..……………………………………………………18 1.3 Description of the Remote Controller…..……………………………………………………………………23 Chapter 2. Installation 2.1 Checking install environment……………………………………………………………………………………24 2.2 Pan/Tilt Connection………………………………………………………………………………………..………26 2.3 KEYBOARD Controller……………………….…………………………………………………………………27 2.4 Connecting LAN/PSTN Communication Lines………………………………………………….……………28 2.4.1 LAN and Dedicated Line Connection…………………………..…………………………………28 2.4.2 PSTN (telephone line) Connection (optional)………………………………………………………29 2.5 External Alarm In Connection (Input)………………………………………...…………………………………30 2.6 Alarm Out Port Connection (Output)………………………………………..…………………………………31... - Page 12 4 . 4 N e t w o r k … … … … … … … … … … … … … … … … … . … … … … … … … … … … … … … … … … … … … … 5 5 4.4.1 DDNS Setup…………………………...………………..…………………..…………………………………55 4.4.2 Network Setup………………………………………..…………………………………………………………56 4.4.3 Network Test………..…..…………….…………….………………………..…………………………………57...
- Page 13 Chapter 6. Backup 6.1 Video Backup ……………………………………………………………………………………..……………90 6.2 Still Image Backup………………………..………………………………………………………..…………91 6.3 Media Format…………………….……………..………………………………………………..…………92 Appendix 1. KDB Viewer……………………………………………………………………….……………………………………94 1.1 How to run Viewer………………………………..……………….…………..…………………………………94 1.2 Viewer main screen……………………………………………..……………………………………………97 2. WebDVR………………..………………………………………………………………………………………………100 3. Watermark Checker………………………………………….………………………………………………………104 4. Adding HDD………………………………………………………………………………….………………………106 4.1 Installing new HDD………………………………..………….…………..…………………………………106 4.2 Checking HDD Database………………………………………..……………………………………………107 5.
-
Page 14: Chapter 1. Introducing Your Real Time Dvr
1. Introducing your real 1. Introducing your real time DVR time DVR... -
Page 15: Front Panel
1.1 Front panel 1.1 Front panel The following describes the keys and ports on the front of the system and their functions: [Figure 1-1. System front view(DW-716T)] [Power] - Use this button to shutdown the DVR. - When the button is pressed a password menu will pop-up and password details should be entered click [OK] and the DVR will turn off. - Page 16 [Directional keys] - Use to move through the menu options in Setup or Search mode. - When controlling P/T/Z camera, press the directional keys to move the camera. - When searching recorded image, you can adjust the size of the image using up and down directional key.
- Page 17 [LED Status Panel] -The LED Status Panel displays the current operation state of the DVR. REC : The light indicates that the DVR is recording. BACKUP : The light indicates when a backup is in progress. NETWORK : The light indicates that a client is connected remotely. AUDIO SEL : The light indicates when the audio select function is active.
-
Page 18: Rear Panel
1.2 Rear panel 1.2 Rear panel The following describes keys and ports on the rear part of the system and their functions. [Figure 1-2. System rear view(DW-716T)] [Power Connector] 110V ~ 220V, • Power cable input, for system main power supply. [Caution] •... - Page 19 [ALARM IN Port] • This is the input port for sensor devices. •The system supports NC(Normal Close) and NO(Normal Open) sensor types. [ALARM OUT Port] • This is the output port for alarm out devices . • The system supports NC(Normal Close) and NO(Normal Open) control types. [Caution] •...
- Page 20 [IEEE 1394] - To use an IEEE1394 external storage as the ‘Recording device’ or ‘Backup device’. [LAN] - Ethernet 10/100 connection port for connection the system through network. - To access the network through the network hub, connect the network cable to the LAN port.
- Page 21 [Note] Removable Disk The table below lists compatible USB disks. If you want to use other removable disk, it should be compatible with Linux 2.6.0 or over. Other USB disk may not work properly. It is recommended that you confirm through the manufacturer the Linux compatibility of the removal disk you wish to purchase.
-
Page 22: Description Of The Remote Controller
1.3 Description of the Remote controller 1.3 Description of the Remote controller The following describes the remote controller buttons, which have the same functions as the buttons on the front panel of the system: MENU SEARCH NUMBER BACKUP Shuttle(+) Shuttle(-) Directional Keys Enter Jog(+) -
Page 23: Chapter 2. Installation
2. Installation 2. Installation... -
Page 24: Checking Install Environment
2.1 Checking install environment 2.1 Checking install environment You should pay attention to the following before you use the product. • Do not use it outdoor. • Do not place water or liquid near the connection part or the product. •... - Page 25 Please keep the following instructions for rack-mounting the DVRs to proceed with the installation. 1. The rack on which the DVR is mounted should not be sealed off. 2. And it also can allow air circulation through the vent. 3. As shown in the Figure 2, we recommend you to heap the product with other DVR s or use rack-mount devices at certain space, or install a vent system to accommodate airflow.
-
Page 26: Pan/Tilt Connection
2.2 Pan/Tilt Connection 2.2 Pan/Tilt Connection RS-485 Signal Cable Connection Port (Used for connecting Speed Dome camera and RX-Receiver) [Caution] • Please beware of (+ve) and (-ve) poles of the signal cable when connecting. A wrong connection may cause malfunction of the system. •... -
Page 27: Keyboard Controller
2.3 Keyboard Controller 2.3 Keyboard Controller RS-485 Signal Cable Connection Port (Used for connecting External devices such as keyboard or POS system) [Caution] • Please beware of (+ve) and (-ve) poles of the signal cable when connecting. A wrong connection may cause the system to malfunction. -
Page 28: Connecting Lan/Pstn Communication Lines
2.4 Connecting LAN/PSTN Communication Lines 2.4 Connecting LAN/PSTN Communication Lines 2.4.1 LAN and Dedicated Line Connection (Used for connecting to DW-6/7 series UTP port) Center PC Router Internet Network & Local Intranet Network (Dedicated Modem) (Used for connecting UTP port of the LAN Card) Dedicated Line Router... -
Page 29: Pstn (Telephone Line) Connection (Optional)
2.4.2 PSTN (telephone line) Connection (options) (Not available in Europe) MODEM (DW-6/7 series RS-232 connection) MODEM Center PC... -
Page 30: External Alarm In Connection (Input)
2.5 Alarm In Port Connection (Input) 2.5 Alarm In Port Connection (Input) Alarm In Connect one of the two signal lines from the sensor (infrared sensor, magnetic) to COM port, and connect the other signal line to the desired Alarm-In number. [Caution] Use a separate adapter to supply power to each sensor. -
Page 31: Alarm Out Port Connection (Output)
2.6 Alarm Out Port Connection (Output) 2.6 Alarm Out Port Connection (Output) Alarm Out Alarm Light, Amplification Siren, External Power ( DC12V ) External Relay, Etc. • During automatic control of an external sensor, the Alarm-Out output port is “interworked” (the value set in “Set Alarm-In/Alarm-Out”... -
Page 32: Chapter 3. Live
3. Live 3. Live... -
Page 33: Screen Layout
3.1 Screen layout 3.1 Screen layout 50.0% [Camera number] [Audio recording status] Displays camera number. • Shows audio recording enabled. [Camera name] [HDD Capacity] Displays camera name. • Display HDD used by percentage. [Recording status] [HDD Status] Displays camera recording mode enabled. •... -
Page 34: Enabling Full Screen And Sequence Mode
3.2 Enabling full screen and sequence mode 3.2 Enabling full screen and sequence mode [To Select 16 way split screen] • Press the 16 way split screen button to view all cameras on one screen (DW-616T/716T). [To Select 9 way split screen] •... -
Page 35: Pop-Up Menu
3.3 POP UP MENU 3.3 POP UP MENU • You can use this menu by pressing mouse-right button. Items shown on the pop-up menu are identical with buttons at system’s front panel. The benefit of this menu is that user can operate DVR system by simply using mouse. - Page 36 Names Features Playback button • It start search mode. Mute button • Adjust select MUTE if you do not wish to listen to live audio.
-
Page 37: Pan/Tilt Camera
3.4 Pan/Tilt Camera 3.4 Pan/Tilt Camera 3.4.1 Switching to Pan/Tilt control mode [Pan/Tilt camera control] • Select the camera channel connected to the P/T/Z camera by using the mouse or camera number keys on the front panel. This will display the channel in full screen mode. -
Page 38: Pan/Tilt Camera Control
3.4.2 Pan/Tilt Camera Control In P/T/Z menu, you can switch the P/T/Z camera controls to manual control, as well as changing Zoom, Focus, and Auto Pan settings. [Figure 4-3. P/T/Z menu] [P/T/Z model] [Preset] Displays the P/T/Z camera model. • If you have a Speed Dome camera configured with presets, selection of a numbered button will move the camera to that preset position (see [Mode Select] [P/T/Z function buttons]... -
Page 39: Supported Pan/Tilt Camera List
3.4.3 Supported Pan/Tilt Camera List Manufacture Modal Name Zoom Focus Preset Manual IRIS Control Speed Speed other function LG-MULTIX 9600 PELCO PELCO-SD 2400 DONG-YANG DRX-501A 2400 HONEYWELL GC-755 9600 ZC-SD622JF 19200 SAMSUNG Samsung PTZ 9600 camera SAMSUNG Techwin 9600 ORION KRE-303 2400 ORION... -
Page 40: Alarm Out - Manual Control
3.5 ALARM OUT – Manual Control 3.5 ALARM OUT – Manual Control 3.5.1 Switching to Alarm Out Mode If you wish to use the control devices manually, select the 16-splitscreen mode in Surveillance mode, then press Enter key. You will then be able to select the control devices you wish to use manually. -
Page 41: Chapter 4. System Setup
4. System setup 4. System setup... -
Page 42: Accessing Setup Mode
4. System Setup 4. System Setup 4.1 Accessing Setup mode To go to the system setup screen, click the [MENU] button on the front of the system. The login window will then be displayed, enabling the inputting of login ID and password as shown below: •... -
Page 43: Motion Detection
4.2.1 Motion detection • Set the motion detection area, sensitivity and alarm for each camera video. Press the [Enter] button after moving the cursor on the camera to be set. [Motion Link Setting] • You can set a motion-link recording for each camera. •... - Page 44 [Camera] • Use the jog/shuttle on the system to select other cameras for set up. [Full Motion] • To set the whole channel screen to motion-detection area, switch the [Full Motion] option to “ON”. To cancel the whole screen from motion-detection area, switch the option to “OFF”. [Sensitivity] •...
-
Page 45: Schedule
4.2.2 Schedule • Set the recording type for each camera over a 24 hour period. [Camera] • Use the mouse wheel or the Jog/Shuttle to select the camera to change its schedule. [Time] • Change the recording time in hourly intervals •... -
Page 46: Quality/Resolution
4.2.3 Quality/Resolution • The details of the Quality/Resolution menu are as follows: 4.2.3.1 Normal REC Setting • You can set the recorded mode values for normal DVR recording. [Resolution] • Set the screen size for recording. Video Full D1 Half D1 Source NTSC 704x480... -
Page 47: Alarm Rec Setting
[Quality] • Select the recording video quality. Set between the option of LOW, NORMAL, HIGH and BEST. [Frame] • Select the number of frames for recording. The number of frames refers to the number of screens recorded per second (fps). [Bit Rate] •... -
Page 48: Network Rec Setting
[Bit Rate] • Select bit rate to fit network bandwidth. • VBR transfer high quality image to remote software, but network transfer speed can be slow. • CBR transfer middle quality image to remote software, but network transfer speed can be fast. [Audio] •... -
Page 49: Alarm Rec Time
[Bit Rate] • Select bit rate to fit network bandwidth. • VBR transfer high quality image to remote software, but network transfer speed can be slow. • CBR transfer middle quality image to remote software, but network transfer speed can be fast. [Apply All] •... -
Page 50: Property
4.2.4 Property • Change the color, brightness and contrast for each camera. [Camera] • Select which channel to set up. [Color/Bright/Contrast] • You can set the color, brightness and contrast of the selected camera. • The adjustment can be made from ‘0’ to ‘255’ using the jog/shuttle or mouse wheel. [Default] •... -
Page 51: Camera Menu
4.3 Camera menu • The details of the camera menu are as follows: 4.3.1 Channel Setting • Set camera status and name, add PTZ protocol to camera. [Camera] • Select the channel to set up the camera. [Camera Available] • Set the use of the selected camera between Enable/Disable and Secure using the mouse scroll wheel or jog/shuttle. -
Page 52: Alarm In Setting
[Camera Name] • The camera name of the selected channel can be set. A virtual keyboard appears if you press the Enter button. • Characters can be input one by moving the cursor. You can input up to 10 characters. If you press “Shift”, you can input the uppercase letters and number keys. -
Page 53: Alarm In Out Link
4.3.3 Alarm In Out Link • Link Alarm In and Alarm Out devices, and activation time. [Alarm In] • Select the Alarm In number for configuration. [Alarm Out] • You can link a Alarm In with Alarm Out devices. When a Alarm In is triggered, the lined Alarm Out device(s) will automatically activate. -
Page 54: Spot Out Camera Link
[Alarm In] • Select the Alarm In number for configuration. [Camera] • Choose the cameras you wish to link with the selected Alarm In. • When the Alarm In is trigged, the linked camera(s) will automatically begin recording. 4.3.5 Spot Out Camera Link •... -
Page 55: N E T W O R
4.4 Network • The details of the network menu are as follows : 4.4.1 DDNS Setup • DDNS Setup function allows you to use the dynamic IP address connected to the system as if it is a fixed IP Address. [ID] •... -
Page 56: Network Setup
4.4.2 Network Setup • Input Network connection details for remote access. [Network] • The system supports network connection using Static IP, as well as DHCP, ADSL connections. The other option is to select no network when not networking the DVR. [ID/Password] •... -
Page 57: Network Test
[Subnet Mask] • Input the subnet mask address for the system. [Gateway] • Input the gateway address for the system. 4.4.3 Network Test • Check the DVR is connected to the network. [Assigned IP] • Assigned IP display the system’s IP address used for remote backup and remote monitoring. [Connection Status] •... -
Page 58: Ntp Setup
4.4.4 NTP Setup • Synchronize time to a server with the NTP(Network Time Protocol). [Primary Address] & [Secondary Address] • Sets the NTP server address. [Connection Status] • To check the connection status with the NTP server in [Primary Address] or [Secondary Address] field, click on “Test”... - Page 59 * NTP Server List Area NTP Server Address Worldwide pool.ntp.org Asia Asia.pool.ntp.org Europe Europe.pool.ntp.org North America North-america.pool.ntp.org Oceania Oceania.pool.ntp.org South America South-america.pool.ntp.org Austria at.pool.ntp.org Australia au.pool.ntp.org Belgium be.pool.ntp.org Canada ca.pool.ntp.org Switzerland ch.pool.ntp.org Chile cl.pool.ntp.org Germany de.pool.ntp.org Denmark dk.pool.ntp.org Spain es.pool.ntp.org Finland fi.pool.ntp.org France...
-
Page 60: Emergency Notification
4.4.5 Emergency Notification • When an emergency Alarm in event has occurred, the Emergency Notification either delivers the emergency message and video to the IP address with the CMS or transmits an e-mail to a designated e- mail address. • Press the “CMS” button to set the Emergency Notification by CMS. [Alarm In Enable/Disable] •... - Page 61 • Click the “E-mail” button to display the email transmission settings. • To receive emergency notification via e-mail, set the SMTP address, sender’s e-mail address, recipient’s mail address. [Alarm In Enable/Disable] • You can select/unselect the Alarm In to be used as an emergency Alarm In. •...
- Page 62 [To] • Enter the user accounts to receive the e-mail message. The following screen will appear if the “Enter” button is pressed. • The virtual keyboard window appears by pressing the “New”, enter the recipient address. When registering the address to the recipients list, press the after selecting the address from the address book list.
-
Page 63: System Setup
4.5 System Setup • The details of the system setup menu are as follows : 4.5.1 User Management • The details of the User Management menu are as follows:... -
Page 64: Password Setup
4.5.1.1 Password Setup • Change the password for the administrator. [Old Password] • The default password is not designated first time. This must be used when changing the password. [New Password] • A virtual keyboard will appear if the “Enter” button is pressed. -
Page 65: Group Setup
[User Add] Enter “User ID” and “Password” for the User. Then select the group that the user has permission, there are three options “Group1”, “Group2”, and “Group3”. • If you press “Add”, the entry is registered and displayed in the user list on the right. •... -
Page 66: Site Setup
4.5.2 Site Setup • The details of the Site Setup menu are as follows: 4.5.2.1 Regional Setting • The regional settings menu is for change the DVR time and date to fit the time zone and language to the installation country. Also there is the option for changing the site code which is essential for network connection. - Page 67 [Site Code] • Setup the ID code to the system, for identifying the system when multiple systems are connected through network and to increase network security. • The Site Code comprise 6 digits. When entering Site Code, you can enter a maximum of 6 digits. [Date Type] •...
-
Page 68: Osd Dwell Time
4.5.2.2 OSD Dwell Time • Configure the setup of the on screen display (OSD) and the dwell time for the camera sequencing. • You can turn the display settings in Surveillance mode on or off, such as [OSD All], [Event Monitoring Duration], [Camera Name], [Recording], [Audio], [P/T/Z], [Backup], [Data/Time], [HDD Space], [Dwell Time], [Transparency] and [Bad Sector Dwell time] displays. -
Page 69: Remote Control Id
4.5.2.3 Remote Control ID • In the situation where multiple DVR are using their own remote controller the Remote controller ID menu allows configure each controller to have it’s own ID. [Remote ID] • In order to control the DVR with a remote controller, set the DVR and the remote control ID the same. •... -
Page 70: Live Audio
4.5.2.5 Live Audio [Audio Live Channel] • Select channel for live audio output. • The units supports only one channel live audio output at a time. [Mute] • Check [Mute] button to disable audio output on audio channel. -
Page 71: Software Upgrade
4.5.3 Software Upgrade • View the current software and upgrade to new version. [Package select] • You can upgrade the system program by using a portable storage device to be recognized by DW-6/7 series. The upgrade package must be in a folder called “update”. Connect the storage device containing an upgrade package to the USB port, then press [Select]. -
Page 72: Schedule
4.5.4 Schedule • The details of the Schedule menu are as follows: 4.5.4.1 Backup Schedule • You can set up a system backup schedule so that the system will automatically save backup copies of specific recording times. • Backup Schedule programs the system to save a backup copy of the recorded data to a designated storage device set in the schedule. -
Page 73: Adding Backup Schedule
4.5.4.1.1 Adding Backup schedule [Add] •To add a backup schedule to the list, select [Add] button. • To add a backup schedule, you must set the [Start Time] and [End Time], [Target Drive], and [Rotate] options. [Backup Schedule List] • You will see the added schedule on the backup Schedule list. -
Page 74: Deleting Backup Schedule
4.5.4.1.2 Deleting Backup Schedule [Delete] • To delete a schedule from the list, select the schedule you wish to delete by using the directional keys and Enter key. Then select [Delete] button to delete the schedule. 4.5.4.2 System Restart [System Restart Time] •... -
Page 75: Storage
4.5.5 Storage • The details of the Storage menu are as follows: 4.5.5.1 Backup Schedule • Setup external storage for backup device or extended recording storage device. [External Storage] • Display external storage device type. [Used as] • External Storage can serve as a backup device or the recording device. •... -
Page 76: Hard Disk Format
4.5.5.2 Hard Disk Format • The table shows the system’s built-in HDD’s and their information. You can install up to HDD into the system. • Form the table, you can select the HDD you wish to format, then select [OK] button. •... - Page 77 [Caution] Checking HDD Data Please, pay attention to following information to minimize the change of losing HDD data. • Remember that you should protect HDD from any impact or misuse as this may cause damaged. • The Manufacturer is not responsible for missing data or defects caused by the user’s miss handling.
-
Page 78: System Info
4.6 System Info • The details of the System Info menu are as follows : 4.6.1 Log Info • This function shows as series of logged tasks made in operating the DVR system and when the system runs abnormally, it allows finding the error easily so that the problem can be fixed. •... - Page 79 [Time] • If the [Time] button is pressed, the following screen appears. • Select [Time] to change time to view log information recorded on different date/time. • Change [Start Time] and [End Time] using the mouse and mouse wheel or the directional keys and the jog/shuttle, then press [OK] button.
- Page 80 * System Log List Log Type Log Details Description • REC C(Channel) C REC START/STOP Continuous Recording Start/Stop C(Channel) A REC START/STOP Alarm In Recording Start/End C(Channel) M REC START/STOP Motion Recording Start/End • System SYSTEM START/STOP System Power ON/OFF SYSTEM NET TIMESET System Time Change SYSTEM SHUTDOWN...
-
Page 81: Factory Default
4.6.2 Factory Default • Restore the all settings to the original default settings. It is also possible to input and export setting from other DW-6/7 series. [Factory Initialization] • Returns all the settings back to the original default condition. Click on the OK button using the mouse or directional buttons on the front to select the factory initialization. -
Page 82: Chapter 5. Search
5. Search 5. Search... -
Page 83: Accessing Search Mode
5. Search 5. Search 5.1 Accessing Search Mode To go to the Search screen, click the [SEARCH] button shown in the front of the system screen. The login window will then be displayed, enabling the inputting of login ID and password as shown below. •... -
Page 84: Selecting Date And Time
5.3 Selecting date and time • To select the date you wish to view, use the directional keys to select button, then press Enter. This will display a calendar. • Press the arrow buttons ( ) above the calendar to change year/month. •... -
Page 85: Selecting Cameras And Changing Search Bar Line
5.4 Selecting cameras and changing search bar line [Selecting cameras] • You can select the cameras to be selected. After pressing the Camera1 to Camera16 buttons on the front panel or moving the cursor to the channel to be selected, the cameras can be selected by pressing the [Enter] button. -
Page 86: Audio Output
5.5 Audio Output • To select the date you wish to view, use the directional keys to select button, then press Enter. This will display a calendar. [Audio] • The system can play the video with recorded audio, provided an audio recording device is connected to that channel. -
Page 87: P L A Y B A C
5.6 Playback • If you press [Play] after selecting the channel and date to be searched, the video is played. [Playback buttons ] : Move to the first recorded image for that date. : Reverse Play. : Stop. : Forward Play. : Move to the last recorded image for that date. -
Page 88: E V E N T S E A R C
5.7 Event Search • Event search function can be used to search and display data recorded by motion, or alarm events. •The following Event Search screen will appear if the [Event] button is pressed. [Start Time] and [End Time] • Set the Event search time. •... -
Page 89: Chapter 6. Backup
6. Backup 6. Backup... -
Page 90: Video Backup
• From Search screen display, select [BACKP] button to save a backup copy of the recording using USB HDD, or a portable hard drive such as USB memory stick. The backup files can be saved as SFX, BMP, JPEG, or KDB (Data Base) formats. 6.1 Video Backup [Backup mode –... -
Page 91: Still Image Backup
6.2 Still Image Backup • To back up still images, replay the recorded image first and press the Enter once you reach the scene that you would like to back up. The initial search screen in then converted into the initial search screen. [Backup mode –... -
Page 92: Media Format
6.3 Media Format • On Backup Mode to format external storage equipment (USB, IEEE1394) or set partition, select the media (USB or IEEE1394) then click the [Format] button [Format] • Click [Format] button after selecting the storage equipment which you want to format on media list. [Establishing partition ] •... - Page 93 6. Appendix 6. Appendix...
-
Page 94: Appendix 1. Kdb Viewer
1. KDB Viewer 1. KDB Viewer 1.1 How to run Viewer Connect or insert saved KDB type backup data media to computer, Double click [KDBViewer] Folder to open. Double click ‘Viewer.exe’ to run viewer application. Click on next button. - Page 95 Check the box “I accepted this License Agreement” and click on [Next] Enter the path to install the CMS program, and click on [NEXT] button. Installation will start.
- Page 96 After the Center Program is completely installed, click on [FINISH] button. On the desktop, “KDBViewer.exe”...
-
Page 97: Viewer Main Screen
1.2 Viewer main screen [Scroll button for camera] [Search Line] • This indicates time line for searching data. • Scroll up or down to show camera buttons. • Move the line to the left or right to start searching. [Camera] •... - Page 98 9 10 12 13 14 [Zoom] [Playback] Increases screen size by up to x4. • Be sure to select the camera, time and date to search. • Adjust SKIP and SPEED ratio as you wish. [Digital Zoom] Go to first saved image for selected date Reverse play frame by frame [Zoom In] Click right mouse button to increase the...
- Page 99 [Audio Play Configuration] • When you want to playback audio, select the channel with recorded audio. (Audio recording and replay is supported for only one channel). • When you click the ‘Audio Play’ icon , the audio play configuration window appears as right. •...
-
Page 100: Webdvr
2. WebDVR Connect WebDVR Connect WebDVR 1. Input DVR IP address to connect on Web Browser (Internet Explorer) as blow picture. [Note] • To operate WebDVR without errors on Windows Vista, execute “Internet Explorer” as an administrator. And then you can get the right the access to download ActiveX program. - Page 101 3. After pop-up message, click “Install” to install software. 4. After install is complete, the screen below will be displayed. Insert ID and password to connect to DVR, and then click “Login”.
- Page 102 Live Watch Mode Live Watch Mode View Panel : It can be shown live picture from DVR. And each channel screen can be moved through Drag and Drop. Live Watch : Press button to enter the live display. Playback : Press button to enter the search display. Split button : Choose the screen division displayed by 4/6/9/10/13/16/25/33/36 splits.
- Page 103 Search Mode Search Mode View panel: Displays the playback of recorded data. Live Watch : Press button to enter the live display. Playback : Press button to enter the search display. Split button : Choose the screen division displayed by 4/6/9/10/13/16/25/33/36 splits. Search date : Input the search date and time.
-
Page 104: Watermark Checker
3. Watermark Checker 3. Watermark Checker Double click ‘WMChecker.exe’ to run Watermark program Press ‘File Open’ button to select backup still image data (BMP,JPEG) Select image to check forgery. - Page 105 4 If select correctly, it will be shown as below picture. Press [Water mark Check] button to check forgery of selected file as below pictures B. Original Image a. Modified Image...
-
Page 106: Adding Hdd
4.1 Installing new HDD • Turn the system off and install the new HDD into the system. • Turn the system back on and wait for the HDD format message. • The message will ask you to confirm HDD format. HDD format is a necessary procedure before using the newly installed HDD. -
Page 107: Checking Hdd Database
4.2 Checking HDD Database • If the newly installed HDD database does not correspond with the original HDD, the system will display the HDD table. • If the database of the HDD does not correspond, you must format either the system’s original HDD or the newly installed HDD. -
Page 108: Specifications
5. Specifications 5. Specifications System Specifications • HDD : Max. HDD x 2 • O/S : Embedded Linux • LAN : Ethernet 10/100 Mb/s • Modem : 56Kbps. External-type modem is supported. (Optional, but not available in Europe) Video Input e c w $ ƒ... - Page 109 Auto Sequence • Automatic channel rotation in order of x1,x4,x9 Screen Division (DW-616T/716T) Playback Display Mode • Playing in split screen mode up to 1, 4, 9, 16-splitscreen is possible (DW-616T/716T) • Enlarging an image to full screen is possible Alarm In &...
-
Page 110: Faq
6. FAQ 6. FAQ The system power does not turn on. Check if the power cable is connected correctly. Check if the input voltage is correct. If the system power does not turn on when the power cable is connected correctly, please contact the service Center. - Page 111 Color of some camera videos are strange or videos are shown abnormally. Check if the camera connected to the system has a problem. Check to make sure the camera is not damaged by trying another camera into a working video output. Check if the video system setting is the same with your camera system.
- Page 112 Warranty Guide Warranty Guide The quality of this product is guaranteed by strict quality control processes and testing. If the product becomes non operational the warranty may be in operation. The warranty period is valid for 1 year from the date of purchase. Warranty Guide Check the Product Warranty Sheet to make sure it is still in effect.
