User manual
SL35100
［ＶＲ． ５］
S L35100-42STD-HP2
Model:
Thank you for purchasing a RAY GEARS product.
Please read this manual thoroughly to ensure safe and correct use.
Please make sure to read "Safety cautions" (pages 2 and 3) before use.
After reading this manual, make sure to keep this manual handy for future reference.
Advertisement
Summary of Contents for RAY GEARS SL35100 Series
- Page 1 with warranty User manual SL35100 ［ＶＲ． ５］ S L35100-42STD-HP2 Model: Thank you for purchasing a RAY GEARS product. Please read this manual thoroughly to ensure safe and correct use. Please make sure to read "Safety cautions" (pages 2 and 3) before use. After reading this manual, make sure to keep this manual handy for future reference.
-
Page 2: Table Of Contents
Contents Safety cautions …………………………………………………………………… 2 Nomenclature……………………………………………………………………… 4 Nomenclature and functions of battery checker/remote controller………… 5 …………… 6 How to turn ON light/How to recharge/How to light continuously with AC adapter Focus adjustment function/Brightness control function……………………… 7 How to attach lens cover…………………………………………………………… 8 Please carry out periodic supplementary recharging…………………………… 9 When the light does not behave as designed……………………………………10 Troubleshooting………………………………………………………………………11 Specifications………………………………………………………………………… 12 Warranty and after service ………………………………………………………… 13 Optional products ………………………………………………………………… 14 Safety cautions Please observe the following points. Please make sure to read this section before use. This product is designed in consideration of safety. However, misuse can cause damage of the product, electric shock, and/or fire that can cause health hazards and is extremely dangerous. Please observe the following points to ensure safe use of this product. ■Potential harms and damages as a result of failure to follow the instructions are categorized and explained using the following severities. Failure to observe the item marked with this mark can potentially cause Warning accidents involving fatalities and serious injuries due to fire, electric shock, damage, and for other reasons. - Page 3 Warnings ■Do not look into the light directly when it is ON. ■Do not point the light at eyes of people and animals directly with the light ON. ■Do not point the light at traveling cars and working people directly with the light ON. Failure to observe the above can cause eye injuries and/or a serious accident. ■Do not place the battery in fire. ■Do not use the product in an environment where combustible substances and gases can be produced. ■ Do not store the product at a highly humid place, a hot place at 40℃ or above, or a heavily dusty place. ■Do not irradiate the light at an easily flammable item for a long period of time. Failure to observe the above can cause a fire or the like. ■Set the switch to OFF after use without fail. ■Do not use this product ■Fully recharge the battery after use as a weapon. without fail. ■Carry out periodic maintenance. Failure to observe the above can cause Failure to observe the above can damage the a serious accident. product. ■Before replacing an accessory, check that the power is OFF without fail. ■When the glass lens cracks or comes off, turn the ■Before touching the light, check that power OFF and stop the use. the temperature of the lens has dropped to a safe level to touch Failure to observe the above can cause without fail. a serious accident. Failure to observe the above can cause burn injuries. Cautions ■Do not touch the glass lens and the bottom of the main unit directly ■Store the product out of with hands with the light ON.
-
Page 4: Nomenclature
各部の名前 Nomenclature Dedicated belt attachment ring Misoperation prevention cover Light switch Dedicated belt attachment ring Digital meter Lens Lens cover Main switch Waterproofing cover Brightness control lever Focus adjustment lever /adapter connector port Accessories ・ Transparent diffusion lens cover × 1 ・High strength waterproof case × 1 ・AC continuous lighting adapter (100 ~ 240 V) × 1 ・User manual with warranty × 1 ・DC continuous lighting connector (3 m) × 1 ・Remote controller × 1 ・Dedicated belt × 1... - Page 5 Nomenclature and functions of battery checker ① ② ③ ① Digital meter 100%： "Fu" is displayed 10 to 99 %： Exact percentage is displayed. Less than 10%： "Lo" is displayed. ② Battery check button The battery level is indicated in the digital meter while the battery check button is pressed. ③ Battery indicator The battery level is indicated by the lamp color. Lit (red):：Charging Lit (green)：Fully charged Flashing (red):：Error * Perform "turning OFF and ON the main switch" operations twice to reset the system. Nomenclature and functions of remote controller Remote control range is up to 20 m where there are no shielding structures. (1) Light switch: ON/OFF ② ① (2) Flashing strobe: ON/OFF ④ ③ (3) Increase brightness: Brightness continues to increase while this button is pressed. (4) Decrease brightness: Brightness continues to decrease while this button is pressed. * Make sure to set the main switch to ON before using the remote controller.
-
Page 6: How To Turn On Light/How To Recharge/How To Light Continuously With Ac Adapter
How to turn ON light (1) Set the main switch to ON. (2) Lift the misoperation prevention cover and press the light switch. * Do not remove the translucent silicone cover of the light switch. * In the lit mode, the LED indicator of the light switch is lit in red. * When used near wireless equipment, it can cause the battery protection circuit to disable the product. When this occurs, recharging operation can reset the circuit to help the light turn ON. How to recharge (1) Lift the waterproofing cover at the back of the main unit and connect the adapter plug to the charge connector port. (2) Set the main switch to ON. (3) Insert the power plug of the adapter to the 100 V~240V outlet. (4) In the charging mode, the battery indicator is lit in red. (5) When the battery indicator switches to green, the charging process is complete. (6) Disconnect the adapter from the main unit and disconnect the power plug from the power outlet. * Because this product uses a lithium ion battery, additional recharge may be performed. * Safety design to prevent overcharge is adopted. * The AC adapter generates noise during charging mode but it does not mean that the product has failed. * Make sure to recharge until the battery indicator turns green. * Recharging would not start when the main switch is at OFF. * When charging error occurs, perform "turning OFF and ON the main switch" operations twice to reset the system. How to light continuously with AC adapter (1) Lift the waterproofing cover at the back of the main unit and connect the adapter plug to the charge connector port. (2) Set the main switch to ON. (3) Insert the power plug of the adapter to the 100 V~240V outlet. (4) Set the light switch to ON. (5) Continuous lighting with the AC adapter starts. (6) When the light switch is set to OFF, the light reverts to the charging mode. * When charging error occurs, perform "turning OFF and ON the main switch" operations twice to reset the system. ... - Page 7 Focus adjustment function Turn the lever to left or right to adjust the focus of the light. ◇Spot light distribution (Suitable to irradiate long distance.) ◇Wide light distribution (Suitable to irradiate short distance and/or wide range.) H100W L35W Focus adjustment lever Brightness control function Flip up or down the lever to adjust the brightness of the light. H100W L35W Brightness control lever - When the light is turned ON, the brightness always starts from 35 W. - 11-step adjustment is supported. * The brightness level is indicated in the digital meter. L 1 2 3 4 5 6 7 8 9 H Flip up the lever: Increase output （35W） （100W） Flip down the lever: Decrease output...
-
Page 8: How To Attach Lens Cover
How to attach lens cover This section covers how to attach diffusion lens covers (accessories) and various optional lens covers (optionally available). Loosen Tighten (1) Remove the lens cover by turning in anti-clockwise direction. (2) Attach the intended lens cover by turning in clockwise direction. * Use our genuine lens covers without fail. Use of non-genuine products can cause damage to the product and injuries. * Turning the cover forcibly in an unfitted state can damage the threads. * If the cover cannot be turned smoothly, use commercially available silicone spray or the like on the threads. * Make sure to set the main switch to OFF before attaching the lens cover. ■Special lens covers (optionally available) Product names Models 850 infrared lens cover 3050IR850S-LC Diffusion 850 infrared lens cover 3050IR850W-LC 950 infrared lens cover 3050IR950S-LC Diffusion 950 infrared lens cover 3050IR950W-LC 530 dust detection lens cover 3050GD530-LC 365 ultraviolet lens cover 3050BL365SーLC Diffusion 365 ultraviolet lens cover 3050BL365W-LC 415 protein denatured lens cover 3050PT415-LC Eye glasses EX-415-OGEG... -
Page 9: Please Carry Out Periodic Supplementary Recharging
Please carry out periodic supplementary recharging ◆ This product requires periodic supplementary recharging. Read this section without fail. Lithium ion batteries are known to discharge although not used due to their self-discharge characteristics. Thus, when the product is left unused for a long period of time, the performance can deteriorate significantly and the product can become unusable in the worst case. Carry out supplementary recharging as described below after use of the product without fail. Also when not using the product for a long period of time, carry out supplementary recharging once a month for reference. Please be informed that performance deterioration due to long-term storage without carrying out supplementary recharging is outside the scope of our warranty. Supplementary recharging C a r r y o u t s u p p l e m e n t a r y r e c h a r g i n g a t t h e f o l l o w i n g t i m e s t o m a i n t a i n g o o d ... -
Page 10: When The Light Does Not Behave As Designed
When the light does not behave as designed Before making a request for a repair, please check the following items. Reference Condition Check point A c t i o n s page in user manual The battery Is the main switch at ON? Set the main switch to ON. Page６ cannot be recharged. Is the AC adapter connected correctly? Connect the AC adapter to the main unit Page６ correctly and insert the power plug to the power outlet. The light Is the main switch at ON? Set the main switch to ON. Page６ would not light. Set the light switch to ON. Is the light switch at ON? Page６ (Light switch: lit in red when ON, not lit when OFF) Is the battery depleted? Page６ Press the battery check button of the battery ... -
Page 11: Troubleshooting
Troubleshooting ◆ When the battery cannot be recharged: 1. Set the main switch to ON. 2. Connect the AC adapter to the main unit correctly and insert the power plug to the power outlet. 3. In that state, wait for about 10 minutes. 4. Set the main switch to OFF. 5. Set the main switch to ON again. 6. Check the battery indicator. When it is lit in red, the battery is recharging normally. When the above ●It is extremely dangerous to disassemble the light for repair on your own. operation does not ●The light may have failed. Please contact our customer service representative. seem to help the situation See "Warranty and after service" (page 13) for details. ◆ When the light would not light When the product is left unused for a long period of time, the light may fail to turn ON. In that case, please reset the product by following the procedure below and see if it helps. 1. Set the main switch to ON. 2. Connect the AC adapter to the main unit correctly and insert the power plug to the power outlet. 3. Disconnect the AC adapter. 4. Set the light switch to ON. * When used near a wireless equipment, it can cause the battery protection circuit to disable the product. When this occurs, follow the procedure given in the "When the light would not light" section. When the above ●It is extremely dangerous to disassemble the light for repair on your own. operation does not ●The light may have failed. Please contact our customer service representative. seem to help the See "Warranty and after service" (page 13) for details. situation... -
Page 12: Specifications
Specifications Product name ＳＬ３５１００[ＶＲ.５] Model ＳＬ３５１００-４２ＳＴＤ-ＨＰ２ ０ Output 100 W<-> 35 W (11-step brightness control) Maximum light flux １００ｗ／９１００(lm) ３５ｗ／３３００(lm) Irradiation distance １００ｗ／２２００(m) ３５ｗ／８００(m) Main unit lighting time Approx. 1 h 30 m at 100 W, approx. 3 h 45 m at 35 W Color temperature ４２００Ｋ Main unit weight Approx. 2.8 kg Main unit dimensions １４０×１５４×２９６（mm） Focus adjustment Spot <-> wide Battery model SLHBP-3050 * Lithium ion battery Battery specifications PAN NCR18650B-4S3P 14.4V 10350mAh 147Wh 5 h Charging time (approx.) - Main unit × 1 Model: SL3570 (VR.5) Contents - Diffusion lens cover (translucent white) × 1 Model: 3050WW-LC - AC continuous lighting adapter (100V-240V) × 1 Model: ACDCCH-3050 - DC continuous lighting connector (3 m) × 1 Model: 3MDC-3050 - Shoulder belt × 1 Model: SHB-3050 - High strength waterproof case × 1 Model: BSWP-3570 - User manual with warranty × 1 - Remote controller × 1 Model: RC-100...
