- Page 2 There is a 90 day warranty on the rechargeable battery of the TRAX. In no event shall JAMAR Technologies, Inc. be liable for any damages arising from the use of this product including damages arising from the loss of information.
- Page 3 If you have any questions about the use of the TRAX Totalizer, please call the following number: 1-215-491-4899 Monday — Friday 8:00 AM to 5:00 PM Eastern time You may also contact us by e-mail at: sales@jamartech.com For more information on our products, or for the latest news in product development, visit our web site at: www.jamartech.com...
-
Page 4: Table Of Contents
..............ii Quick Setup Guide ..............v Introduction to the TRAX Totalizer............. 1-1 What is the TRAX Totalizer? ..............1-2 How is the TRAX Totalizer Powered?............. 1-3 ON/OFF, DO and TAB Functions ............1-3 Operation of the TRAX Totalizer ..............2-1 Start-up Screens .............. - Page 5 Quick Setup Guide for the TRAX Totalizer 1. Turn the TRAX Totalizer ON. 2. Once the Main Menu appears, press the DO key while ‘Start’ is flashing. START VIEW SETUP 3. To view your totals as they are recorded, press TAB until View_Count is flashing then Press DO.
- Page 6 TRAX Totalizer User’s Manual...
-
Page 7: Introduction To The Trax Totalizer
Chapter 1 — Introduction to the TRAX Totalizer CHAPTER 1 Introduction to the TRAX Totalizer... -
Page 8: What Is The Trax Totalizer
The counter is designed to al- low the collection of volume information without the need to download to a computer. There are two models of the TRAX Totalizer — one that collects data using road tubes, a second that collects data using loops. -
Page 9: How Is The Trax Totalizer Powered
Chapter 1 — Introduction to the TRAX Totalizer How is the TRAX Totalizer Powered? The TRAX Totalizer is powered by a rechargeable lead gel, with optional solar panel. For loop Totalizers with external power, the loop cable provided with the unit will contain a power jack. - Page 10 TRAX Totalizer User’s Manual...
-
Page 11: Operation Of The Trax Totalizer
Chapter 2 — Operation of the TRAX Totalizer CHAPTER 2 Operation of the TRAX Totalizer... -
Page 12: Start-Up Screens
TRAX Totalizer User’s Manual Start-up Screens When you power on the TRAX Totalizer, the counter will display several screens with information on the current status of the unit. After the initial sign on, the version number of the firmware is displayed. -
Page 13: Main Menu
Chapter 2 — Operation of the TRAX Totalizer Main Menu START VIEW SETUP The Main Menu of the Totalizer can be used to access the setup information for the counter, view an existing count or start a new count. Setup To access the Setup menu, in the Main Menu press the TAB key until Setup is flashing then press the DO Key. -
Page 14: Layout
TRAX Totalizer User’s Manual *Note that the 24-hour totals begin from when you start the count. If you start the count at 3 pm on Monday, your first 24 hour totals will be from 3 pm Monday to 3 pm Tuesday, etc. - Page 15 EXAMPLE: As a car approaches and both front and rear axles pass over the “A” or “B” tube, the TRAX Totalizer will record one (1) count. As a four axle truck approaches, and all four axles pass over the “A” or “B”...
-
Page 16: Lsense
TRAX Totalizer User’s Manual L3 - Two Channels with Lane Separation A to B, B to A In this layout, both tubes (A and B) are extended completely across the road. Channel A and channel B record independent of each other. -
Page 17: Starting A Count
Chapter 2 — Operation of the TRAX Totalizer Starting a Count To start a new count with the Totalizer, press DO while Start is flashing on the Main Menu. The Totalizer will begin recording information and the following screen will be displayed:... -
Page 18: Total
TRAX Totalizer User’s Manual The first two digits (01 in the previous example) list what 24-hour (or hourly) totals you are viewing. To go to the next 24-hour (or hourly) totals, press the TAB key. 02:000244 0000197 After the last 24 hour (or hourly) totals have been displayed, pressing the TAB key will bring up the End of Count screen. -
Page 19: Road Tube Installation
Chapter 3 — Road Tube Installation CHAPTER 3 Road Tube Installation... -
Page 20: Installing Road Tube
Installing Road Tube Proper road tube installation is very important for collecting accurate data with your TRAX Totalizer. The road tube and the Totalizer’s air switches comprise the sensing device for the unit. As with all receivers, the sensor has to be functioning properly to record reliable information. With this in... -
Page 21: Installation
Chapter 3 — Road Tube Installation Installation Round Tube (.25 ID x .60 OD) Round tube should be stretched one foot for every ten feet of roadway when being installed. Each tube should be secured at each end of the roadway by using a galvanized C-Clamp, Chinese Finger, Figure 8 Grip or an End Plate. -
Page 22: Mini Tube
TRAX Totalizer User’s Manual Mini Tube (.187 ID x .365 OD) Since mini tube is smaller and lighter than standard round tube, less hardware is required to install the tubes. Also, mini tube should not be stretched when installed, just placed on the road. -
Page 23: Loop Connections
Chapter 4 — Loop Connections CHAPTER 4 Loop Connections... -
Page 24: Connecting To The Loop
TRAX Totalizer User’s Manual Connecting to the Loop The Totalizer is connected to the Loop using the loop cable (shown to the right) that was supplied with the counter. This cable contains wires for connecting one or two loops to the totalizer. -
Page 25: Battery Care
Chapter 5 — Battery Care CHAPTER 5 Battery Care... -
Page 26: Charging
TRAX Totalizer User’s Manual Battery Care The following information regarding battery care is furnished to assist you in the use and maintenance of rechargeable batteries. Battery life is dependent on the user’s preventative maintenance procedures. Establish regular routines for all of your batteries regardless of their usage. -
Page 27: Additional Battery Notes
Chapter 5 — Battery Care After a battery has been charged, allow it to sit for at least 8 hours and check the voltage again to determine if the battery maintained its charge. Some decay is acceptable; however, if the battery falls below 6.1 volts, recharge it for a longer period of time. - Page 28 TRAX Totalizer User’s Manual...
-
Page 29: Menu Tree & Specifications
Chapter 6 — Menu Tree & Specifications CHAPTER 6 Menu Tree & Specifications... -
Page 30: Menu Tree
TRAX Totalizer User’s Manual MENU TREE SIGN-ON STOP START STATUS TOTALS VIEW_COUNT 24Hr VIEW TOTAL DAYS SETUP LAYOUT... -
Page 31: Technical Specifications
Chapter 6 — Menu Tree & Specifications TECHNICAL SPECIFICATIONS Size — 11” x 7” x 4.5” Weight — approximately 7 lbs. Sensor Inputs — Road Tube, Loop. Memory — 4K internal. Power — rechargeable battery, with optional solar panel. Temperature Range — Minus 40 F (-40 C) to 165 F (72 C). Recording Volumes —... - Page 32 TRAX Totalizer User’s Manual We are pleased that you have chosen the JAMAR TRAX Totalizer for your traffic analysis needs. We have strived to develop a unit that is easy to use and has the options that our customers require. The TRAX Totalizer has undergone extensive testing to verify the accuracy of its operations, and each unit is tested before it leaves our facility.
