Congratulations on your purchase of the world's finest Driver Cooling System
The COOLSHIRT® Pro Air & Water System is the finest Driver Cooling System Available today. Used
by drivers in all levels of racing, this system delivers the ultimate in driver cooling comfort. The Pro
Air & Water System delivers temperature controlled cooled water to the driver's COOLSHIRT® while
providing cooled HEPA-4 filtered, blower enhanced air to the driver's helmet.
COOLSHIRT Personal Cooling Systems are manufactured in the USA and contain the highest quality
components available. With proper installation and maintenance, your system will provide you with
years of dependable service. Please inspect your purchase to ensure that your system contains the
selected components listed below. If there are any discrepancies, please contact COOLSHIRT 
SYSTEMS Customer Service at 800-345-3176 immediately.
Included with your system:
Quantity
_________ 1
_________ 1
_________ 1
_________ 1
_________ 1
_________ 2
_________ 1
_________ 1
_________ 1
_________ 1
_________ 1
_________ 1
_________ 2
System Specifications:
Dimensions
PSAW-12: 14"L x 9.5"W x 11"H
PSAW-24: 15.5"L x 10.5"W x 13"H
© 2014 COOLSHIRT SYSTEMS, 170 Andrew Drive, Stockbridge GA 30281
Office : 800-345-3176
Pro Air & Water System
Part #
PSAW-12/24
H-12-S
Dual Flow Temperature Control Switch for Air & Water
FC-2
MT-12/24
AIRH-8
8-foot x 1½" diameter heavy-duty clear Helmet Air Hose
HEF-1½
HEF-H
A-x3X3FT
HEF-4
FS-10
FS-1
BF-235
IC
__________________________________________________________________
Cooling Time
3 Hours
6 Hours
Platinum Series Cooling Unit w/ heat exchanger & internal pump
12-foot insulated water hose with quick disconnects
Mounting Tray with tie-down strap
Blue Air Hose Connectors: 1/½" diameter
Blue helmet connector for Air Hose
3' x 3" heavy duty clear intake air hose
4" blue intake air Hose-to-Blower connector
HEPA-4 Micron Air Filters: 10 per package
Metal Screen for Air Filter
235CFM Blower with 1½" Blue Filter Housing attached
Block Ice Container
Dry Weight
6 lbs.
7 lbs
Fax: 678-289-4325
Made in the U.S.A
Description
Power Required
235 CFM Blower: 2.9A, 12V Water Pump: 2.0A, 12V
235 CFM Blower: 2.9A, 12V Water Pump: 2.0A, 12V
www.coolshirt.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro Air & Water System and is the answer not in the manual?

Questions and answers

Summary of Contents for CoolShirt Pro Air & Water System

  • Page 1 Pro Air & Water System Made in the U.S.A Congratulations on your purchase of the world’s finest Driver Cooling System The COOLSHIRT® Pro Air & Water System is the finest Driver Cooling System Available today. Used by drivers in all levels of racing, this system delivers the ultimate in driver cooling comfort. The Pro Air &...
  • Page 2: Installation Instructions

    Pro Air & Water System Installation Instructions: MOUNTING TRAY (MT-12/24) and COOLING UNIT (PSAW-12/24) 1) Select mounting tray location and permanently attach the tray to the racecar with any appropriate hardware (not provided). Place cooling unit into the mounting tray. 2) Thread the tie down strap through one of the two slots provided on the cooling unit, then run the strap down through the slot on the same side of the mounting tray.
  • Page 3: Operating Instructions

    Pro Air & Water System Installation Instructions(continued): INTAKE AIR HOSE (A-3X3FT) AND HELMET AIR HOSE (AIRH-8) 1) Determine the length of 3-inch hose needed to pick up outside air and cut the hose to the appropriate length. 2) Slide one end of the 3-inch hose over the intake side of the blower. If you have a NACA duct, connect the hose to the duct appropriately.
  • Page 4 Pro Air & Water System Troubleshooting(continued): 4) Air not circulating: Recheck electrical connections. Maintenance: 1) COOLSHIRT®: Turn the shirt inside out and wash in washing machine on the gentle cycle in warm or cold water 2) Add 2 ounces of Maintenance Additive (MA-16) to the cooling unit with the ice and water each time the unit is used.
