Summary of Contents for TV Logic TVK-4000SH
- Page 1 4K Cross Converter...
-
Page 2: Table Of Contents
Contents 1. Getting Started - Introduction - LCD Layout 2. Operation Modes 3. Setting Up 4. Usage Example 5. Specification... - Page 3 Product Overview Feature • 12G SDI Input and Output - Support HD, 3G Level A/B, 6G, 12G • HDMI 2.0a Input and Output - Support up to 3840x2160@60p • Dual Scaler Included - Support SDI and HDMI outputs with independent resolutions - Convert resolutions and frame rates •...
-
Page 4: Getting Started
Getting Started... -
Page 5: Introduction
Introduction Rear DC Power IN Connect the supplied DC Adapter (+12V/3.5A) HDMI IN Connect HDMI 2.0 type A Cable to the HDMI Source (Video Player etc.) REF IN SDI IN Connect 12G SDI Cable to the SDI Source (SDI Camera etc.) Reclocked output of SDI IN signal to the SDI Rx (SDI Monitor etc.) SDI LOOP OUT SDI OUT2... -
Page 6: Lcd Layout
LCD Layout SDI IN HDMI IN SDI OUT HDMI OUT INPUT/OUTPUT Status Input Resolutions Output Resolutions INPUT/OUTPUT Status INPUT/OUTPUT Status Top GUI shows HDMI Output related settings. INPUT/OUTPUT Status Bottom GUI shows SDI Output related settings. Input Resolutions Show the resolutions of input signals Output Resolutions Show the resolutions of output signals IN/OUT Preview... - Page 7 IN/OUT Setup Output Selection Select to change SDI OUT settings SDI OUT HDMI OUT Select to change HDMI OUT settings Input Selection Select one of 4 Input Sources, [SDI], [HDMI], [PATTERN] and [AUTO] If you select [AUTO], available input source will be selected automatically. ...
- Page 8 System Settings HDMI Out EDID Limit : ON : Limit Resolutions according to capability of HDMI TV connected OFF : Enable all Resolutions up to 2160p60 Copy SDI Out : ON : Change resolutions on SDI and HDMI OUTs simultaneously OFF : Change resolutions on SDI and HDMI OUTs independently...
- Page 9 System Settings Network DHCP : Network assigns IP address automatically Manual : User can assign IP address manually MISC Auto Hide : ON : Main Menu will disappear after show time OFF : Main Menu will show and stay Transparency : Change transparency of GUI System Show Model Name, SW Version, FPGA Version and MAC address...
-
Page 10: Operation Modes
Operation Modes... - Page 11 Operation Mode SDI IN -> HDMI OUT, SDI OUT SDI signal can be converted to HDMI and SDI signals. Input SDI signals can be up or down scaled to outputs. Output resolutions for HDMI and SDI can be set independently. Camera 12G-SDI/HDMI2.0 Cross Converter...
- Page 12 Operation Mode HDMI IN, SDI IN -> HDMI OUT, SDI OUT This mode works as a two separate scaler. HDMI input signal can be up or down scaled to HDMI output. SDI input signal can be up or down scaled to SDI output. SDI and HDMI paths are working independently.
-
Page 13: Setting Up
Setting Up... - Page 14 Preparations Cable High Speed HDMI Cable SDI Cable LAN Cable Devices HDMI Source 4K Cross Converter (PC, BDP, OTT etc) SDI Source(SDI Camera etc) HDMI Sink (HDMI 4K TV etc) SDI Sink (SDI Monitor etc) Adaptor & Power Code...
- Page 15 Connections HDMI Player...
-
Page 16: Usage Example
Usage Example... - Page 17 SDI to HDMI Conversions Cable Connection (1) Connect SDI Source and SDI Input of Converter (2) Connect HDMI Out of Converter with HDMI TV Software Setup IN/OUT >> HDMI OUTPUT >> INPUT SDI Selection >> Resolution Selection >> Set...
- Page 18 HDMI to SDI Conversions Cable Connection (1) Connect HDMI Source and HDMI IN of Converter (2) Connect SDI OUT of Converter and SDI Monitor Software Setup IN/OUT >> SDI OUTPUT >> INPUT HDMI Selection >> Resolution Selection >> Set...
-
Page 19: Specification
Specification... - Page 20 Specification for S/W Item Spec Notes 720p, 1080i, 1080p,2160p Resolutions 23.98, 24, 25, 29.97, 30, Frame Rate 50, 59.94, 60 Any Resolution -> Up/Down Scaling Any Resolution Frame Rate Any Rate -> Any Rate Conversion Built-in Web Server Firmware Upgrade using Ethernet Front 2.7”...
- Page 21 Specification for H/W Q’ty Item Type Spec 12G SDI Input HDMI HDMI 2.0a 12G SDI 12G SDI Output Loop HDMI 2.0a HDMI 2.7” LCD + Capacitive LCD + Touch Touch 9 x Front Menu Buttons Buttons Ethernet 10/100Mbps Network RJ45 Power DC-Jack 12V / 3.5A...
- Page 22 MEMO...
- Page 23 MEMO...
- Page 24 4K Cross Converter FOR MORE INFORMATION PLEASE VISIT : http://www.tvlogic.tv 12F, ACE HIGH-END 8, 84 Gasan digital 1-ro, Geumcheon-gu, Seoul, 153-802, KOREA TEL : +82-70-8668-6611, FAX : 82-2-6123-3201, E-mail : sales@tvlogic.co.kr...
