I N T E R N A T I O N A L
T h e p r o f e s s i o n a l ' s c h o i c e
Solvent Based Spray Gun Cleaner
Operating
Instructions
UGC2006M
UGC2006
UGC4006
UGC5006
What it should come with
1186 - Work Screen x 1
2051 - Quick Release Coupling x 1
736 - Hook x 1
Also available:
786 - Air, Dirt & Water trap
783 - Nipple
Installation fittings:
FRA3 3" Angle Flange
We also recommend:
Solvent Recycler
FD3 3" Flexi Ducting
FR3 3" Angle Flange Flat
F6R5 6" to 5" Reducer
Paint Can Crusher
UGC5006 ONLY
1186 - Work Screen x 2
2051 - Quick Release Coupling x 2
736 - Hook x 2
Gate Valve 803
FF3 3" Flange Flat
Paper Compactor
F5R3 5" to 3" Reducer
Advertisement
Table of Contents
Related Manuals for Unic UGC2006M
Summary of Contents for Unic UGC2006M
- Page 1 I N T E R N A T I O N A L T h e p r o f e s s i o n a l ’ s c h o i c e Solvent Based Spray Gun Cleaner Operating Instructions UGC2006M UGC2006 UGC4006 UGC5006 What it should come with...
-
Page 2: Maintenance Check
Remove the hose from the pump air inlet and add two drops of machine oil to the air inlet. The Unic range of Gun Cleaning Machines are Category 2 equipment that is suitable for Apparatus Groups (Gas groups) IIA, IIB and IIC, with a temperature class of T6. - Page 3 Turn drain valve lever to vertical position (see diagram 2). Underneath the machine at the rear are the earthing wire(s), the crocodile clip(s) must be attached to any metal solvent container(s) if used (these are not supplied by Unic international).
-
Page 4: Using The Machine
• TO UNLOCK SWITCH OFF THE MACHINE MANUAL WASH/ CLEAN RINSE UGC4006 and UGC5006. For UGC2006M Manual Wash and Clean Rinse begin this process at step three. MANUAL WASH Turn Mode Control Valve on the front of machine to Manual Mode. - Page 5 Health & Safety Data Sheet Information supplied in accordance with section 6 of the health and safety at work etc. Act 1974 PRODUCT NAME UNIC POWERCLEAN SPRAY GUN CLEANING UNIT. USES Removal of paint from Spray guns, cups and hoses.
-
Page 6: Test Report
Test Report on emissions from Powerclean Spray Gun Cleaners Table 3 - Solvent concentrations measured during the operation of a Unic Powerclean Automatic Spray Gun Cleaning Machines. Short Term Monitoring Monitoring Monitoring Solvent Exposure Limit Position 1 Position 2 Position 3... - Page 7 Certificate number: SIRA 03ATEX5252 EC Notified Body: not applicable Approved By: Date: Director (Signed) Date: Director (Printed) Unic International, Colwick Road, Nottingham NG2 4BG England Tel: +44 (0) 115 947 4000 Fax: +44 (0) 115 950 6666 Email: info@unic.co.uk Web: www.unic.co.uk...
- Page 8 Ex II 2G T6 Certificate Number: SIRA 03ATEX5252 Manufactured By: Unic International UK Colwick Rd Nottingham NG2 4BG Unic International, Colwick Road, Nottingham NG2 4BG England Tel: +44 (0) 115 947 4000 Fax: +44 (0) 115 950 6666 Email: info@unic.co.uk Web:...
-
Page 9: Information Request
Solvent Recycler Spares Service Information Other Comments: Please send this information to: Name: Address: Email: Telephone: Fax: Unic International, Colwick Road, Nottingham NG2 4BG England Tel: +44 (0) 115 947 4000 Fax: +44 (0) 115 950 6666 Email: customerservice@unic.co.uk Web: www.unic.co.uk... -
Page 10: Warranty Conditions
UK. – Unic International - Tel +44(0)115 – 9474000 - Fax: +44 (0)115-9506666 - Email: info@unic.co.uk OUTSIDE UK Contact your local Flojet distributor. If unknown check their web site www.flojet.com for details. Quote your date of purchase. The machines are not user serviceable and Unic International or their authorised distributor should only carry out repairs.
