Summary of Contents for Ugin MINICAST
-
Page 1: Table Of Contents
INSTRUCTIONS FOR USE MINICAST CONTENTS INTRODUCTION SPECIFICATIONS INSTALLATION AND SET-UP DESCRIPTION OF THE CONTROL PANEL 13-14 MELTING AND INJECTION CIRCUIT DIAGRAM... -
Page 2: Introduction 10
MINICAST, please read the operating instructions and advice contained in this manual attentively. -
Page 3: Specifications 11
330mm cover open : 730mm - Net weight : 50kg ACCESSORIES - 2 crucibles type Minicast DF1F, code P15145 OPTIONS - Casting ring table - casting ring tongs - oxy acetylene torch - set of casting rings - oxy propane torch... -
Page 4: Installation And Set-Up
INSTRUCTIONS FOR USE MINICAST INSTALLATION AND SET-UP OF THE MINICAST CASTING MACHINE -After unpacking the machine, verify its condition and notify the shipper and supplier of any damage. Remember to have the deliveryman sign the shipping order on which any reservations have been noted and to confirm the latter to the shipper by registered letter with acknowledgement of receipt. -
Page 5: Description Of The Control Panel
INSTRUCTIONS FOR USE MINICAST DESCRIPTION OF THE CONTROL PANEL 1 - Power On / Off key 2 - «Cycle start » key 3 - Door safety lock indicator 4 - Injection time-delay 5 - Selector of arm acceleration... - Page 6 INSTRUCTIONS FOR USE MINICAST 1 - POWER ON/OFF KEY This key switches indicate the power on. It may also be used in the event of a problem for emergency 2 - CYCLE START KEY Before beginning a melting operation, you must make sure to press this key (with the cover open).
-
Page 7: Melting And Injection
INSTRUCTIONS FOR USE MINICAST MELTING AND INJECTION After installing your machine according to the instructions on page 9 - Press the ON/OFF key. - Set the time-delay potentiometer " (roughly 1/4 turn above the minimum). - Open the cover. - Position the casting ring and adjust its height using the lever. - Page 8 INSTRUCTIONS FOR USE MINICAST...
