Summary of Contents for ISC EZYiD
- Page 1 ® EZYiD Retro-fit System ® EZYiD Retro-fit System - Issue A - August 2019 ®...
-
Page 2: Table Of Contents
5.3 - Pairing the Reader to Your Device for illustrative purposes. 5.4 - Status Notifications: Sounds & LED Lights 5.5 - How to Hold the EZYiD Reader NOTE: Reproduction of the contents of this manual, in whole or in part, 5.6 - Reading the EZYiD Retrofit System without written permission of CSP Distribution Pty. -
Page 3: Who Should Read This User Instruction Manual
The EZYiD Reader is a specially designed Ultra High Frequency medical treatments. (UHF) device, designed for use in conjunction with EZYiD RFID Tags, Cable Ties, Stickers and Universal Moulded Tags and also with EZYiD embedded hardware products. The Reader is designed to transfer unique serial number information from the tag to a computer, tablet or mobile phone device of the user’s choice. -
Page 4: Nomenclature
4 Nomenclature The Reader EZYiD Retrofittable System ® EZYiD Universal Moulded Tag EZYiD Sticker Antenna Central Button Product Information Label LED (Blue) Serial Number EZYiD Tag EZYiD Logo Charging Port ® Body of Reader Identification Numbers EZYiD Cable Tie (Not to Scale) -
Page 5: Ezyid Reader Operation
® 5.1 Charging the Reader Insert the Micro USB into the portal on the back of the EZYiD Reader Insert the USB into the computer, tablet or other USB charging portal Flashing Blue Light (when charger cable unplugged) = Battery Low... -
Page 6: Powering The Reader
4. To turn the device off, hold down the central diamond shaped button. The blue light will flick to orange 2 Seconds EZYiD Retro-fit System - Issue A - August 2019 EZYiD Retro-fit System - Issue A - August 2019 ®... -
Page 7: Pairing The Reader To Your Device
5.3 Pairing the Reader to Your Device The EZYiD Reader is a “Plug ‘n’ Play” device. It is not necessary to download any software onto your computer, tablet or mobile phone, in order for the EZYiD Reader to function. Simply, turn on your EZYiD Reader, and follow the Bluetooth pairing instructions for your computer, tablet or mobile phone to pair the Reader to your personal device. -
Page 8: Status Notifications: Sounds & Led Lights
Reader is paired to your computer, tablet or mobile device and the information from the tag is being sent to and stored onto that device. EZYiD Retro-fit System - Issue A - August 2019 EZYiD Retro-fit System - Issue A - August 2019 ®... - Page 9 5.5 How to Hold the EZYiD Reader ® The EZYiD Reader should be held comfortably in one hand, ensuring that the antenna is not covered. Care should be taken not to press, hold or damage the antenna, as this may result in your Reader malfunctioning.
- Page 10 5.6 Reading the EZYiD Retrofittable System ® To scan, hold the Reader 2-3mm away from the tag Hold the antenna closely (2-3mm) over the Tag, Sticker, Cable Tie or Universal Moulded Tag which needs to be read Press down on the central button. The Reader will search for a readable...
- Page 11 6 EZYiD Retrofittable Application ® Tags: Tags are low profile, with a depth of ~2mm and diameter of 6mm. Tags can be applied to assets using a commonly available Contact Adhesive or Two-part Epoxy Resin (not supplied). It is the responsibility of the user to ensure that the adhesive used is suitable for use on the intended asset.
- Page 12 Retrofittable Application ® Cable Tie: Cable Ties are fitted with an EZYiD Tag, near the buckle-end of the tie, thus allowing the Cable Ties to be fitted in the usual manner with any excess length of the Cable Tie trimmed.
- Page 13 6 EZYiD Retrofittable Application ® 25mm Stickers: Stickers are 25mm x 25mm (1”x1”), with a low profile of <1mm and contain a special flat RFID tag. Stickers are supplied with a self-adhesive backing and can be applied to a range of non-metal assets.
- Page 14 6 EZYiD Retrofittable Application ® Universal Moulded Tags: Universal Moulded Tags are 19mm x 10mm x 5mm (3/4” x 25/64” x 13/64”) and can be fitted to assets by using a cable tie, nail, screw, pop-rivet, or glue. The Universal Moulded Tags can be attached to any asset.
- Page 15 All Tags, Cable Ties, Stickers and Universal Moulded Tags are passive (passive components are electronic components that do not require a source of energy to perform their intended functions). EZYiD Retro-fit System - Issue A - August 2019 EZYiD Retro-fit System - Issue A - August 2019 ®...
- Page 16 NOT directly apply detergents on to the product. Do NOT immerse the device in water/liquid. The EZYiD Reader should be handled with care and when not in use, should be stored in the protective case (as supplied with the device)
- Page 17 USB interface – Bluetooth 2.1 + EDR This equipment has been tested and found to comply with the limits 4mm Antenna is suitable for EZYiD Tags, Cable Ties, Stickers, Universal for a Class B digital device, pursuant to part 15 of the FCC Rules.
- Page 18 10: Lifespan & Warranty: other queries you may have regarding your EZYiD Reader. CSP Distribution Pty. Ltd. guarantees that EZYiD products will be free from material defects caused by workmanship or production. This Telephone Support:...
- Page 19 It is the responsibility of the user to read and understand these instructions prior to use. If the Reader is used in a manner contrary to the specification of the manufacturer (as defined in this manual), the protection of the equipment may be impaired.
- Page 20 Notes Notes EZYiD Retro-fit System - Issue A - August 2019 EZYiD Retro-fit System - Issue A - August 2019 ® ®...
- Page 21 ® CSP Distribution Pty. Ltd. 12/386 Scarborough Beach Road Osborne Park, WA, 6017 www.ezyid.com +61 8 6146 0170 support@ezyid.com International Safety Components Ltd. Unit 1, Plot 2 Llandygai Industrial Estate Bangor Gwynedd LL57 4YH United Kingdom +44 (0) 1248 363 125 sales@iscwales.com...
