Summary of Contents for Trinity SLIDING WIRE DRAWER
- Page 1 OWNER’S MANUAL SLIDING WIRE DRAWER 2-pack...
-
Page 2: Parts List
PARTS LIST Your Sliding Wire Drawer should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact Customer Service. Parts can also be requested online at our customer center. -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS – In Cabinet STEP 1 Place CABINET MOUNTING TEMPLATE (G) inside your cabinet. Using a pencil, mark the location G (1) where you plan to install the CABINET SCREWS (F). • Note: To ease the installation you can pre-drill small holes at the marked locations. - Page 4 INSTALLATION INSTRUCTIONS – In Cabinet STEP 3 Align WIRE DRAWER (A) at the marked location and push it into the clips of the LEFT & RIGHT SLIDES (B) & (C). A (1) Installation Suggestion: With the WIRE DRAWER (A) resting on top of the clips, brace the top of the WIRE DRAWER (A) with one hand and, with a rubber mallet, lightly tap each bottom corner of the WIRE DRAWER (A) to secure the WIRE DRAWER (A) into the clips.
- Page 5 INSTALLATION INSTRUCTIONS – On Wire Rack STEP 1 Identify LEFT & RIGHT SLIDES (B) & (C). • Note that the BACK end of each SLIDE (B) & (C) has a black tip and the FRONT end does NOT. B (1) C (1) Place SLIDES (B) &...
- Page 6 INSTALLATION INSTRUCTIONS – On Wire Rack STEP 3 With a Phillips screwdriver, secure the SLIDES (B) & (C) to the wire shelf by putting PLATE SCREWS (E) through the slots and fasten to the RACK PLATES (D). D (4) E (4) STEP 4 Attach the WIRE DRAWER (A) to the clips in the LEFT and RIGHT SLIDES (B) &...
-
Page 7: Service Parts List
SERVICE PARTS LIST Customer Service provides the following replacement parts: Description 1)Plastic Cap 2)Cabinet Screw 3)Template 4)Plate Screw 5)Rack Plate 6)Right Slide 7)Left Slide 8)Wire Drawer... -
Page 8: Care And Maintenance
WARNINGS 1. Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage. 2. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of their environment and ensure that they use the product in a safe and responsible manner. -
Page 9: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a Sliding Wire Drawer. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form (2) complete the Product Registration Form online or (3) scan and email the form. - Page 10 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service.
