  • Page 1 TDS-2 Module TDS-6 Unit User Manual 2.5.5r1...
  • Page 2 ® Endace Measurement Systems EDM05.05-01r1 TDS-2 Module TDS-6 Unit User Manual http://www.endace.com Leading Network Intelligence Copyright © 2005. Published by: ® Endace Measurement Systems Building 7 17 Lambie Drive PO Box 76802 Manukau City 1702 New Zealand Phone: +64 9 262 7260 Fax: +64 9 262 7261 support@endace.com...
  • Page 3 ® Endace Measurement Systems EDM05.05-01r1 TDS-2 Module TDS-6 Unit User Manual http://www.endace.com USE THIS SPACE FOR NOTES © Copyright All rights reserved Version 2. 22 September 2005.

  • Page 4: Table Of Contents

    2.2.2 Connect TDS-2 Module to 12V DC Power Source ..........7 2.3 Connect TDS-2 Module to Code Division Multiple Access Source....... 7 2.4 Connect TDS-2 Module to Global Positioning System Time Signal Source ....8 2.5 Connection to TDS-2 Time Distribution Server Module Applications ......9 2.5.1 DAG Card Signals Output Connection..............
  • Page 5 ® Endace Measurement Systems EDM05.05-01r1 TDS-2 Module TDS-6 Unit User Manual http://www.endace.com USE THIS SPACE FOR NOTES Copyright© All rights reserved Version 2. 22 September 2005.

  • Page 6: Overview

    Earth is collated on the ground by GPS receivers. Receiver units can be mounted on building exteriors or elsewhere with an unobstructed sky view. A GPS receiver unit is connected to a TDS-2 module by fitting a DB25 cable to a DB25-toDB9 adapter on the module.
  • Page 7 TDS-2 Time Distribution Servers, which relay them to DAG cards, PC’s or TDS 6 expander units. The capacity of a TDS-2 module can be expanded six outputs at a time by chaining up to four TDS 6 expansion units without compromising timing accuracy.

  • Page 8: Installing Tds-2 Time Distribution Server Module

    2.1.1 TDS-2 Time Distribution Server Module Architecture Description The TDS-2 module is fitted with cable ports and connectors to receive precise time signal inputs, replicate them, and distribute directly to one or two DAG cards. The TDS-2 architecture features include: •...
  • Page 9 • Timing signal outlet ports Figure Figure 2-1 shows the TDS-2 module face-plate architecture. Figure 2-1. TDS-2 Module Face-plate Architecture. The timing signal outputs are provided through RJ45 connectors, and may be connected to DAG cards with standard Ethernet cables and patch equipment.

  • Page 10: Tds-2 Time Distribution Server Module System Requirements

    TDS-6 module When additional time synchronization outputs are required, the capacity of a TDS-2 module is expanded six outputs at a time without compromising timing accuracy by attaching up to four Endace TDS6 units. One TDS-2 module with the maximum number of TDS-6 expansion modules provides 24 time synchronization outputs derived from a single external time standard.

  • Page 11: Tds-2 Time Distribution Server Module Accessories

    This may be checked with a CDMA cellular phone in digital mode. CAUTION The TDS-2 must never be connected directly to active Ethernet equipment. 2.1.3 TDS-2 Time Distribution Server Module Accessories Description The accessories included with the TDS-2 Time Distribution Server include: •...

  • Page 12: Connect Tds-2 Module To Electrical Mains Power Source

    2.3 Connect TDS-2 Module to Code Division Multiple Access Source Description An RJ45 cable is used to connect a TDS-2 module to a CDMA source via an adapter supplied with the CDMA receiver. The module signal source selection switch is set to CDMA and the LED flashes indicate processes are occurring in relation to timing signal and SERIAL packet activity.

  • Page 13: Connect Tds-2 Module To Global Positioning System Time Signal Source

    When CDMA unit locks onto the network, the CDMA receiver’s LEDs activate, with the PPS LED flashing once per second indicating the timing signal is being received. The PPS LED on the TDS-2 front faceplate should now be flashing. 2.4 Connect TDS-2 Module to Global Positioning System Time Signal Source...

  • Page 14: Connection To Tds-2 Time Distribution Server Module Applications

    Set input signal selection switch to GPS position. This sets the GPS as the active signal source. NOTE: The TDS-2 module LEDs will indicate the GPS receiver status after a 5 to 15 minute delay during which the system correlates orbiting signal sources.

  • Page 15: Pc Connection To Tds-2 Time Distribution Server Module

    2.5.2 PC Connection to TDS-2 Time Distribution Server Module Description Once the TDS-2 module is fully functioning, a PC can be connected via the module’s host connection. The PPS signal and SERIAL data packet is then received by the PC. If the timing signal is being generated by a CDMA receiver, the packet can be read on a PC via a standard terminal package.

  • Page 16: Connecting Tds-6 Time Distribution Server Extension Unit

    3.0 CONNECTING TDS-6 TIME DISTRIBUTION SERVER EXTENSION UNIT Introduction Connecting a TDS-2 module to a TDS-6 Time Distribution Server unit expands distribution of global time synchronization signals to multiple destinations. The TDS-6 expansion unit provides 6 time signal synchronization outputs derived from a single TDS-2 module connection.

  • Page 17: Install Tds-6 Time Distribution Server Extension Unit

    A TDS-6 Time Distribution Server extension unit is firmly fixed in a position where cables are readily accessed without obstruction. Connecting the TDS-6 unit involves inserting the supplied chain cable to the TDS-6 CHAIN 1 port and inserting the other end into a vacant TDS-2 module CHAIN port. Figure Figure 3-2 shows the typical TDS-2 module and TDS-6 unit connection configuration.

  • Page 18: Connect Additional Tds-6 Time Distribution Server Extension Units

    A number of TDS-6 units can be coupled together like a daisy-chain to enable extension of time-synchronization output to more DAG cards or PC’s. If the two TDS-2 module chain outputs are in use, with two TDS-6 units already being connected, additional TDS-6 units can be chained to the first TDS-6 units.
  • Page 19 SERIAL On the back of the unit, check the PPS LED is flashing constantly. NOTE: If the LED’s are not flashing check the TDS-2 module is powered and operating, or check connections. In the event of a function failure contact Endace support;...

  • Page 20: Appendix A - Tds-2 Module, Connector Specifications

    DB25 to DB9 GPS Adapter RS422 RJ45 Timing DB2J to DB9 Signal Output Description The TDS-2 module has two RJ45 socket outputs for connecting to DAG card RS422 synchronisation input port. The socket consists of 8 pins. The pin-out configuration is shown below.

  • Page 21: Rs232 Db9 Cdma Input

    PPS In - Ground Power Out [12V DC] RS232 Host PC Connection Description A standard female DB9 on the TDS-2 module enables connection to a host PC. The pin-out configuration is shown below. PPS Out SERIAL Out Ext-SERIAL In CDMA port, pin 4...

  • Page 22: Rs422 Chain Output

    Figure 5-2. TDS-2 Module Chain Output Pin-out Configuration. DB25 to DB9 GPS Adapter Plug Description The Endace supplied DB25 to DB9 GPS adaptor plug housed in a single body enables connection of the Trimble Acutime receiver to a TDS-2 module.

  • Page 23: Appendix B - Tds-6 Extension Unit, Connector Specifications

    ® Endace Measurement Systems EDM05.05-01r1 TDS-2 Module TDS-6 Unit User Manual http://www.endace.com APPENDIX B – TDS-6 EXTENSION UNIT, CONNECTOR SPECIFICATIONS RS422 RJ45 Timing Signal Output Description There are six RS422 ports on the TDS-6 unit on a RJ45 modular jack that provides synchronized timing signals to DAG card RSS422 input ports.

  • Page 24: Rs422 Chain Connection

    ® Endace Measurement Systems EDM05.05-01r1 TDS-2 Module TDS-6 Unit User Manual http://www.endace.com RS422 Chain Connection Description A two-port, six-position, six-contact modular jack on a TDS-6 facilitates chaining of additional TDS-6 units. PPS In + PPS Out + SERIAL In +...
