4.6.2 Stop in open + closed position (protection against anything being snagged and pulled in) 4.6.3 Stop in closed position (passage protection) 4-10 4.6.3.1 Process of re-opening after triggering during closing 4-10 eißner gate systems Gate control operating manual mts2000/02...
Page 3
Assembly and installation Safety information regarding assembly Fitting gate control mts2000/02 Electrical connection Start-up and operation Programming gate control mts2000/02 6.1.1 Controls of gate control mts2000/02 6.1.1.1 Hardware settings 6.1.1.2 Function of keys 6.1.2 Menu structure of operating software 6.1.2.1 Language setting 6.1.3...
Page 4
Table of contents 7.1.1.1 Testing 7.1.2 Fault rectification 7.1.3 Control PCB measurement points Regular testing Address of manufacturer eißner gate systems Gate control operating manual mts2000/02...
CE mark Gate control mts2000/02 corresponds to the fundamental requirements of the relevant directive (EMC 89/336/EEC, dated 3 May 1989) of the Council of the European Union.
Ship used devices to an authorised recycling plant (separated into metals, plastics etc.). 2.1.1 Information regarding the safety information The safety instructions in these instructions for use MUST be noted and followed. Gate control operating manual mts2000/02 2 - 1 eißner gate systems...
Operation of the control unit is only permitted while its covers and guards are all in position. Ensure that all gaskets and screw connections are properly secured. eißner gate systems 2 - 2 Gate control operating manual mts2000/02...
Purchaser obligation The purchaser must ensure that users are trained in the operation and all safety- related aspects of gate control mts2000/02. A report should be produced by all training course attendees documenting the training they have received and this report should be kept on file.
The programme sequence can be restarted via the emission of a pulse. These voltage peaks can be suppressed on-site (e.g. by inserting a mains filter as close as possible to terminals 43 and 44, or by taking similar measures). eißner gate systems 3 - 2 Gate control operating manual mts2000/02...
(red light(s) flash(es), if fitted). 3. The gate system cannot be started if an error is present. Normal operations can only be continued once the cause of the error has been rectified. Gate control operating manual mts2000/02 4 - 1 eißner gate systems...
Description of product Scope Gate control mts2000/02 can be used wherever a high degree of flexibility and complexity is needed. It is used to activate the gates, refer to Chapter 3.4 (Correct use) The operating modes are programmed via a removable display / keypad module.
Firstly, release plug from connection X1, then remove PCB and bolts The operating and fault statuses appear on the LCD display on the control PCB. Fig. 4 –1 Control PCB with controls Gate control operating manual mts2000/02 4 - 3 eißner gate systems...
Page 14
Description of product Supply lines are guided into the housing via screw connections. Apertures which are not used must be sealed with blind plugs. eißner gate systems 4 - 4 Gate control operating manual mts2000/02...
• impulse for open • impulse for close Activation from either: • internal + / - keys • radio 2 commands triggers the following function: the gate opens or closes. Gate control operating manual mts2000/02 4 - 5 eißner gate systems...
The gate opens or closes for as long as the internal + or – keys are pressed. Note This mode is used for start-up as well as other functions. eißner gate systems 4 - 6 Gate control operating manual mts2000/02...
Care must be taken to ensure that emergency control does not cause damage to the gate and/or does not put people at risk. Note We would recommend using a key-operated switch as the external switch. Gate control operating manual mts2000/02 4 - 7 eißner gate systems...
Halt key A key with a make and break contact can be fitted on-site. The halt function takes preference over all other operating functions; i.e. “live” processes are interrupted. eißner gate systems 4 - 8 Gate control operating manual mts2000/02...
The function of this safety equipment is checked before every gate movement. Precondition: use of one-way light barriers (separate transmitter and receiver). A reflection light barrier can also be connected up but this does not comply with the safety rulings! Gate control operating manual mts2000/02 4 - 9 eißner gate systems...
The hold open time can be set to anything between 1 and 600 seconds. Note This applies to the single/dual lane feedback control operating modes. eißner gate systems 4 - 10 Gate control operating manual mts2000/02...
If the gate does not reach a limit position as a result of the run time set, the system is transferred into error mode. In other words, red light(s) flash(es), if fitted and gate remains motionless. Gate control operating manual mts2000/02 4 - 11 eißner gate systems...
11, 12 Stop in closed position (light barrier, potential-free contact) 24 V / 100 mA Supply for transmitter terminals 16,17 Supply for receiver terminals 16,17 Switching output terminals 14,15 eißner gate systems 4 - 12 Gate control operating manual mts2000/02...
Mechanical data Dimensions W x H x D 160 mm x 250 mm x 127 mm Weight 1800 g Installation position vertical 4.7.2.1 Ambient conditions Temperature range 0° - 60°C Gate control operating manual mts2000/02 4 - 13 eißner gate systems...
VDE 0160: Equipping high power systems and electrical operating equipment VDE 0700: Safety of electrical devices for domestic consumption etc. BGV A2: Electrical systems and operating equipment BGR 232: Guidelines for power-assisted windows, doors and gates Gate control operating manual mts2000/02 5 - 1 eißner gate systems...
Attach cable to terminals according to Chapter 5.3, Electrical connection. Carefully attach control board to plug connections of connection board and use 3 screws to secure. Close and screw down cover. eißner gate systems 5 - 2 Gate control operating manual mts2000/02...
Page 27
Assembly and installation Fig. 5-1 Housing dimensions of gate control Gate control operating manual mts2000/02 5 - 3 eißner gate systems...
The following diagram shows an overview of the connection board. Follow the references on the detailed diagrams. Connect the external inputs and outputs to gate control mts2000/02 as shown in these diagrams. Fig. 5-2 Connection boards of gate control mts2000/02 eißner gate systems...
Page 29
Assembly and installation Attach connections to connection board of gate control mts2000/02: • 24 V connections 1) Gate control (controls) 2) Closing edge protection 3) Protection against anything being snagged or pulled in • 230 V connections 1) 230 VAC connection...
Page 30
Assembly and installation Fig. 5-4 Closing edge control eißner gate systems 5 - 6 Gate control operating manual mts2000/02...
Page 31
Assembly and installation Fig. 5-5 Passage protection and protection against anything being snagged or pulled in, earthing 0 V Gate control operating manual mts2000/02 5 - 7 eißner gate systems...
Page 32
Assembly and installation Fig. 5-6 Passage protection and protection against anything being snagged or pulled in, earthing 0 V eißner gate systems 5 - 8 Gate control operating manual mts2000/02...
Page 33
Assembly and installation Fig. 5-7 Light connection and potential-free contact Gate control operating manual mts2000/02 5 - 9 eißner gate systems...
Page 34
Assembly and installation Fig. 5-8 Emergency control and mains connection eißner gate systems 5 - 10 Gate control operating manual mts2000/02...
Page 35
Assembly and installation Fig. 5-9 Drive Gate control operating manual mts2000/02 5 - 11 eißner gate systems...
6.1.1 Controls of gate control mts2000/02 Gate control mts2000/02 is programmed using 4 keys (refer to Fig. 4-1) on the control unit display board. The individual menu items of the control unit software are shown on the display. The keys are suppressed and have to be held down for around 1 second before they will respond.
Page 38
Start-up and operation Fig. 6-1 Removable display module with programming keys eißner gate systems 6 - 2 Gate control operating manual mts2000/02...
The value selected is entered by confirming the question “Save?”. 6.1.2 Menu structure of operating software Fig. 6-2 Menu levels of operating software for gate control mts2000/02 6.1.2.1 Language setting The language is set on the display. For more information, refer to Chap. 6.1.4 Service, “Language”.
Assignment during operating mode for impulse control H A Z A R D F L A S H Time between impulse emission and gate closing motion, red light flashes eißner gate systems 6 - 4 Gate control operating manual mts2000/02...
Page 41
R E D I G H T G A T E off: red lights off when gate is closed. C L O S E D O P T Gate control operating manual mts2000/02 6 - 5 eißner gate systems...
Page 42
Reject changes --> press "M". H O L D D O W N Press for 5 seconds Save is acknowledged. S A V E ? S A V E D eißner gate systems 6 - 6 Gate control operating manual mts2000/02...
Change: hold down + and –, then press P Time after which the gate reopens when R E V E R S E I M E closing after closing edge or stop in closed position. Gate control operating manual mts2000/02 6 - 7 eißner gate systems...
S A V E D 6.1.5 Operation Gate control mts2000/02 requires no operation. It is operated as part of the entire gate system using the controls connected to the system such as remote control, keys, continuously open switch. eißner gate systems...
1. De-energise the system before assembly. 2. Attach clock to the intended connection point (refer to Fig. 4-1). 3. Re-energise system. 6.2.2 Programming In accordance with the programming instructions enclosed with the clock. Gate control operating manual mts2000/02 6 - 9 eißner gate systems...
Start-up and operation Operating instructions for radio mts2000/02 The radio (item 91) can be retrofitted. The radio module is equipped with 2 channels, e.g. entrance and exit for one lane mode with automatic closing. 6.3.1 Assembly 1. De-energise the system before assembly.
No function No function Channel 1 No function Channel 1 Channel 2 Channel 1 6.3.4 Displays Press left key, LED 1 lights up Press right key, LED 2 lights up Gate control operating manual mts2000/02 6 - 11 eißner gate systems...
21 or 24 when jumpers J2 and/or J3 are 7.1.2 Fault rectification Impact Rectification Gate not in end position Issue new command using keys or key- operated switches etc. If nothing moves; call Service! Gate control operating manual mts2000/02 7 - 1 eißner gate systems...
Page 51
Closing edge inactive, conductor Voltage failure Continuously open or impulse Voltage Continuously sequence activated (contact +/- 10% open and/or closed) impulse Continuously open or impulse sequence Voltage sequence not activated (contact open) Gate control operating manual mts2000/02 7 - 3 eißner gate systems...
Page 52
Voltage not activated (contact closed) Voltage Impulse for halt and stop not Impulse for +/- 10% activated (contact closed) halt Impulse for halt and stop Voltage activated (contact open) eißner gate systems 7 - 4 Gate control operating manual mts2000/02...
Page 53
Test stage 2 Test stage 3 Test stage 4 After test 5. Close housing again once test is complete. If result of testing is negative, shut down system and call service. Gate control operating manual mts2000/02 7 - 5 eißner gate systems...
