Summary of Contents for StarLogixs GateKeeper RR-07
- Page 1 GateKeeper Remote System Operating Instructions For Rev2.0 Units Receiver Model: RR-07 Remote Model : RT-07 Complies To: AS/NZS4251.1.1999 N10728 FCCPart15(B)
-
Page 2: Table Of Contents
Contents Remote Set-up……..…………………….…..3 Receiver Set-up…………………………….…4 Control Function…….………………….……5 Range and Interference…………………..…..5 5. Receiver Connector Pin-Outs……………...6 6. Standard Receiver Wiring Connections….6 7. Switching Inductive Loads……………...…..7 8. Driving an Electric Motor- Reversible Direction………………………….9 9. Trouble Shooting……………………………..10 10. Specifications………………………………….11... -
Page 3: Remote Set-Up
Remote Set-up 4 Or Less Controlled Devices 5 to 8 Controlled Devices You only require one remote. You will require two remotes with Leave it set on the factory default one set on Low Channel and the Low Channel range. other on High Channel. -
Page 4: Receiver Set-Up
Receiver Set-up Setting the Receiver Channel Remove 4 screws and remove case lid. Using a small flat blade screwdriver rotate the channel switch until the arrow points at the channel number selected in Step 2 of remote set-up. Refit the case lid. Take care to ensure lid seal is in place. Note 1: Power must be off when adjusting the channel switch. -
Page 5: Control Function
Control Function All functions on the remote unit are a 'dead-man' type operation. That is - the function only works while the key is held depressed. As soon as the key is released the device being controlled will stop. The Close key on the remote will drive N/O 1 on the receiver. The Open key on the remote will drive N/O 2 on the receiver. -
Page 6: Receiver Connector Pin-Outs
Receiver Connector Pin-outs The receiver connectors are located on the receiver printed circuit board. The pin-out is shown below. The receiver must be powered by a stable 12V dc power source. The receiver has an internal self-resetting fuse, but it is also advisable to fit an in-line 1 amp fast blow fuse in the +ve power wire. -
Page 7: Standard Receiver Wiring Connections
Standard Receiver Wiring Connections Connection is as below: The above wiring scheme should work for most applications, however the normally open relay contacts in the Receiver can be wired in vari- ous other circuit layouts depending on specific electrical requirements. The exact design of specialised applications is beyond the scope of this document. -
Page 8: Driving An Electric Motor-Reversible Direction
Driving an Electric Motor - Reversible Direction If the motor is 12v then the motor power source and the receiver power source could be the same unit. Separate power sources allow for differ- ent motor voltages. To allow the motor to be reversed using this scheme the motor must be a DC type. -
Page 9: Trouble Shooting
Trouble Shooting No Function 1) Ensure the remote unit has fresh batteries. Only use quality AA alkaline type dry cell batteries. 2) Ensure the receiver unit is powered with a 12V dc supply, and that the supply is capable of supplying the current requirements of any actuators fitted. -
Page 10: 10. Specifications
10. Specifications Remote Unit Transmission Frequency 433.92MHz Transmission Bandwidth 100kHz Transmission Power 3dBm Power Supply 3 x AAA Batteries Standby Current Draw Transmit Current Draw Low Band Channels High Band Channels Channel Encoding Digital PWM Dimensions 117x78x24mm Weight (including batteries) 140g Environmental Sealing IP55... - Page 11 Starlogixs Pty. Ltd. Trademarks...
