Eickemeyer MAGIC 500 User Manual

Ultrasonic diagnostic instruments
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Eickemeyer
MAGIC 500
Ultrasonic Diagnostic Instruments
User's Manual
Information for Users
Users shall carefully read through this manual and fully understand the text before operating the equipment. This manual shall
be placed easy of access for future reference; otherwise it may cause instrument damage or person injury.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAGIC 500 and is the answer not in the manual?

Questions and answers

Related Manuals for Eickemeyer MAGIC 500

Summary of Contents for Eickemeyer MAGIC 500

  • Page 1 Eickemeyer MAGIC 500 Ultrasonic Diagnostic Instruments User’s Manual Information for Users Users shall carefully read through this manual and fully understand the text before operating the equipment. This manual shall be placed easy of access for future reference; otherwise it may cause instrument damage or person injury.
  • Page 2 Eickemeyer. No persons may reproduce this user’s manual, in whole or in part, including but not limited to photography, photocopy, reprint or translation into any other language without prior written consent of Eickemeyer.
  • Page 3 Follow the procedure below if you need to return the purchased equipment: To obtain the right to return the goods, contact local dealer of Eickemeyer Company, indicating product serial number (on the packing case) or parts serial number (on the part), product model, and reason to return the product (through the dealer to return the products or parts).

  • Page 4: Table Of Contents

    Indicates that make sure refer to relevant contents in this manual. 2. Safety Symbols Symbols Meaning Symbols Meaning Type B applied part Fragile Power supply indication Stacking limit by number AC Power Temperature limits DC Power Humidity limitation Atmospheric pressure limitation Marking for the separate collection of Keep dry electrical and electronic equipment...
  • Page 5 5 . 4 B i n d t h e A r m - B a n d … … … … … … … … … … … … … … … … … … … … … … … … … … … … 6 5 .

  • Page 6: Chapter One Technical Specifications

    6 . 1 4 C a s e r e p o r t p r o c e s s i n g c e n t e r V 3 . 1 s o f t w a r e ( o p t i o n a l ) … … … … … … … … … … … … … … 1 5 C h a p t e r S e v e n G e n e r a l M e a s u r e m e n t …...

  • Page 7: Structure Composition Of The Instrument

    Chapter Two System Outline and Structure 2.1 Structure composition of the instrument MAGIC 500 ultrasonic diagnostic instrument is composed of main unit and probe, etc. 2.2 Components name Fig. MAGIC 500 main unit sketch map 2.3 Parts of the probe (Take 6.5MHz animal transrectal linear array probe for example) Fig.

  • Page 8: Operation Condition

    Mode Selection Text Input Enter Confirm menu Main-menu / Cine loop Freeze/Unfreeze Direction Keys Quit Power switch Chapter Three System Configuration 3.1 Typical configuration 1. Main unit 1 PC 2. 6.5MHz animal transrectal linear array probe 1 PC 3. Internal battery 2 PC 4.

  • Page 9: System Placement

    1. When instrument works abnormally, do stop working, turn off the power and check the reason, then contacts the EICKEMEYER Company about it. 2. Turn off power and pull out of the plug from socket after each ultrasonic diagnostic operation.

  • Page 10: Probe Installation

    5.2 Probe installation Warning: 1. The Eickemeyer ultrasonic probe shall be connected to the dedicated Eickemeyer ultrasonic system only. Select proper probe model according to the relevant instructions of ultrasonic diagnostic system.

  • Page 11: Bind The Arm-Band

    1. Adapter has no switch. The isolation of the system with the MAINS used to unplug the adapter as the intended isolation means. 2. The device should be used only with power adapter provided by Eickemeyer Company. 3. To avoid damaging power adapter or harming people by unexpected fallen, make sure the power adapter is placed on the leveled desk.

  • Page 12: Main Unit Check Before And After Operation

    Check if there are any exceptionally on the surface of the probe or cable jacket, such as peeling, cracks, bulge, or if the acoustic lens is reliable, disinfected or cleaned. 5.9 Main unit check before and after operation 5.9.1 Inspection before start-up Check the following items before starting the machine: 1.

  • Page 13: Tv Mode Setting

    3. Press direction keys to select Minutes, Hours, Day, Month and Year; 4. When setting minutes, hours, day, month and year, press direction key to increase value or press direction key decrease value; 5. Press key to confirm the time setting and quit setting interface. 6.2.2 TV Mode Setting 1.

  • Page 14: Compression Curve Setting

    6.2.7 Compression Curve Setting 1. Press key to enter main-menu and press direction keys to move cursor to “Preset”; 2. Press direction keys to enter setting interface; 3. Press direction keys to move symbol “<” to point to “Compression Curve”; 4.

  • Page 15: I M A G E G A I N A N D D Y N A M I C R A N G E A D J U S T M E N

    mode. 3. Change of M speed: Press key to enter main-menu and press direction keys to move cursor to “M Speed” and then press direction keys to select the eight kinds of scan speed. Or left click mouse to switch M speeds. 4.

  • Page 16: D E P T H S E L E C T I O N A N D D E P T H E N H A N C E M E N

    In real time B mode, press key to enter main-menu and press direction keys to move cursor to “Local Zoom” in the display area and then press direction keys , a box appears. Press direction keys or operate mouse to move the box to the position to be enlarged, the selected image be enlarged;...

  • Page 17: B O D Y M A R K A N D P R O B E M A R

    key to unfreeze the image. 6.9 Body Mark and Probe Mark This product contains 22 body marks that are divided into two pages when display. The operation steps are as follows: 1. In frozen status, press key to enter main-menu and press direction keys to move cursor to “Body mark”, press key, body marks will be showed in the image area, press direction keys to change pages;...

  • Page 18: S I N G L E D U M P A N D M A S S D U M

    Explanation: 1. When reading images, it must choose the image code with “*”. The stored and read out images are all black and white images. 2. In the status for saving or reading images, press key, can delete the image with “*” mark in main unit or in the U disk.

  • Page 19: T E X T I N P U

    Press key unfreeze and quit playback status. Note: If the images appear abnormal, that is without enough storage time and the images have not been stored full. 6.13 Text Input Operation steps: 1. Freeze image; 2. Press key, the cursor is located behind name; 3.
  • Page 20 Chapter Seven General Measurement 7.1 Distance Measurement 1. In B, B/B or B/M mode, choose desired image and freeze it, the cursor is located in the “Measure” position of display area; 2. Press key, the measurement methods are showed in the lower left of the screen, press direction keys choose “Distance”, press key again, the cursor will show “+”;...
  • Page 21 elliptic curve appears; or click middle mouse to appear elliptic curve; 5. Press key, the “ ”mark appears on the screen. Hold down key to change the minor axis of the ellipse so as to satisfy the test area. The measured values are displayed at the built-in characters “C: 00000mm, A: 00000mm , V: 00000 cm ”...
  • Page 22 in the right area of the screen; 6. Press key or repeatedly click left mouse to exchange the start and end; 7. Press key or click right mouse to finish the first measurement; 8. Repeat the steps from 3 to 7 to complete the multi-group data measurement; 9.
  • Page 23 Chapter Nine System Maintenance The system maintenance should be performed by the user and service engineer. Users shall be in full charge of maintenance, repair and operation of the system after purchasing the product. 9.1 Maintenance by users 9.1.1 System clean, disinfect and sterilize Warning : Turn off the instrument and pull out the power supply wire before cleaning every instrument of the system.
  • Page 24 4. The battery can be charged hundreds of times, but it will be exhausted gradually. When the work time decreased sharply, the battery should be replaced; 5. Only the battery provided by Eickemeyer Company can be used. The charging time should be less than 12 hours for one time, otherwise, that will short the battery life;...
  • Page 25 Attention: A power indicator will appear “X” and glitter continually when the electric quantity is too low. Connect the main unit to external power supply and recharge the battery, or turn off the machine to recharge. Attention: Don’t throw away the exhausted battery anywhere; especially throw it in the fire.

  • Page 26: Replace The Battery

    9.4 System maintenance To ensure the performance and safety of instrument, it must be checked after using 1 year. When check the instrument, please consult the factory-authorized distributor of Eickemeyer Company for service, as they need to have professional technology engineers.
  • Page 27 Peripheral Enclosure leakage current peripheral equipment Recorded images using equipment Patient leakage current Other mechanical part typical probe Dielectric strength Probe appearance Chapter Ten Storage and Transportation Storage and Transportation 1. If the instrument is stored over 3 months, take out the instrument from the packing case, connect it to power supply for 4 hours, and then disconnect the power and place it in the case again following the direction indicated by arrows on the package.
  • Page 28 Appendix : System Block Diagram Keyboard Microcomputer control system Clock Probe Line/field sync signal Transmission Signal Collating Display synthesis Process & Reception...
  • Page 29 E I C K E M E Y E R Medizintechnik für Tierärzte KG Eltastraße 8 78532 Tuttlingen Germany tel.: ++49 (0) 7461 96580 0 fax: ++49 (0) 7461 96580 91 mail: export@eickemeyer.de web: www.eickemeyer.de Information contained in this manual is subject to change without further notice.
