INSTRUCTION MANUAL
NEO TP500
NEO TP500
SPA CONTROL TOUCHSCREEN
Designed,
Engineered &
Manufactured
2200 E. Sturgis Road, Oxnard CA 93030 • Phone 805.981.0262 • Fax 805.981.9403
in the USA.
waterway@waterwayplastics.com • www.waterwayplastics.com
810-0284.0819
©2019 Waterway Plastics

Advertisement

loading
Need help?

Need help?

Do you have a question about the NEO TP500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Waterway NEO TP500

  • Page 1 INSTRUCTION MANUAL NEO TP500 NEO TP500 SPA CONTROL TOUCHSCREEN Designed, Engineered & Manufactured 2200 E. Sturgis Road, Oxnard CA 93030 • Phone 805.981.0262 • Fax 805.981.9403 in the USA. waterway@waterwayplastics.com • www.waterwayplastics.com 810-0284.0819 ©2019 Waterway Plastics...
  • Page 2 SAVE THIS MANUAL PLEASE MAKE IT AVAILABLE TO ALL OTHER SPA USERS WARNING! Qualified Technician Required for Service and Installation BASIC INSTALLATION AND CONFIGURATION GUIDELINES • Use minimum 6AWG copper conductors only. • Readily accessible disconnecting means to be provided at time of installation. •...
  • Page 3 TP500 OPERATION Software Version 71.06.1 PRIMING MODE: When power is ON, the system will enter Priming Mode. In this mode, all devices such as JETS, BLOWERS or LIGHT are operable. JETS can be turned on and off to prime the pump. The system will exit priming mode and go to the MAIN display when the Circle icon is tapped, or after 4 minutes of inactivity.

  • Page 4: Status Icons

    MAIN SCREEN CONTROL ICONS STATUS ICONS FILTER CYCLE 1 - ON LIGHT - ON LIGHT - OFF FILTER CYCLE 2 - ON JET 1 HIGH - ON JET 1 - OFF FILTER CYCLE 3 - ON JET 2 HIGH - ON JET 2 - OFF FILTER CYCLE 4 - ON JET 3 HIGH - ON...
  • Page 5 NEO TP500 MAIN SCREEN CONTROL The Main Screen displays current time, water temperature, spa setting temperature, and status of the system accessories in the center of the screen. To change spa set temperature, tap the spa set temperature number. Select the appropriate temperature level and tap SAVE to save the desired setting or EXIT to reverse back to the last setting without saving the setting.
  • Page 6 NEO TP500 SETTING SCREENS GENERAL SETTINGS: This will allow user to change the following settings: DEGREE F/C: displays spa temperature in Celsius or Fahrenheit. This option is only available for 60 Hz countries. TIME DISPLAY: displays spa time in 12 hours, AM/PM or 24 hours time.

  • Page 7: Error Codes

    NEO TP500 SETTING SCREENS (continued) BACKGROUND SETTING: allows user to set one of the 6 backgrounds for the spa application CLEANER CYCLE SETTING: sets the duration and starts the additional filtration period after using the spa. Only available for Non-Circs configurations.
  • Page 8 THERAPY SPA WITH VARIABLE SPEED PUMPS The TP500 operates and programs your spa. The basic function icons are described below. SPA FUNCTION ICONS JET 1 (SPEED) ICON: Tap the white JET 1 icon once to turn Therapy Pump 1 on. Jet 1 will run at 40% speed (default setting low), and the yellow jet low icon will appear on the display.
  • Page 9 SPA FUNCTION ICONS (continued) FILTER CYCLE PROGRAMMING: At the start of Filter Cycles 1-4 the VS JET 1 will run on 40% speed, JET 2 (2-speed pump) will run on low for 15 seconds to prevent the spa water from becoming stagnant in the plumbing and air lines and to improve skimming action (removing debris and suspensions from the water surface).
  • Page 10 NEO TP500 WI-FI OPERATING INSTRUCTIONS Touch the glass panel to start up the display. Make sure your Touch Screen panel is connected to your home Wifi and you have a good signal. On the main screen, swipe to the left and tap the Wi-Fi Remote Control Icon.
  • Page 11 NEO TP500 WI-FI OPERATING INSTRUCTIONS (continued) Download and install the App from the App Store or Google Play. Select Create Account. Enter your email address, password, confirm and submit. Select the configured device to connect. i.e. MySpa. The App is connecting to the device.
  • Page 12 NEO TP500 WI-FI OPERATING INSTRUCTIONS (continued) The Light, Jets, and Blower can be turned on and off. Select ‘Spa Set Temperature’ to adjust the set temp. Swipe up or down to adjust the temperature. EXIT to go back or SAVE to save the setting.
  • Page 13 NEO TP500 WI-FI OPERATING INSTRUCTIONS (continued) Select Panel Settings to display the settings for the NEO. Select General Info to display information about the NEO controller. Select General Settings to display the options listed. Select Degree F/C to choose between Fahrenheit or Celsius.
  • Page 14 NEO TP500 WI-FI OPERATING INSTRUCTIONS (continued) Select Device Timeout to show a list of devices that can be adjusted. Light Timeout can be as low as 5 minutes or as high as 240 minutes. Pump High Timeout can be as low as 5 minutes or as high as 60 minutes.
  • Page 15 NEO TP500 WI-FI OPERATING INSTRUCTIONS (continued) Water Temp Check Time can be set as low as 15 or 30 minutes or as high as 240 minutes. Adjust date and time by moving fields up or down. Select Save to set.
  • Page 16 NEO TP500 WI-FI OPERATING INSTRUCTIONS (continued) Each filter cycle can be customized. By default; Filter Cycle 1 = 8:00 am, 2 hrs and Filter Cycle 2 = 8:00 pm, 2 hrs. Select Quiet Timer to set the times that the NEO will not run pumps.
  • Page 17 NEO TP500 WI-FI OPERATING INSTRUCTIONS (continued) Select Cleaner Cycle to set the number of minutes for the cycle to run. START will start the cycle. Select Update System to update the App if the Configuration has been changed on the NEO.

  • Page 18: Wiring Diagram

    WIRING DIAGRAM 777-WW00800 50 Hz with DB2 Daughter Board JL29 JL30 JL23 JL24...
