Page 1 Aoralscan 2 IntraoralScan User Manual...
Page 2: Table Of Contents
Aoralscan 2 User Manual CATALOG Read this First ................- 3 - Safety Information ............... - 8 - Overview ................... - 20 - Setting up the Scanner .............. - 29 - 4.1. Connecting the Scanner ........... - 29 - 4.2.
Page 3 Aoralscan 2 User Manual 7.3. Introduction to Dental Order System ........ - 51 - 7.3.1. Information ..............- 52 - 7.3.2. Order list ..............- 54 - 7.3.3. Setting ............... - 57 - 7.3.4. Data storage .............. - 60 - 7.4.
Page 4: Read This First
Aoralscan 2 User Manual 1. Read this First The Aoralscan 2 is an intraoral scanner that works with the supplied software programs. With Aoralscan 2, you can perform oral scanning and digitally acquire and save the 2D/3D color images of a patient’s teeth for orthodontic, implant, and restoration use.
Page 5 Aoralscan 2 User Manual Updates to hardware and/or software components are made regularly; therefore, some of the instructions, illustrations, and specifications mentioned in this User Manual may differ slightly from your particular situation. To obtain the most updated and accurate information, visit en.shining3d.com...
Page 6 The software in no way interprets these images or provides a medical diagnosis of the patient being examined. 1.4. Warnings Before using the Aoralscan 2,read these warnings and Safety information on chapter 2. WARNINGS  Do not attempt to disassemble, repair, or modify the scanner and software.
Page 7 Aoralscan 2 User Manual  The device should not be used adjacent to or stacked with other equipment. If adjacent or stacked use is necessary, the device should be observed to verify normal operation in the configuration in which it will be used.
Page 8 1.8. Warranty The warranty is void if unauthorized personnel perform service or maintenance on the set of Aoralscan 2. To ensure correct product performance and to obtain warranty service, contact technical support. For more information, see the following.
Page 9: Safety Information
Aoralscan 2 User Manual 2. Safety Information 2.1. Precautions WARNING Follow procedures carefully ensure that power/electrical/environmental requirements are satisfied. Failure to observe the instructions or disregard the warnings may result in damages to the product, personal injury, or even death of the user or the patient.
Page 10 Aoralscan 2 User Manual package.  Connecting the scanner to an unknown power adapter is very dangerous and may lead to fire or explosion.  Using cables or accessories other than those specified for use with the scanner may result in increased emissions or decreased immunity of the device.
Page 11 Aoralscan 2 User Manual 2.2.1. On the Device Specification of scanner serial number Serial number AOS-AH001K13 represents the No.001 device produced on November 13. 2018.  AOS…represents the type of scanner which is the abbreviation of Aoralscan2.  AH…represents the productive year, the letter A to I in alphabetical order represent number 1 to 9 and the number 0 remains the same.
Page 12 Aoralscan 2 User Manual Indicates correct upright position of the transport package. Indicates that the material shall be recycled. Table 2-2 Labels and symbols on the carry box/package 2.3. Compliance Anyone creating or changing a medical electrical system through a...
Page 13 The Aoralscan 2 is intended for use in the electromagnetic environment specified below. The customer or user of the Aoralscan 2 should assure that it is used in such an environment.
Page 14 Table 2-3 Guidance and manufacturer’s declaration–electromagnetic emissions Interference immunity The Aoralscan 2 is intended for use in the electromagnetic environment specified below. The customer or user of the Aoralscan 2 should assure that it is used in such an environment. IEC 60601 test...
Page 15 Aoralscan 2 User Manual 0% UT (100% dip 0% UT (100% dip in in UT) for 0.5/1 UT) for 0.5/1 cyclea cyclea Mains power quality should 40% UT (60% dip in 40% UT (60% dip that typical UT) for 5 cycles...
Page 16 Aoralscan 2 User Manual Electromagnetic Immunity test IEC 60601 test levels Compliance level environment – guidance Portable and mobile RF communications equipment should be used no closer to any part of the Aoralscan, including cables, than the 3 Vrms 150 kHz to...
Page 18 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the Aoralscan 2 is used exceeds the applicable RF compliance level above, the Aoralscan 2 should be observed to verify normal operation.
Page 19 Aoralscan 2 User Manual Separation distances The Aoralscan 2 is intended for use in the electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the Aoralscan 2 can help prevent electromagnetic interference by maintaining...
Page 20  Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 30 cm (12 inches) to any part of the Aoralscan 2, including cables specified by the manufacturer. Otherwise, degradation of the performance of this equipment could result.
Page 21: Overview
3. Overview 3.1. Benefits of the Product The Aoralscan 2 is designed to provide powder-free intraoral color scanning, with higher speeds bringing greater accuracy and less time-lag for image acquisition. It can be used to scan a single tooth, multiple teeth, and whole dental arches.
Page 22 Aoralscan 2 User Manual shipped) 5. 1 x USB 3.0 cable (for the connection between the cradle and your computer; cable length: 1.5 meters) 6. 1 x medical grade AC/DC power adapter (manufacturer: Adapter Technology Co., Ltd.; model name: ATM020-W120U; input: 100-240 V, 50-60 Hz, 0.45-0.27 A;...
Page 23 Aoralscan 2 User Manual WARNINGS  AC plug types vary by country/region.  Using accessories, peripherals, or cables not supplied with the product or recommended by Shining3D Corporation can affect the device in the form of increased emissions or decreased immunity to external EMI/EMC occurrences.
Page 24 Aoralscan 2 User Manual 3.3. Scanner Overview 3.3.1. Tip and scanner body Component Function Use the tip to scan the upper jaw, lower jaw, or total jaw. Scanner tip The tip(s) can be autoclaved up to 20 times. The anti-condensation heater prevents fogging on the Heater mirror to ensure successful scanning.
Page 25 For connecting the scanner cradle and the USB port of USB 3.0 your computer using the supplied USB cable.This port downstream transfers data between the Aoralscan 2 and your port computer. Connect the scanner cable to this port. USB 3.0...
Page 26 Aoralscan 2 User Manual NOTES  When the scanner is left idle for 10 minutes (including being placed on a desk), it will go into standby mode. After 1 minute of inactivity, it will automatically go into sleep mode, and the LED ring light on the end of the scanner body will also go off.
Page 27 Aoralscan 2 User Manual 3.4. Software Overview Aoralscan 2 is designed to operate with software programs,which include two modules (supplied in the 2-in-1 USB dongle):  Dental Order System Module Designed to manage and store patient data, including cases, prescriptions, and restoration information,realizing functions such as order creation, editing, searching, scanning and deletion, as well as uploading, downloading, previewing and tracking of scanned order and data.
Page 29 Aoralscan 2 User Manual 3.4.2. Installing the software programs The supplied 2-in-1 USB dongle contains the IntraoralScan software program. CAUTIONS  Install the software programs in accordance with the instructions given here.  When the installation is completed, do not plug the power adapter to the wall outlet or turn on the scanner yet.
Page 30: Setting Up The Scanner
Aoralscan 2 User Manual 4. Setting up the Scanner 4.1. Connecting the Scanner CAUTIONS  Ensure the supplied software programs are installed on your computer before the connection.  Install the scanner in accordance with the instructions stated in this User Manual.
Page 31 Aoralscan 2 User Manual (2) Insert the power plug of the supplied power adapter into the power connector on the cradle, and plug the power adapter into a wall outlet. (3) Connect the scanner cable to the USB 3.0 upstream port on the cradle.
Page 32: Disconnecting The Scanner
Aoralscan 2 User Manual 4.2. Disconnecting the Scanner CAUTION Do not attempt to directly disconnect the scanner by removing the power cable and USB cable. Follow the steps below to safely disconnect the scanner: (1)Quit the IntraoralScan scanning software. (2)Turn off the power switch on the cradle.
Page 33 Aoralscan 2 User Manual Follow the steps below to perform the calibration: (1) Insert the power plug of the supplied power adapter into the power connector on the cradle, and plug the power adapter into a wall outlet. (2) Connect the scanner cable to the USB 3.0 upstream port on the cradle.
Page 34 Aoralscan 2 User Manual NOTES  Do not place your finger(s) on the mirror of the tip when detaching as this may result in damage to the mirror.  Store the detached tip in a safe place, e.g. a dental instrument tray, for future use.
Page 35 Aoralscan 2 User Manual (10) Click Calibration.If the Calibrator was not closely plugged onto the scanner, a warning message would be popped up. So, make sure the scanner be plugged into the calibration firmly before next operation. (11) Click Start. The status bar shows the percentage of completion.
Page 36 Aoralscan 2 User Manual (13) Gently slide the Calibrator off the scanner. CAUTION Make sure that the Calibrator is removed from the scanner after the calibration is done. Otherwise, the Calibrator temperature may get very high. (14) Re-attach the scanner tip to the scanner for later use or put the protection cap onto the scanner to prevent damage and dust.
Page 37: Scanning Sreparation
Aoralscan 2 User Manual 5. Scanning Sreparation 5.1. Scanning Basics Read and follow the guidelines and tips given in this chapter prior to acquiring quality images. WARNING Concerning hand hygiene and personnel safety when performing a scan, you must wear clean surgical gloves through the whole process.
Page 38 Aoralscan 2 User Manual to a power source and powered on, and IntraoralScan is launched and ready to work.  To avoid condensation on the mirror of the tip when scanning, the scanner tip must have been warmed up. For details, see Heating the scanner tip on chapter 5.
Page 39 (2) Gently and carefully attach the scanner tip to the scanner body, with the mirror facing downward. (3) Connect the power supply to the Aoralscan 2. For details, see Connecting the scanner on chapter 4. (4) Place the scanner in the cradle to secure it in place.
Page 40 Aoralscan 2 User Manual When the message disappears, the warm-up is done. The scanner is now ready for an acquisition. NOTES  The heater maintains constant temperature on the scanner tip.  The scanner tip is being heated whenever power is supplied, even if the scanner is in standby or sleep mode.
Page 41: Clinical Case Quick Guide
Aoralscan 2 User Manual 6. Clinical Case Quick Guide 6.1. Connection the Scanner See Chapter 4 “Connecting the scanner”for details 6.2. Calibration See Chapter 4 “Connecting the scanner” for details.In order to ensure the quality of the scanned data, it is necessary to perform calibration periodically (recommended every 15 days).
Page 42: Activate The Scanner
Aoralscan 2 User Manual displayed. 6.4. Activate the scanner When the scanner is first used, it must be connected to the internet and activated successfully. Double-click the intraoralScan icon on the desktop, open the order system. The interface will pop up as below Please make sure the computer has been connected to the Internet, click “Yes”...
Page 43 Aoralscan 2 User Manual shown in the figure below, the scan position is incorrect. You need to move the scan tip to scan the data displayed in the red frame. Click the “ ” button in the right side and then it will turn to “...
Page 44: Scan Lowerjaw
Aoralscan 2 User Manual Confirm that the model scan is complete.Click the finish button long press the space bar to process and save the data. After the completion, the upper jaw icon is green and ticked, indicating that the scanning process is finished.
Page 45 Aoralscan 2 User Manual After the stitching After the upper and lower jaws’ data are stitched successfully as well as the whole jaw, click “ ” or press the space bar to pause the scanning, check the occlusion and collision results.
Page 46: View Result Data
Aoralscan 2 User Manual 6.8. View Result Data View result data in IntraoralScan 6.8.1. View upperjaw/ lowerjaw 6.8.2. View the occlusal effect Copyright  2019 All Rights Reserved - 45 - SHNING 3D TECH Co.,Ltd...
Page 47: Pre-Design
Aoralscan 2 User Manual 6.9. Pre-Design See Chapter 7 “Pre-Design” for details on pre-design functions. 6.10. View Data Storage Path Click the button to return to the order interface and click to open the folder path of the current order storage.
Page 49: Using Intraoralscan
Aoralscan 2 User Manual 7. Using IntraoralScan 7.1. Introduction to IntraoralScan IntraoralScan includes three modules: calibration module,dental order system and scan module.  Calibration module is mainly used to calibrate the accuracy of scanner and ensure the quality of scan data, it contains three functions which are accuracy measurement, intensity control and calibration.
Page 50: Accuracy Checking
Aoralscan 2 User Manual 7.2.1. Accuracy Checking Accuracy checking is used to check the accuracy validity of existing calibration result of the scanner. Connect the scanner and calibrator correctly as shown, click “Start” button Copyright  2019 All Rights Reserved - 49 - SHNING 3D TECH Co.,Ltd...
Page 51: Brightness Adjust
Aoralscan 2 User Manual to proceed the accuracy measurement, continue the next step according to the testing result. 7.2.2. Brightness Adjust Brightness adjust is to correct the brightness of scanner and improve the color fidelity of scan data. It is recommended to proceed the intensity control every 3 months.
Page 52: Introduction To Dental Order System
Aoralscan 2 User Manual Connect scanner and calibrator correctly as shown, click “Start” button to proceed the calibration. The successful (or failed) calibration will pop up the corresponding information dialog. 7.3. Introduction to Dental Order System Double-click the desktop icon to open the software to dental order system.
Page 53: Information
Aoralscan 2 User Manual The dental order system is mainly composed of three parts:order information, order list and setting. 7.3.1. Information (1) Button column  New: Create a new order.  Load: Load a saved order.  Save: Save the new order with the completed order information.
Page 54 Aoralscan 2 User Manual  Preview: After the order scan is completed, the scanned data is viewed through the DentalViewer.  Upload: After the order scan is completed, the current order data is uploaded to the dental cloud.  Choose lab: choose a lab in the drop-down list ...
Page 55: Order List
Aoralscan 2 User Manual  Shift+left click to button, copy the type of repair defined by the previous tooth to all the teeth between the tooth position of the same jaw and the last tooth position.  Clear current: Clear the defined repair type of the currently selected tooth position.
Page 56 Aoralscan 2 User Manual order status.  Need Scan: orders that have not been scanned. The right-click menu or operate icons for such orders are: Load/Open in Explore/Duplicate/Delete.  Need Upload: Orders that have been scanned but have not been uploaded order data to the dental cloud.
Page 57 Aoralscan 2 User Manual before uploading the design. The right-click menus or operate icons for such orders are: Load/Open in Explore/Duplicate/Delete/Re-Upload.  Canceled: Order data has been uploaded to the dental cloud, and the doctor has cancelled the order. Doctors can refuse to take orders before the labs uploads the design.
Page 58: Setting
Aoralscan 2 User Manual Request Re-delivery. Confirm Received. 7.3.3. Setting Users can view or set specific information through the setting button on the software interface. (1) Save EXO order: The exocad order *.dentalProject is saved while saving the order. You can import the order into the EXO design software for design.
Page 59 Aoralscan 2 User Manual (4) Dental Notation: FDI World Dental Federation notation and Universal numbering system.The default is FDI World Dental Federation notation. (5) Dental Model Viewer Path:Set the path of the DentalViewer program.After the order scan is completed, the scanned data is viewed through DentalViewer.
Page 60 Aoralscan 2 User Manual NOTE After modifying the setting “User Interface Language” / “Dental Notation” / “EXO DentalACD Path”/”Dental Order Path” /”Order File Naming Rule”, click “Apply” button, and the message “New setting will take effect after restart, do you want to restart application now?” is displayed. Then click “Restart Now”...
Page 61: Data Storage
Aoralscan 2 User Manual ⑥Login: Fill in the account and corresponding password. The contact information filled in during registration is displayed in the upper left corner of the software. ⑦Phone login:First select the area, then enter the mobile number. The default area is China.
Page 62: Navigating Intraoralscan Interface
Aoralscan 2 User Manual 7.4. Navigating IntraoralScan Interface After creating and saving an order in the Dental Order System, the scanning interface is displayed. If no scanner is connected, an error message appears to remind you to check and reconnect the scanner, as shown below.
Page 63 Aoralscan 2 User Manual seconds, and relaunch IntraoralScan again. If the scanner is detected, the workspace is shown as below. （1） Guidance: Scan wizard description, prompt information, etc. （2） Process: Includes Dental Order System, upper jaw ( upper jaw implant), lower jaw (lower jaw implant), total jaw, pre-design, upload order.
Page 64 Aoralscan 2 User Manual  Delete button: Click the select button to select the specified area, click the delete button to delete the data;  Remove disconnected data button: Click this button to automatically delete a number of large pieces of isolated data.
Page 65 Aoralscan 2 User Manual  Intraoral: Checked by default. It is for intraoral scan. It is recommended not to tick this when scanning the dental model.  Refined Scan: Unchecked by default. It can be applied for selecting teeth in refined areas, and the post-processing data is more elaborate and refined.
Page 66 Aoralscan 2 User Manual Recommended value for manual setting of the dental scan gain: [0, 2]; Intraoral Scan gain is recommended to be 8.  Cut: By default, it is read from the camera. You can also manually set the cropping parameters of the top, bottom, left, and right sides of the camera window.
Page 67 Aoralscan 2 User Manual 。 here （11） IMU Icon: click the icon or hold the scanner, pause 1 second, shake 2 times, both can call out the IMU menu. Move the scanner to select different functions, white means the selected state, wait for the blue area expanded to the corresponding menu area and the function will be triggered.
Page 68: Introduction To Intraoralscan Functions
Aoralscan 2 User Manual part of the data.  :Next step. The icon will become “finish” during the scanning.  :Rotate the view data. （12） 3D View: Displays the 3D model data acquired by the scan. Support the left mouse button to rotate the 3D model, and the right mouse button to translate the 3D model data.
Page 69 Aoralscan 2 User Manual Figure a-scanning The S-scan process is: face (1) -> lip side to tongue side (2) -> tongue side to lip side (3) -> face (4). In Figure a, steps 1, 2, and 3 are performed as...
Page 70: Loading Project
Aoralscan 2 User Manual 7.5.2. Loading project Load the unscanned order (that is, the post-processing is not completed), open IntraoralScan and the following message is displayed: Click “OK” to continue the last scan and the total jaw data must be rescanned or click Cancel to restart scanning.
Page 71 Aoralscan 2 User Manual Click the “ “ button in the right side and then it will turn to “ ”, during the scanning, the model will display the tooth color (gray), it will guide the user to judge the reliability of the data quality in this area.
Page 72 Aoralscan 2 User Manual green area means this area is not scanned. User can re-scan the corresponding area according to the demand. Figure 2 -Scan is paused, hole areas are in green Click the “ “button again to continue the scanning Rescan If the scan data is not satisfactory, you can re-scan it.
Page 73 Aoralscan 2 User Manual Click “Yes” to delete the previous data and restart the scan. Add Scanning After the scan or post-processing is completed, do not exit scan software interface and click scan button to re-scan the data. Scanning Completed After confirming that the model scan is completed, click the finish button or long press the space bar to save the data.
Page 74: Scan Upper Jaw/Lower Jaw Implant
Aoralscan 2 User Manual Figure 3 - Scan completed If the scan is completed and you return to the dental order system or upload the order, the prompt box “Do you confirm to complete scanning?” is displayed. If you select “Yes”, in this order you can no longer add scanning.
Page 75 Aoralscan 2 User Manual implant scanning is added in the scanning process. Scan the lower jaw first (without intraoral scan bar). After the lower jaw scan is complete, the lower jaw implant scanning interface is displayed. Select the implant area and delete it.
Page 76 Aoralscan 2 User Manual Figure 2 - Delete the selected area Click the button to enter to the scanning implant process (the implant bar must be located in the model before scanning). Copyright  2019 All Rights Reserved - 75 -...
Page 78: Scan Metal Tooth
Aoralscan 2 User Manual Figure 4- Scan implant bar Figure 5 - Post-processed implant data 7.5.6. Scan Metal Tooth Select “ ” during the scanning, the metal teeth can be scanned, the result is showed as below Copyright  2019 All Rights Reserved - 77 - SHNING 3D TECH Co.,Ltd...
Page 79: Scan Total Jaw
Aoralscan 2 User Manual 7.5.7. Scan Total Jaw After the lower jaw scanning and the data processing are finished, the total jaw scanning interface is automatically displayed. Click the scan button or press the space bar to start scanning. After scanning some data, the software automatically performs dynamic bite stitching alignment, as shown below.
Page 80 Aoralscan 2 User Manual After the stitching After the upper and lower jaws’ data are stitched successfully as well as the whole jaw, click “ ” or press the space bar to pause the scanning, check the occlusion and collision results.
Page 81 Aoralscan 2 User Manual For the whole jaw scanning it does not need to scan the entire model, and you can just scan some part such as the whole jaw of the anterior portion, two total jaws on the left and right sides (recommended), three total jaws on the left and right sides and the anterior portion, so that the upper and lower jaw models of the scan are aligned.
Page 82: Pre-Design
Aoralscan 2 User Manual Scan a three-piece total jaw example: 7.5.8. Pre-design Pre-design function is added for users to easily apply the scanning data in the design software. Users can skip this process and upload orders directly. Copyright  2019 All Rights Reserved - 81 - SHNING 3D TECH Co.,Ltd...
Page 83 Aoralscan 2 User Manual This module provides five functions: ① Adjust Coordinate: used to (manually) adjust the reference coordinate system of the dental jaw, and adjust the dental jaw data to the unified standard reference coordinate system (supports the ExoCAD...
Page 84 Aoralscan 2 User Manual the margin line and for viewing the undercut; ③ Extract Margin Line: used to extract and save the margin line of the marked (corresponding) teeth; ④ Check Undercut: Used to calculate and view the undercut area of the marked (corresponding to the order) teeth.
Page 85 Aoralscan 2 User Manual Mark Teeth under the “Pre-design” process to enter interface Click on the button on which you can mark the teeth, and the tooth map on the left side shows the teeth defined by the order. Mark teeth operation: Select the tooth to be marked in the tooth map, and then double-click the corresponding tooth on the right to mark the tooth position information.
Page 86 Aoralscan 2 User Manual Margin line editing operation: double-click to add a point; select a point, the point color turns from green to yellow, and you can move or delete (double-click with right mouse or press Del key or click ) this point.
Page 87 Aoralscan 2 User Manual : Finish (confirm and save the extracted margin line and exit the extract margin line process). Check Undercut under the “Pre-design” process to enter the check Click the button undercut interface. The following figure shows the effect of the undercut display in different visual directions: the blue arrow indicates the visual direction, and the blue surface of the tooth indicates the undercut area.
Page 88 Aoralscan 2 User Manual bite interface. Green indicates that the teeth on the two jaws are distant while red indicates the contact area of the two jaw teeth, and blue indicates the bite overlap of the two jaw teeth. Figure 1 - Two jaw tile effect Figure 2 - Two jaw bite effect Copyright ...
Page 89: Upload Order
Aoralscan 2 User Manual Click the button “ ” to adjust the occlusion parameters “ “. Click on a point to detect the occlusion clearance in this point. Description of several operation buttons: :Open/Close Jaws (switche between the tile effect and bite effect of two jaws).
Page 90 Aoralscan 2 User Manual “You have not logged in to the account. Whether to direct to the setting interface to log in?”, select “Yes” to open the “Configure Account” interface. See chapter 6 “Upload Order” for the dental order system for details.
Page 91: Using Dental Cloud
Aoralscan 2 User Manual 8. Using Dental Cloud 8.1. Introduction to Dental Cloud Dental Cloud is a platform for connecting clinical and technical workers. In this platform, you can establish relationships between labs and doctors/clinics; you can manage order; manage organizations and maintain account information.
Page 92 Aoralscan 2 User Manual “Create new account”, select the registration type.  I am a hospital/clinic: register as a hospital/clinic institution and administrator. After registration is successful, you need to wait for the system administrator to review before you can log in.
Page 93: Establish A Relationship Network
Aoralscan 2 User Manual After the login is successful, the hospital, clinic or doctor's account can establish a network connection with the partner technical institution (i.e. add a lab) 8.3. Establish a Relationship Network The network can only be created by a doctor/hospital/clinic account and then the lab can accept or reject the connection.
Page 94: Management Institution
Aoralscan 2 User Manual 8.4. Management Institution An institution administrator can add/remove members for this institution. 8.4.1. Add Member After login, select “Admins” ->“Members”, and create a new administrator and ordinary members for the institution. ① Belongs: Select the name of the institution.
Page 95: Order Workflow
Aoralscan 2 User Manual corner of the page to see all the cases managed by this user Doctor and lab can instantly communicate on each order on the webpage. After clicking , they can send messages or documents in the prompted communication box.
Page 96 Aoralscan 2 User Manual Brief introduction to the workflow: (1) Doctor uploads order data: see the previous section for details. (2) The lab refused to accept the order: the technician of the lab refused to accept the order. (3) The lab received the order: the technician of the lab confirmed the order.
Page 97 Aoralscan 2 User Manual Select the file to be uploaded. After the file is uploaded successfully, click Submit. (5) Doctor confirmed plan: After the technician uploads the design plan, the order status is “Need Confirm Design”, and the doctor can download the design plan in the client Dental Order System.
Page 98 Aoralscan 2 User Manual the doctor chooses not to review the design when uploading data, skip this process. (6) During the making of the lab: After the doctor confirms the design plan, the order status is “Making”, indicating the processing data of the lab.
Page 99: Care And Maintenance
9. Care and Maintenance 9.1. Pre-cleaning,Disinfection, and Sterilization The whole set of Aoralscan 2 , including scanner tip, scanner body, and scanner cradle, requires proper care, cleaning, and handling. As individual part may be processed differently, read and follow the information and instructions given to help you effectively and thoroughly reprocess the set.
Page 100  Ensure that the scanner body is not placed in the cradle prior to disinfecting the scanner cradle. Follow the steps below to complete the disinfection: (1) Disconnect the power of the Aoralscan 2 (see Disconnecting the scanner on chapter 4). (2) Hold the cradle firmly with your hand.
Page 101 Follow the steps below to complete the disinfection: (1) Disconnect the power of the Aoralscan 2 (see Disconnecting the scanner on chapter 4). (2)Hold the scanner tip firmly with your thumb and forefinger on both sides, and then gently slide the tip off from the scanner, as illustrated.
Page 102 Aoralscan 2 User Manual NOTE Do not place your finger(s) on the mirror of the tip when detaching as this may result in damage to the mirror. (3) Store the detached tip in a safe place, e.g. a dental instrument tray, prior to disinfecting the scanner body.
Page 103 Aoralscan 2 User Manual wipe the surface of scanner body. CAUTIONS  Avoid using detergent of any kind as some detergents or surfactants might penetrate into the surface of the scanner body.  Do not clean the intake and exhaust vents with any sharp objects or other such tools.
Page 104 9.4.1. Cleaning and high-level disinfection Follow the steps below to perform cleaning and high-level disinfection: (1) Disconnect the power of the Aoralscan 2 (see Disconnecting the scanner on chapter 4). (2) Hold the scanner tip firmly with your thumb and forefinger on both sides, and then gently slide the tip off from the scanner body, as illustrated.
Page 105 Aoralscan 2 User Manual (3) Hold the supplied protection cap with the triangle mark facing upward. Then, align the protection cap blocks to the matching slots on the front end of the scanner body. (4) Slide the protection cap onto the scanner to prevent damage and dust.
Page 106 Aoralscan 2 User Manual to make sure that the cleaning is done properly and the mirror is not damaged during the cleaning process. (12) Cautiously fill a container with the FDA-approved disinfectant solution, e.g. CIDEX OPA® Solution. Do not spill any of it.
Page 107 9.4.2. Cleaning and steam sterilization Follow the steps below to perform cleaning and steam sterilization: (1) Disconnect the power of the Aoralscan 2 (see Disconnecting the scanner on chapter 4). Copyright  2019 All Rights Reserved - 106 - SHNING 3D TECH Co.,Ltd...
Page 108 Aoralscan 2 User Manual (2) Hold the scanner tip firmly with your thumb and forefinger on both sides, and then gently slide the scanner tip off from the scanner, as illustrated. CAUTION Do not place your finger(s) on the mirror of the tip when detaching as this may result in damage to the mirror.
Page 109 Aoralscan 2 User Manual  When cleaning the outer surface of the tip, move the brush lightly back and forth, and repeat for each side. (7) Repeat the previous step for at least two times. (8) Rinse the tip thoroughly with sterile water for at least 3 minutes.
Page 110 9.5. Scanner Storage In case you need to transport the device, we strongly recommend that you keep the original packaging after unpacking your Aoralscan 2. Shipping the device without its original packaging material may cause possible product damage and result in additional service fees.
Page 111 Aoralscan 2 User Manual from the package. 9.5.2. Daily and long-term storage  Always place the scanner in the cradle when it is not in use.  When the scanner tip is detached from the scanner body, always protect the subtle units and the inner optical components on the front end of the scanner by putting on the supplied protection cap.
Page 112: Hardware Specification
Aoralscan 2 User Manual Hardware Specification 10.1. Specifications Type name Intraoral Scanner Model name Aoralscan 2 Scanner 11 mm x 11 mm Scan field Non-contact scanner with the (DLP) Scan principle structured light Length: < 280 mm Width: < 40 mm Dimension Height: <...
