Specifications

TECHNICAL SPECIFICATIONS
Image Sensor
Sensitivity
Exposure
Imaging Features
Image Compression
Frame Rate
Typical File Sizes
Network Connection
Network Protocols Supported
Serial Connection
I/O Connectors
Internal Operating System
Security
Operating Temperature
Dimensions
Weight
EMI Approval
Power Requirements
FCC STATEMENT OF COMPLIANCE
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Opera-
tion of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
NetCam
NetCam - 640x480 Sharp 1/3" RGB Frame Transfer CCD
NetCam MP - 1280x960 Sony 1/2" RGB Frame Transfer CCD
2 LUX (with f1.2 iris)
Auto exposure with brightness adjustment and grid exposure selection or manual
exposure (1/50,000 second ~ 1.3 seconds)
Auto/manual color balance (including skew override), contrast enhancement (haze
subtraction, gamma correction) and sharpening
Industry Standard JPEG (adjustable quality/compression)
96x80 (4 frames per second)
160x120 (2.5 frames per second)
192x160 (2 frames per second)
320x240 (1 frame per second)
640x480 (1 frame every 3 seconds)
1280x960 (1 frame every 8 seconds) - NetCam MP only
320x240 (8~20KB)
640x480 (25~70KB)
1280x960 (50~120KB) - NetCam MP only
1 x 10-baseT Ethernet (10/100 compatible)
TCP/IP, HTTP, FTP, DHCP, PING, TELNET, DAYTIME, NTP, SMB, NFS
2 x RS-232 Ports, DB9, up to 115.2Kb/sec
4 x Digital Alarm Inputs
or
4 x 5V Swing Output Pins
1 x Fully Isolated Relay, 2A@5V or 0.5A@28VDC
Output is 5VDC@50mA
uClinux
Separate password-protected user accounts for administering the server and viewing the
images, additional user accounts can be added
-40°F to +120°F (-40°C to +49°C)
3.25" wide (82.5 mm) x 2.20" high (56 mm) x 6.6" deep (167 mm)
19.5 ounces (553 grams)
FCC Class A, CE (EN55024/1998, EN55022/1998)
8VDC - 15VDC (500mA@12V)
