- Page 1 User Manual ...
- Page 2 Omnicabsim Deluxe cabinet simulator, praised by bass and guitar players worldwide. As usual with DSM noisemaker´s products, this super practical pedal is packed with a lot of features and easy to use layout in a small package that will fit on any pedalboard with a tight real estate.
- Page 3 Connections: The Omnicabsim MINI features: ¼” Input Jack : Connect here the output from your pedalboard/ amp fx send, or just the instrument (for best results, a high output instrument, or a preamp is recommended) ¼” Output Jack : This output can be set to carry the Cabinet simulator signal or the Bypass signal.
- Page 4 Controls: Switches: Bypass Switch: Toggles between the effect and the input signal. N ote: Be aware that DI levels are lower than instrument/preamp level. The level knob will help you get the right DI signal level, but if you bypass the pedal, the level may be much higher.
- Page 5 Knobs: Level : Sets the master output level of the effect. Gain : Emulates the gain of a power amp, starting from linear behaviour to slight compression up to soft clipping. It also considers the output transformer core saturation, limiting the lows and highs as the gain raises. The amount of clipping is also dependent on the input signal level.
- Page 6 Texture: The texture controls the shape and response of the high end. It models the variety of sharp low pass filters naturally made by speaker’s inductance and reactance. You can precisely set the amount of high end fizz by turning this knob. It can make the nastiest fuzz sound like velvet if set right.
- Page 7 Technical Specs: ● Size (cm): 3.5w X 10.8h X 4.5t ● Weight: 180gr. ● Input Impedance: 200K Ohms ● Output impedance: ○ Out: 1k Ohms ○ XLR: 100 Ohms ● Power Consumption: 20mA Always use a good quality power source. Regulated 9v DC, center negative is recommended.
