AGRI-COVER
Use these instructions to install and operate remote control with AGRI-COVER
Switch Control. Read and follow these instructions along with the installation instructions
carefully before using the Switch Control.
NOTICE TO INSTALLER: Even if familiar with hardware, read instructions prior to
installation as improvements may be made without notice. Always handle components
with care. If you have questions or problems call customer service. When done, these
instructions must be given to the consumer.
NOTICE TO CONSUMER: Before using AGRI-COVER
read operating and safety sections. Save these instructions for future reference.
DATE PURCHASED:
WHERE PURCHASED:
SERIAL NUMBER 1:
SERIAL NUMBER 2:
REMOTE CONTROL INSTRUCTIONS
TM
FOR YOUR RECORDS
Questions? 800-233-4655
agricover.com
Switch and Remote Control,
TM
(Located inside Switch Control
(Located on back of Remote Control)
TM
cover)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGRI-COVER and is the answer not in the manual?

Questions and answers

Related Manuals for aci AGRI-COVER

Summary of Contents for aci AGRI-COVER

  • Page 1 AGRI-COVER REMOTE CONTROL INSTRUCTIONS Use these instructions to install and operate remote control with AGRI-COVER Switch Control. Read and follow these instructions along with the installation instructions carefully before using the Switch Control. NOTICE TO INSTALLER: Even if familiar with hardware, read instructions prior to installation as improvements may be made without notice.

  • Page 2: Safety Information

    PREPARATION Follow standard installation instructions before performing these instructions. COMPONENTS TOOLS NEEDED • (1) AGRI-COVER Switch Control • Protective eyewear • Slotted screwdriver • (1) Remote Control SAFETY INFORMATION • Always use caution when operating tarp. • Disconnect power before servicing system or electrical components.

  • Page 3: Remote Control Diagram

    REMOTE CONTROL DIAGRAM The following diagram identifies the remote control components. BACK FRONT COMPONENT DESCRIPTION < (Channel Decreases the channel number. Press the button to Decrease) decrease once or hold button to decrease rapidly. Display Displays the currently selected channel. >...
  • Page 4 OVERVIEW After the Switch Control (receiver) is installed, the remote control may be setup. The remote control provides wireless push-button control. The remote is simple to use and provides convenient, reliable operation and is suitable for a wide variety of applications. NOTE: Only Switch Controls with rotary switches are compatible with wireless remote controls, Switch Controls without rotary switches are incompatible with wireless remote controls.
  • Page 5 2. PROGRAM A REMOTE CONTROL Your Switch and Remote Control come pre-programmed to each other. If reprogramming is required or you desire to use a different channel, follow the procedures below. CLEAR RECEIVER CAUTION: This step involves pressing a button near power cables. Avoid touching power wires.
  • Page 6 2. PROGRAM A REMOTE CONTROL (Continued) PROGRAM REMOTE TO RECEIVER A. Use < and > to select the desired remote channel. NOTE: There are 99 selectable channels. B. Open Switch Control and locate the Program button. C. In the control box, press and hold Program, the LED activates.
  • Page 7 3. CONNECTING REMOTE TO RECEIVER NOTE: After 3 minutes of inactivity, the remote control times out and deactivates its communication hardware. A. To activate the remote control communication hardware and connect to receiver, press Activate/Stop for approximately 3 seconds. NOTE: The LED inside the Switch Control activates when remote control is connected.

  • Page 8: Remote Battery Replacement

    5. REMOTE BATTERY REPLACEMENT NOTE: If remote becomes unresponsive or channel numbers do not appear on display, replace battery. A. Remove battery door. B. Remove battery. C. Insert new A23 battery. Only use new A23 batteries. NOTE: Ensure battery polarity matches the battery slot polarity indicators.

  • Page 9: General Troubleshooting

    GENERAL TROUBLESHOOTING If system has a battery cutoff switch, ensure it is turned to “ON” position. Check all wiring components. A. Check positive (+) and negative (-) wire connections on vehicle battery. B. Retighten and re-crimp loose connections. C. Replace any corroded connections. D.
  • Page 10 TROUBLESHOOTING REMOTE CONTROL PROBLEM SOLUTION Remote transmitter does not work. None A. Check remote for dead batteries. If of the lights turn on when remote is turned batteries are dead, replace with new, quality, high capacity batteries. Ensure batteries are loaded correctly in remote and terminals are clean.
  • Page 11 TROUBLESHOOTING SWITCH CONTROL PROBLEM SOLUTION After activating, Switch Control LED A. Typically indicates a breaker issue. If flashes and system does not operate. breaker resets, try operating. If breaker does not reset, disconnect power, replace breaker and try activating again. System will not operate with remote or A.

  • Page 12: Manufacturer's Limited Warranty

    Goods to be returned must have a pre-authorized RA # (Returned Authorization Number) - obtained by calling the number above. Mark the number on the package and ship it freight prepaid to address below. Agri-Cover, Inc. will pay freight to return goods to sender.
